856-15712 Overview

imcv-medialinx, TX/FX-mm850-SC

856-15712 Parametric

Parameter Name	Attribute value
Datasheets
iMcV-MidaLinX Series
Product Photos
856-157xy Series
Standard Package	1
Category	Networking Solutions
Family	Miscellaneous

Preview

Download Datasheet

View All

iMcV-MediaLinX Series

10/100/1000 Mbps and

Standard and Extended Temperature (IE)

10/100 Ethernet SNMP-Manageable, Switching Media Converters

The MediaLinX series offers the most flexible Ethernet switching

media converters in the industry.

Features and Benefits

Same unit converts speed, media and

duplex mode!

• Available in 10/100 Mbps and

10/100/1000 Mbps models

• IE-iMcV-MediaLinX supports SFP (LC)

transceivers and extended operating

temperatures

• Configure twisted pair port for Auto

Negotiation or force the speed

• Twisted pair and fiber ports can be

individually configured for Half- or

Full-Duplex operation

Easy to configure and manage with

GUI-based iView²

witching

• Up and running in less than 5 minutes

• Easily adjust settings when user

requirements change

• Easy upgrades; no user intervention or

visits to remote locations required

• Monitor and control all connections

* SFPs sold separately

Dissimilar media types, protocols and duplex settings can

make LAN internetworking and Fiber-to-the-Subscriber projects

challenging undertakings. For example, if the service provider’s

network infrastructure is 100 Mbps or Gigabit fiber, but the

customer wants to receive a standard 10 Mbps Ethernet interface

to their LAN; making the connection between the two network

segments can be difficult. The complexity of today's mixed

media networks and the increasing demand for bandwidth

requires access equipment that is both flexible in connecting

different media types and scalable between different speeds.

Convert speed, media and duplex mode:

The iMcV-MediaLinX series of switching media converters

offers service providers and enterprise networks unparalleled

flexibility in connecting copper-based networks to Fast Ethernet

or Gigabit fiber optic infrastructures. The SNMP-manageable

iMcV-MediaLinX converters allow device managers to use Auto

Negotiation functionality on the twisted pair port for plug-and-

play operation, or to manually configure the port for the desired

speed and duplex mode. What's more, you can even set the

fiber port for Half- or Full-Duplex operation (10/100 Mbps only).

The iMcV-MediaLinX series includes three models:

The iMcV-MediaLinX supports Config Control, a feature that

retains the latest configuration on the module regardless of how

the initial configuration was setup; whether through DIP Switch

settings or the SNMP Management Module’s configuration. This

feature is beneficial when 1) changing the settings of a currently

installed iMcV-Module through iView², 2) replacing the same

type of iMcV-Module, or 3) installing a new or different type of

iMcV-Module.

The iMcV-MediaLinX series also includes troubleshooting

features and LEDs to assist in network diagnostics as well

as make isolating cable breaks easier should they occur. In

addition, hot-swappable iMcV-MediaLinX modules significantly

reduce operating costs by allowing other modules within

the same chassis to remain up and running during product

upgrades, maintenance and troubleshooting.

Meets a variety of installation

requirements

• Available for multi-mode, single-mode

and CWDM fiber

• Available with single-strand fiber

• LinkLoss, FiberAlert, SNMP management

and LEDs assist in diagnosing problems

on fiber optic networks

• Features Link Fault Pass-Through (LFPT),

a troubleshooting feature that monitors

the copper and fiber ports of the unit;

if a port loses LINK, the unit disables the

transmitting signal on the other port

(Pass-Through) and notifies the user via LED

• Supports

Config Control,

a feature that

retains the latest configuration on a

module regardless of how the initial

configuration was setup; whether by DIP

Switch or SNMP Management Module

(available on iMcV-MediaLinX)*

Eases Troubleshooting

* iView² v.1.8.9 and SNMP firmware v. C4 must

be installed to use the Config Control feature.

www.imcnetworks.com

800-624-1070

Making Your Net

Work

Better — Since 1988

RoHS Compliant
