KGM
three-terminal capacitor
EU
features
Surface mount type noise filter
Plated terminals provide excellent solder resistance
Small size and high rated DC current
0603-2A, 0805-2A, 1206-2A series is available
in signal lines in addition to power line
•
Marking: Black body color with no marking
•
Products with lead-free terminations meet
EU RoHS requirements
•
•
•
•
dimensions and construction
L
Size
W
0603
t
e
Glass
Coating
g
GND
Terminals
(Ag + Ni,
Sn Plating)
e
Terminals
(Ag + Ni,
Sn Plating)
0805
1206
1812
L
W
t
g
e
.063±.008 .031±.008 .024±.008 .020±.008 .008±.006
(1.6±0.2)
(0.8±0.2)
(0.5±0.2) (0.2±0.15)
(0.6±0.2)
.079±.008 .049±.008 .031±.008 .016±.012 .012±.008
(2.0±0.2) (1.25±0.2) (0.8±0.2)* (0.4±0.3)
(0.3±0.2)
.126±.008 .063±.008 .031±.008 .039±.012
(3.2±0.2)
(1.6±0.2) (0.8±0.2)* (1.0±0.3)
.016±.012
.177±.012 .126±.012 .039±.008 .039±.012
(0.4±0.3)
(4.5±0.3)
(3.2±0.3)
(1.0±0.3)
(1.0±0.2)
* KGM0805 470
KGM1206CHT221/2A:
KGM0805 101
t = .043 ± .008
(1.1 ± 0.2)
KGM0805 222
t = .035 ± .008
(0.9 ± 0.2)
ordering information
New Part #
KGM
Type
0805
Size
0603
0805
1206
1812
For further information on packaging,
please refer to Appendix A.
H
Rated
Voltage
C: 16V
E: 25V
V: 35V
H: 50V
C
Temp.
Charact.
C
F
T
Termination
Material
T: Sn
TE
Packaging
TE: 7" embossed plastic
(0603 - 4,000 pieces/reel)
(0805 - 4,000 pieces/reel)
(1206 - 2,000 pieces/reel)
(1812 - 1,000 pieces/reel)
220
Capacitance
2 significant
digits + no.
of zeros
2A
Rated
Current
1A
2A
4A
circuit schematic
In
Out
temperature characteristics
Temperature
Character
C
F
Temperature
Range
-25°C to +85°C
Standard
Temperature
20°C
Rate of
Change
(Capacitance)
±15%
-80 ~ +30%
GND
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
2/24/08
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
.O.
273
EMI/EMC
filtering
KGM
three-terminal capacitor
environmental applications
(continued)
Performance Characteristics
Parameter
Terminal Adhesion Strength
Requirement
No physical damage
Test Method
Solder a chip to a test
substrate and then
laterally apply a
load (5N, 500gF) in
the arrow direction
Chip
Substrate
Resistance to Solder Heat
Appearance: No physical damage
Capacitance: Within tolerance
Dielectric Loss: Within tolerance
Insulation Resistance: Within tolerance
Flux: 25% rosin Preheating: 60 seconds
Preheating Temperature: 150°C
Solder: H60A
Solder Temperature: 260°C ±5°C
Dip Time: 5 seconds ± 0.5 second
Flux: 25% rosin Preheating: 60 seconds
Preheating Temperature: 150°C
Solder: H60A
Solder Temperature: 230°C ±5°C
Dip Time: 4 seconds ± 1 second
Repeat the following heat cycle 10 times:
Step:
1
2
3
4
Temperature:
-40°C ± 3°C
Room Temp.
85°C ± 2°C
Room Temp.
Time:
30 minutes
15 minutes
30 minutes
15 minutes
± 3 minutes
maximum
± 3 minutes
maximum
Solderability
More than 95% of the terminal electrode
shall be covered with new solder
Temperature Cycle*
Appearance: No physical damage
Capacitance: Within tolerance
Dielectric Loss: Within tolerance
Insulation Resistance: Within tolerance
High Temperature
Resistance*
Appearance: No physical damage
Capacitance: Within tolerance
Dielectric Loss: Within tolerance
Insulation Resistance: Within tolerance
Appearance: No physical damage
Capacitance: Within tolerance
Dielectric Loss: Within tolerance
Insulation Resistance: Within tolerance
Appearance: No physical damage
Capacitance: Within tolerance
Temperature: 70°C ± 2°C
Bias: 150% of rated voltage
Test Time: 1000 +48/-0 hours
Humidity Resistance
(Unload)*
Temperature: 85°C ± 2°C
Humidity: 85% ± 5%
Test Time: 500 +24/-0 hours
20
Substrate Bending Test
After soldering a chip to a test
substrate, bend the substrate
Substrate
by 1 mm and then measure.
The substrate is GE4 or
based on GE4.
45
±
2
Temperature: 40°C ± 2°C
Humidity: 90 - 95%
Bias: 100% of rated voltage
Test Time: 500 +24/-0 hours
Temperature: -40°C ± 2°C
Test Time: 1000 +48/-0 hours
Weight
Displacement
45
±
2
Humidity Resistance
(Load)*
Appearance: No physical damage
Capacitance: Within tolerance
Dielectric Loss: Within tolerance
Insulation Resistance: Within tolerance
Appearance: No physical damage
Capacitance: Within tolerance
Dielectric Loss: Within tolerance
Insulation Resistance: Within tolerance
Appearance: No physical damage
Capacitance: Within tolerance
Dielectric Loss: Within tolerance
Insulation Resistance: Within tolerance
Low Temperature
Resistance
(Unload)*
Vibration
The frequency of applied vibration should be swept
from 10 Hz to 55 Hz and return to 10 Hz. This cycle
time should be about 1 minute and this cycle should
be repeated.
Amplitude (Total Excursion): 1.5 mm
This motion shall be applied for a period of 2 hours in
each of 3 mutually perpendicular axes (total of 6 hours).
* After temperature cycle test, high temperature resistance test, humidity resistance test or low temperature resistance test, the tested sample
should be measured after having been left in temperature from 15°C to 35°C and relative humidity from 45% to 75% for 24 hours.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
3/05/07
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
.O.
275
