54F402LMQB: DescriptionCRC Generator Circuit, F/FAST Series, 1-Bit, TTL, CQCC20, QFN-20; Categorylogic logic; File Size217KB，15 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

54F402LMQB Overview

CRC Generator Circuit, F/FAST Series, 1-Bit, TTL, CQCC20, QFN-20

54F402LMQB Parametric

Parameter Name	Attribute value
package instruction	QCCN,
Reach Compliance Code	unknow
Other features	SELECTABLE POLYNOMIALS
series	F/FAST
JESD-30 code	S-CQCC-N20
length	8.89 mm
Logic integrated circuit type	CRC GENERATOR CIRCUIT
Number of digits	1
Number of functions	1
Number of terminals	20
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QCCN
Package shape	SQUARE
Package form	CHIP CARRIER
propagation delay (tpd)	26 ns
Filter level	MIL-STD-883 Class B
Maximum seat height	1.905 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	TTL
Temperature level	MILITARY
Terminal form	NO LEAD
Terminal pitch	1.27 mm
Terminal location	QUAD
width	8.89 mm
Base Number Matches	1

Preview

Download Datasheet

View All

54F 74F402 Serial Data Polynomial Generator Checker

January 1995

54F 74F402 Serial Data Polynomial

Generator Checker

General Description

The ’F402 expandable Serial Data Polynomial generator

checker is an expandable version of the ’F401 It provides

an advanced tool for the implementation of the most widely

used error detection scheme in serial digital handling sys-

tems A 4-bit control input selects one-of-six generator poly-

nomials The list of polynomials includes CRC-16 CRC-

CCITT and Ethernet as well as three other standard poly-

nomials (56

order 48

order 32

order) Individual clear

and preset inputs are provided for floppy disk and other

applications The Error output indicates whether or not a

transmission error has occurred The CWG Control input

inhibits feedback during check word transmission The

’F402 is compatible with FAST devices and with all TTL

families

Features

Guaranteed 30 MHz data rate

Six selectable polynomials

Other polynomials available

Separate preset and clear controls

Expandable

Automatic right justification

Error output open collector

Typical applications

Floppy and other disk storage systems

Digital cassette and cartridge systems

Data communication systems

Commercial

74F402PC

Military

Package

Number

N16E

Package Description

16-Lead (0 300 Wide) Molded Dual-In-Line

16-Lead Ceramic Dual-In-Line

16-Lead Cerpack

20-Lead Ceramic Leadless Chip Carrier Type C

54F402DM (Note 1)

54F402FM (Note 1)

54F402LM (Note 1)

J16A

W16A

E20A

Note 1

Military grade device with environmental and burn-in processing Use suffix

DMQB FMQB and LMQB

Logic Symbol

Connection Diagrams

Pin Assignment

for DIP SOIC and Flatpak

Pin Assignment

for LCC

TL F 9535 – 1

TL F 9535 – 2

TL F 9535–4

TRI-STATE is a registered trademark of National Semiconductor Corporation

Ethernet is a registered trademark of Xerox Corporation

1995 National Semiconductor Corporation

TL F 9535

RRD-B30M105 Printed in U S A
