LESHAN RADIO COMPANY, LTD.
LR6206
INTRODUCTION
The LR6206 Series
are a group of
positive voltage regulators manufactured
by CMOS technologies with high ripple
rejection,
extremely
low
power
consumption and low dropout voltage,
which provide large output currents even
when the difference of the input-output
voltage is small. Each of the CE6206
series consists of a high-precision
voltage reference, an error correction
circuit, and a current limited output
driver. Thus the series are very suitable
for the battery-powered equipments,
such as Portable/Palm computers,
Portable consumer equipments, industry
equipments and so on, which want to
prolong the using life of the battery.
FEATURE
●
Low Power Consumption：5.0µA（Typ）
●
Standby Current : Less than 0.1µA (TYP.)
●
Maximum Operating Voltage : 2.0V ~ 10V
●
Maximum Output Current：300mA（Typ）
●
Output Voltage Range：1.4V½6.0V，
（selectable
in 0.1V steps）
●
High Accuracy：±2％（Typ）
●
Dropout Voltage：160mV@100mA（3.0V Typ）
●
Excellent Line Regulaion：0.1％/V
●
High Ripple Rejection : 62dB (10kHz)
●
Buit-in Chip Current Limit & Short Protect Circuit
●
Static safety: 2KV@HBM
●
TC：100ppm/℃
APPLICATION
●
Battery powered systems
●
Radio control systems
●
Portable instrumentations
●
Portable/Palm computers
●
Reference Voltage Sources
●
Portable consumer equipments
BLOCK DIAGRAM
ORDER INFORMATION
1/5
LESHAN RADIO COMPANY, LTD.
LR6206
ELECTRICAL CHARACTERISTICS
L R 6206 Series
PARAMETER
Output Voltage
Supply Current
Standby Current
Output Current
Dropout Voltage
(Note 3)
Load Regulation
Line Regulation
Output Voltage
Temperature
Characteristics
Short Current
Input Voltage
CE "High" Voltage
CE "Low" Voltage
SYMBOL
V
OUT
(E)
(Note 2)
I
SS
I
Standby
Iout
V
dif1
V
dif2
∆V
OUT
∆V
OUT
∆V
IN
* V
OUT
∆V
OUT
∆T
* V
OUT
I
Short
V
IN
V
CE
“H”
V
CE
“L”
CONDITIONS
I
OUT
=40mA
V
IN
= V
OUT
+1V
V
CE
=V
IN
=Vout+1V
V
CE
=V
SS
－
I
OUT
=40mA
I
OUT
=100mA
V
IN
= V
OUT
+1V,
1mA≤I
OUT
≤100mA
I
OUT
=40mA
V
OUT
+1V≤V
IN
≤10V
I
OUT
=40mA
-40≤T≤+85
V
OUT
=V
SS
－
1.0
300
80
160
10
0.1
MIN.
V
OUT
*0.98
TYP.
V
OUT
5.0
0.1
Ta=25℃
MAX.
V
OUT
*1.02
UNITS
V
μA
μA
mA
mV
mV
mV
%/V
100
200
10
V
IN
0.2
ppm
mA
V
V
V
NOTE :
1. V
OUT
：Specified
Output Voltage.
2. V
OUT
(E)
：Effective
Output Voltage ( Ie. The Output Voltage When V
IN
= (V
OUT
+1.0V)
And Maintain A Certain I
OUT
Value).
3. V
dif
：The
Difference Of Output Voltage And Input Voltage When Input Voltage Is
Decreased Gradually Till Output Voltage Equals To 98% Of V
OUT
(E).
TYPICAL APPLICATION CIRCUIT
LR6206A Series
LR6206B Series
3/5
