LED Module
Rev. No
1.2
Page
1 / 11
Data Sheet
Linear Module, M-series
Model Name LT-M562A, M562B, M562C
Type
560x18x5.8[mm]
Model
3000 K
M562A
SI-B8V111560WW
SI-B8U111560WW
SI-B8T111560WW
SI-B8R111560WW
M562B
SI-B8V151560WW
SI-B8U151560WW
SI-B8T151560WW
SI-B8R151560WW
M562C
SI-B8V171560WW
SI-B8U171560WW
SI-B8T171560WW
SI-B8R171560WW
Parts No.
3500 K
4000 K
5000 K
SAMSUNG ELECTRONICS CO,.LTD.
SAN #24 NONGSEO-DONG, GIHEUNG-GU,
YONGIN-SI, GYEONGGI-DO, 446-711, KOREA
LT-M562A, M562B, M562C
Date of Issue : June 2014
LED Module
1. Products and Application
Rev. No
1.2
Page
3 / 11
This specification defines general specification and performance for LED Linear module.
Samsung Linear Modules target to replace conventional fluorescent lamps as T5, T8 and so on
with LED solutions. Due to transferring LED, new luminaire transferred to LED can take more
energy saving and longer life-time.
In special, Samsung has competitiveness in middle-power solutions. This module uses
LM561B. Middle power solutions provide more homogeneous and higher efficient lights. Linear
module has been designed to expand length simply and adopt easy connection way.
This M-series have 3 product types which are M562A, M562B and M562C. Depending on
luminaire target performance, module can be selected.
2. Specification
No.
2-1
2-2
Item
Dimension
Weight
Specifications
560.0(L) × 18.0(W) × 5.8(h) mm
27.5(g) for M562A/M562B
28.5(g) for M562C
Unit
Remark
mm Tolerance:±0.4mm
g
Tolerance:±1.4g
2-3
Rated lifetime
> 50,000
L70B50
@Tc = 70℃ (M562A)
hour
Tc = 80℃
(M562B, M562C)
-
℃
℃
-
-
-
2-4
2-5
2-6
Ingress Protection
Operating Temperature
Storage Temperature
N/A
Ta = - 20 ~ 70
Ta = - 35 ~ 85
LT-M562A, M562B, M562C
Date of Issue : June 2014
LED Module
2-3. M562C
No.
Item
Specifications
Sym.
Model
3000K
3-1
Luminous flux
Φ
v
3500K
4000K
5000K
3000K
3-2
Efficiency
LPW
3500K
4000K
5000K
3000K
3-3
CCT
-
3500K
4000K
5000K
3-4
3-5
3-6
Operating Current
Operating Voltage
Power Consumption
Iop
Vdc
-
-
-
-
Min.
1986
2019
2087
2154
-
-
-
-
2901
3322
3810
4850
-
-
-
Nom.
2350
2390
2460
2530
140
142
146
151
2991
3437
3961
5099
700
24.0
16.8
Max.
2455
2497
2581
2663
-
-
-
-
3085
3562
4120
5389
900
-
-
mA
V
W
K
lm
Unit
Rev. No
1.2
Page
5 / 11
Remark
@700mA,Tp = 50
℃
lm/W
@700mA,Tp = 50
℃
@700mA,Tp = 50
℃
-
@700mA,Tp = 50
℃
@700mA,Tp = 50
℃
2-4. Common
No.
4-1
4-2
SDCM
Item
Specifications
Sym. Model
-
CRI
-
-
Min.
-
80
Nom.
3
-
Max.
-
-
Unit
step
Ra
Remark
MacAdam
@ initial time
-
Color Rendering Index
※
Measurement tolerance of luminous flux becomes ± 7%
in the
value,
measurement tolerance of Vf becomes
±
0.3V in the value
and the measurement tolerance of the color coordinates is ± 0.005.
LT-M562A, M562B, M562C
Date of Issue : June 2014
