USL Series
Powertron
•
•
•
•
•
•
•
UAL-25-4T
UAL-25-4
UAL-25-4TR
Power Rating 5 to 300Watts
All Welded Construction
Resistances from 0.005 to 250kOhms
Tolerance to ±0.01%
High Overload and Pulse Handling
Low TCR: ± 20ppm/K Standard
Four Terminal Versions Available
SPECIFICATIONS
Type
UAL-5
UAL-10
UAL-25
UAL-50
UAL-100
UAL-180
UAL-250
UAL-300
MIL-R-39009
MIL-R-18546
Style
Power Rating ( W @ 25°C )
Commercial
7.5
a
12.5
a
25
b
50
c
100
d
180
d
250
d
300
e
1
a
b
c
d
e
MIL
5
a
10
a
20
b
30
c
75
d
-
120
d
-
Free Air
4.5
7.5
12
20
40
-
100
75
Resistance
Range
1
0.01 to 22K
0.01 to 47K
0.01 to 90K
0.01 to 250K
0.01 to 50K
0.01 to 50K
0.01 to 50K
0.005 to 100K
RER-60 / RE-60
RER-65 / RE-65
RER-70 / RE-70
RER-75 / RE-75
RER-77 / RE-77
-
RER-80 / RE-80
-
For non-inductive windings, divide maximum resistance by 2
Heatsink Required : 0.040 [1.0] Alum. Plate, 129 in
2
[832 cm
2
] or equiv.
Heatsink Required : 0.040 [1.0] Alum. Plate, 167 in
2
[1077 cm
2
] or equiv.
Heatsink Required : 0.059 [1.5] Alum. Plate, 291 in
2
[1877 cm
2
] or equiv.
Heatsink Required : 0.125 [3.2] Alum. Plate, 294 in
2
[1896 cm
2
] or equiv.
Heatsink Required : 0.125 [3.2] Alum. Plate, 895 in
2
[5780 cm
2
] or equiv.
Ordering Information
For Non-Inductive Windings / insert the letter “N” ( i.e. UALN-25 )
Part Number - Resistance - Tolerance - TCR ( If not standard )
Example: UAL-25 10 Ohm 1%
Document Number: 64325
Revision: 20-09-10
For technical questions, contact:
powertron@vishaypg.com
www.powertron.de
1
UAL Series
Powertron
SPECIFICATIONS
(continued)
Specification
Tolerances
Temperature Coefficient
Value
±0.01% to ±10% ( 1% Standard )
>10W : ±20ppm/K
1W to10W : ±50ppm/K
<1W : Call Factory
-55°C to +275°C
1500 VAC
Centerless ground ceramic core
Tinned copper or copperweld leads
High-temperature epoxy molding Compound
Anodized aluminum housing
All welded terminations
Temperature Range
Dielectric Strength
Constuction
Environmental Performance
(MIL-STD 202)
DR
±0.2% + 0.05W
±1% + 0.05W
±0.2% + 0.05W
±0.2% + 0.05W
±0.2% + 0.05W
±0.2% + 0.05W
±0.1% + 0.05W
±0.1% + 0.05W
Dielectric
Load Life
Storage
Moisture Resistance
Thermal Shock
5X Overload ( 5s )
Shock
Vibration
Power Derating Curve
120
100
80
Mo
u
nt
ed
on
Power ( % )
He
60
40
20
0
0
A
B
C
D
ats
ink
Free-air Derating
A : UAL-5, UAL-10
B : UAL-25
C : UAL-50, UAL-100, UAL-250
D : UAL-300
50
100
150
200
250
300
350
Ambient Temperature (°C)
www.powertron.de
2
For technical questions, contact:
powertron@vishaypg.com
Document Number: 64325
Revision: 20-09-10
