Ring Terminal, KYNAR
■
Insulated
B1.
Cable Ties
Type PK-R
• For nuclear containment areas and high temperature to 300°F
(150°C) applications
• Color code: natural with appropriate color stripe to identify
wire range
• Ring tongue design assures a secure connection in high
vibration applications
• UL and CSA rated up to 600 V per UL 486A/B
Note: For PK18
–
PK10 Terminals the following applies:
• Classified as Class 1E in accordance with IEEE 323-2003
• Metal insulation grip sleeve crimps to wire insulation, providing
