REVISIONS
REV.
A
B
F
ECO. NO
648
679
1126
1869
DESCRIPTION
INITIAL RELEASE
REMOVED KEY, FROM 3.2 TO 3.15
DATE
6/15/2005
7/13/2005
BY
TT
TT
MV
JH
F
C
D
UPDATE SPECIFICATION
9/12/2006
UPDATE CONTACT DEPTH TO 6.5mm, TOLERANCE & 12/23/2008
TEXT
E
E
A
.197 5.00
.100 2.54
D
D
.100 2.54
A±.008 [ 0.20]
B±.014 [ 0.35]
02-20, 0.20mm MAX.
21-40, 0.30mm MAX.
C
.040±.002 1.02±0.05
RECOMMENDED PCB LAYOUT
.124±.012 3.15±0.30
C
.256±.008 6.50±0.20
.335 8.50
.063±.010 1.60±0.25
B
B
A
NOTES:
1. INSULATOR MATERIAL: SEE PART NUMBER CODING.
2. CONTACT MATERIAL: PHOSPHOR BRONZE.
3. CONTACT PLATING: SEE PART NUMBER CODING.
4. CURRENT RATING: 3 AMPS
5. INSULATOR RESISTANCE: 5000 MEGOHMS MIN.
6. CONTACT RESISTANCE: 20 MILLIOHMS MAX.
7. DIELECTRIC WITHSTANDING: AC 500V.
8. OPERATING TEMPERATURE: -40° C TO +105° C.
*INDICATED TEMPERATURE AND TIME IS FOR COMPONENT
INSULATOR. HIGHER PROCESSING TEMPERATURES MAY BE USED,
PROVIDED HEAT IS APPLIED FROM BACK SIDE OF PCB, AND INSULATOR
DOES NOT EXCEED INDICATED TEMPERATURE AND TIME.
8
7
6
.100±.010 2.54±0.25
.024(w) X .016(t)
[0.60 X 0.40]
.100±.004 2.54±0.10
Pb
R
oHS COMPLIANT
5
4
DIMENSIONS ARE IN INCHES[MM]
TOLERANCES:
ANGULAR: 5
.XX= .014 [.35]
.XXX= .008 [.20]
SURFACE FINISH: 63 Ra
UNLESS OTHERWISE SPECIFIED:
DRAWN
DATE
NAME
12/15/08
JH
REMOVE ALL BURRS AND SHARP EDGES .010 MAX
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
DESCRIPTION
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
PART NUMBER
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
HEADER FEMALE, 2.54mm CC, 2 ROWS, RA
A
xPxCxx2LJBN-RC
SIZE DWG. NO.
INTERPRET DIMENSIONS AND GEOMETRIC
TOLERANCING
PER: ANSI Y14.5M-1994
3
2
SCALE: 8:1
1
C
REV
10494
D
SHEET 1 OF 1
FILE NAME: Z:\COMPONENTS\Taiwan\10494, P(N)PxCxx2LJBN-RC PRINT: 2/3/2009
