C1210H209C5GAC7025 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> C1210H209C5GAC7025

C1210H209C5GAC7025: DescriptionCeramic Capacitor, Ceramic, 50V, 12.5% +Tol, 12.5% -Tol, C0G, -/+30ppm/Cel TC, 0.000002uF, 1210,; CategoryPassive components capacitor; File Size533KB，6 Pages; ManufacturerKEMET; Websitehttp://www.kemet.com; Environmental Compliance

Download Datasheet Parametric View All

C1210H209C5GAC7025 Overview

Ceramic Capacitor, Ceramic, 50V, 12.5% +Tol, 12.5% -Tol, C0G, -/+30ppm/Cel TC, 0.000002uF, 1210,

C1210H209C5GAC7025 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	712165727
package instruction	, 1210
Reach Compliance Code	compliant
Country Of Origin	Mexico
ECCN code	EAR99
YTEOL	6.88
capacitance	0.000002 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	0.78 mm
JESD-609 code	e3
length	3.2 mm
negative tolerance	12.5%
Number of terminals	2
Maximum operating temperature	200 °C
Minimum operating temperature	-55 °C
Package form	SMT
method of packing	TR, Plastic, 7 Inch
positive tolerance	12.5%
Rated (DC) voltage (URdc)	50 V
series	C(SIZE)H
size code	1210
Temperature characteristic code	C0G
Temperature Coefficient	30ppm/Cel ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
width	2.5 mm

Preview

Download Datasheet

View All

Product Bulletin

Surface Mount Ceramic Chip Capacitors

High Temperature 200ºC C0G MLCC

No Piezoelectric Noise.

Extremely low ESR and ESL.

High Thermal Stability.

High Ripple Current Capability.

Preferred capacitance solution at line frequencies and into the MHz range.

No capacitance change with respect to applied rated DC voltage.

Minimal capacitance change with respect to temperature from -55ºC to +200ºC.

No capacitance decay with time.

Non-polar device.

Beneﬁts and Features:

Typical applications include critical timing, tuning, circuits requiring low loss,

circuits with pulse, high current, decoupling, by-pass,

ﬁ

ltering, transient voltage

suppression, blocking and energy storage for use in extreme environments com-

monly present in applications such as down-hole exploration, aerospace engine

compartments and geophysical probes.

Applications:

KEMET’s New High Temperature Surface Mount C0G MLCCs feature a robust and proprietary base metal

dielectric system that offers industry-leading performance relative to capacitance and case size combined with

capacitance stability at extreme temperatures up to +200ºC. This new platform promotes downsizing opportu-

nities of existing High Temperature C0G technology, and offers replacement opportunities of existing X7R/BX/

BR technologies.

Standard capacitance ratings for these devices range from 0.5 pF up to 0.22

μF

in capacitance tolerance offer-

ings of ±0.25pF, ±0.5pF, ±1%, ±2%, ±5%, ±10%, or ±20%. The Temperature Coefﬁcient of Capacitance (TCC)

is ±30ppm/°C from -55°C to +200°. Devices are available in DC voltage ratings of 10V, 16V, 25V, 50V and

100V, with a maximum dissipation factor of 0.10%. Seven standard EIA case size options are available which

include –0603, 0805, 1206, 1210, and 1812- with either nickel barrier/tin or Sn/Pb terminations.

Outline Drawing

Dimensions - Millimeters (Inches)

EIA SIZE

CODE

0603

0805

1206

1210

1812

METRIC

SIZE CODE

1608

2012

3216

3225

4532

LENGTH

1.6 (.063) ± .15 (.006)

2.0 (.079) ± .20 (.008)

3.2 (.126) ± .20 (.008)

4.5 (.177) ± .30 (.012)

WIDTH

0.8 (.032) ± .15 (.006)

1.25 (.049) ± .20 (.008)

1.6 (.063) ± .20 (.008)

2.5 (.098) ± .20 (.008)

3.2 (.126) ± .30 (.012)

BANDWIDTH

0.35 (.014) ± .15 (.006)

0.50 (.020) ± .25 (.010)

0.60 (.024) ± .35 (.014)

SEPARATION

minimum

0.7 (.028)

0.75 (.030)

N/A

F4002 01/10
