Product Data Sheet
SATCOM / "1 ppm Forever"
Temperature Compensated Crystal Oscillators
Features
Frequency from 0.5 MHz to 160 MHz
Stability to
±
0.05 ppm 0 to 50˚C
+5Vdc to +24Vdc supply voltage options
Sinewave, HCMOS, TTL options
Over 500,000 units produced
Applications
SATCOM
Base Stations and Picocells
LMDS, WLL, SONET, Stratum 3
Description
The SATCOM and "1 ppm Forever" series of
Temperature Compensated Crystal Oscillators
(TCXO's) are available in frequencies from
0.5 MHz to 160 MHz.
These series offer performance for short term
stability, phase noise, G sensitivity, aging and
temperature stability normally only associated
with Oven Controlled Crystal Oscillators
(OCXO's), while consuming typically < 20 mA.
With over 500,000 units produced,
Vec-
tron International has more experience with this
type of TCXO then the rest of the industry
combined.
1
SATCOM / "1 ppm Forever" TCXO
Performance Characteristics
Parameter
Output Options:
AC
= ACMOS
HC
= HCMOS
Characteristics
0.5 to 160 MHz
0.5 to 160 MHz
TD
= 10 TTL
0.5 to 160 MHz
RG
= 0 dBm 50 ohm
3.0 to 30 MHz
RC
= +7.0 dBm 50 ohm 3.0 to 90 MHz
Stability Options:
(Other stability
options are available)
A58
=
±
0.05 ppm
B17
=
±
0.1 ppm
CB7
=
±
0.25 ppm
D57
=
±
0.5 ppm
E16
=
±
1.0 ppm
AC
= +12 Vdc
±
5%
HC
= +12 Vdc
±
5%
TD
= +12 Vdc
±
5%
RG
= +5 Vdc
±
5%
RC
= +12 Vdc
±
5%
Allan Variance
(typical):
Aging:
±
1 x 10-10 at tau = 1 sec
"1 ppm Forever"
SATCOM
-110 dBc / Hz
-135 dBc / Hz
-150 dBc / Hz
-155 dbc / Hz
Typical P/N
(SATCOM)
("1 ppm Forever")
< 0.2 ppm / 1st year
< 0.7 ppm / 10 years
< 0.5 ppm / 1st year
< 2.0 ppm / 10 years
Phase Noise
(typical):
10 MHz, RC option
@ 10 Hz offset
@ 100 Hz offset
@ 1 kHz offset
@ 100 kHz offset
0˚C to +50˚C
0˚C to +70˚C
-20˚C to +70˚C
-40˚C to +85˚C
-55˚C to +85˚C
Supply Voltage:
(Other voltage
options are available)
RCR7HYA58C 10.00 MHz
RGR5HXA37C 15.00 MHz
HY is predetermined, HX is for "1 ppm Forever" max temp range -20 to +70
Note:
Not all stabilities are available with all options. Vectron International does not recommend wave
soldering, IR reflow or other elevated temperature processing without consulting the factory.
For AC, HC and TD outputs with frequencies above 30 MHz a low phase noise PLL multiplier
will
be used.
Please inform the factory of your phase noise requirements.
