ESAL01-01N datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> ESAL01-01N

ESAL01-01N: DescriptionRectifier Diode, 1 Phase, 2 Element, 150A, 100V V(RRM), Silicon, MODULE-2; CategoryDiscrete semiconductor diode; File Size159KB，2 Pages; ManufacturerFuji Electric Co., Ltd.

Download Datasheet Parametric View All

ESAL01-01N Overview

Rectifier Diode, 1 Phase, 2 Element, 150A, 100V V(RRM), Silicon, MODULE-2

ESAL01-01N Parametric

Parameter Name	Attribute value
Objectid	2015708061
Parts packaging code	MODULE
package instruction	R-XUFM-X2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	FREE WHEELING DIODE
application	POWER
Configuration	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.3 V
JESD-30 code	R-XUFM-X2
Maximum non-repetitive peak forward current	2000 A
Number of components	2
Phase	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-40 °C
Maximum output current	150 A
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	100 V
surface mount	NO
Terminal form	UNSPECIFIED
Terminal location	UPPER

Preview

Download Datasheet

View All

ESAL01

(2x150A)

100V,200V / 150A

2 in one-package

POWER DIODE MODULE

Features

· Glass Passivation Chip

· Variety Connection Menu

· Non-Insulated Type

POWER DIODE MODULE

Outline Drawings, mm

Applications

· Battery Chargers

· Free-Wheeling Diode

· General Purpose Rectifiers

Inner Curcuit Schematic

Symbol

Inner Circuit

Maximum ratings and characteristics

Absolute maximum ratings

Item

Repetitive peak reverse voltage

Non-repetitive peak reverse voltage

Average output current

Surge current

Operating junction temperature

Storage temperature

Screw torque

*1: Recommendable value : 2.5 to 3.0 N·m(M5)

Symbol

RRM

Conditions

型

廃

RSM

F(AV)

FSM

50/60Hz Sine wave, Tc=100°C

From rated load,Sine wave 10ms

From rated load

種

機

100

150

-01

Rating

ct.

-02

Unit

°C

N·m

200

250

2 x 150

2000

16000

-40 to +150

stg

(M5)

3.5

Electrical characteristics (Ta=25°C Unless otherwise specified )

Item

Forward voltage drop

Reverse current

Thermal Characteristics

Item

Thermal resistance

Symbol

th(j-c)

th(c-f)

Conditions

Junction to case

the base to cooling fin *

Min.

Typ.

Max.

0.15

0.05

Unit

°C/W

Symbol

RRM

Conditions

Tj=25°C, I

=450A

Tj=150°C, V

RRM

Min.

Typ.

Max.

1.35

Unit

: With Thermal Compound
