RangeMAX™
TM
®
LXMG1611-01
Digital Dimming CCFL Inverter Module
P
RODUCTION
D
ATA
S
HEET
ABSOLUTE MAXIMUM RATINGS
WWW .
Microsemi
.C
OM
Input Supply Voltage (VIN).....................................................................................................................................................-0.3V to 18V
Output Voltage, no load ..............................................................................................................................Internally Limited to 1800V
RMS
Output Current ..............................................................................................................................................10mA
RMS
(Internally Limited)
Output Power .......................................................................................................................................................................................... 6W
Input Signal Voltage (BRITE Input) .......................................................................................................................................-0.3V to 6.5V
Input Signal Voltage ( SLEEP , V
SYNC(-)
, V
SYNC(+)
Inputs) ........................................................................................................ -0.3V to V
IN
Ambient Operating Temperature Range ................................................................................................................................... 0°C to 70°C
Storage Temperature Range .................................................................................................................................................-40°C to +85°C
Note: Exceeding these ratings could cause damage to the device. All voltages are with respect to Ground. Currents are positive into, negative out of
specified terminal
.
RECOMMENDED OPERATING CONDITIONS
This module has been designed to operate over a wide range of input and output conditions. However, bet efficiency and performance will be obtained if
the module is operated under the condition listed in the ‘R.C.’ column. Min. and Max. columns indicate values beyond which the inverter, although
operational, will function optimally.
Parameter
Input Supply Voltage Range (Functional)
Input Supply Voltage (Fully Regulated Lamp Current)
Output Power
Brightness Control Input Voltage Range
Lamp Operating Voltage
Lamp Current (Full Brightness)
Operating Ambient Temperature Range
Symbol
V
IN
P
O
V
BRT ADJ
V
LAMP
I
OLAMP
T
A
LXMG1611-01
Min
R.C.
Max
8
9
0
300
0
12
12
4
675
7
18
16
5
2.5
800
70
Units
V
V
W
V
V
RMS
mA
RMS
°C
ELECTRICAL CHARACTERISTICS
Unless otherwise specified, these specifications apply over the recommended operating conditions and 25°C ambient temperature for the LXMG1611.
Parameter
OUTPUT PIN CHARACTERISTICS
Full Bright Lamp Current
Minimum Lamp Current (Note 2)
Lamp Start Voltage
Operating Frequency
BRITE INPUT
Input Current
Input Voltage for Max. Lamp Current
Input Voltage for Min. Lamp Current
Symbol
Test Conditions
V
BRT ADJ
= 2.5V
DC
,
SLEEP
= HIGH,
Burst Duty = 100%, V
IN
= 9V
DC
V
BRT ADJ
= 0V
DC
,
SLEEP
= HIGH,
Burst Duty = 2%, V
IN
= 9V
DC
0°C < T
A
< 40°C, V
IN
> 7V
DC
V
BRT ADJ
= 2.5V
DC,
SLEEP
= HIGH, VIN = 12V
DC
V
BRT ADJ
= 0V
DC
I
O(LAMP)
= 100% Duty Cycle
I
O(LAMP)
= Minimum Duty Cycle
LXMG1611-01
Min
Typ
Max
6.3
7.0
0.14
1500
52
-10
57
-12
2.5
0
1800
62
-14
2.6
0
V
IN
0.8
7.7
Units
I
L(MAX)
I
L(MIN)
V
LS
f
O
I
BRT
V
C
V
C
V
SLEEP (HI)
V
SLEEP (LO)
mA
RMS
mA
RMS
V
RMS
kHz
µA
DC
V
DC
V
DC
V
DC
V
DC
SLEEP INPUT
RUN Mode
SLEEP Mode
2.2
-0.3
P
ACKAGE
D
ATA
P
ACKAGE
D
ATA
I
SLEEP
Input Current
SLEEP = 5V
V
SYNC(-)
/ V
SYNC(+)
CHARACTERISTICS
Logic High Level
V
SYNCH(HI)
4.0
Logic Low Level
V
SYNCH(LO)
-0.3
Input Impedance
Z
IN
60
Pulse Width (Note 3)
t
PW
25
Input Frequency
f
SYNC
49
POWER CHARACTERISTICS
Sleep Current
I
IN(MIN)
V
IN
= 15V
DC
,
SLEEP
< 0.8V
Note: 2. Minimum lamp current required to maintain even light output may vary with display panel.
3. The module will be functional with pulse widths much larger than 250µs, but will have limited dimming.
