P1TX6A-SX51-01M
Product Specification Sheet
ORIGINATOR:
B. Peters
DATE:
8/7/09
D
PNSPO!
P1TX6A-SX51-01M Product Specification Sheet
DOCUMENT NO.
DOC000924
SHEET
1
OF
10
CONFIDENTIAL INFORMATION
PNSPO
1.0
Description
O
MRON
N
ETWORK
P
RODUCTS
®
The P1TX6-SX51-01M (TX-SX51) is an optical module
that transmits an HDMI™ signal on one strand of
multimode fiber. The TX-SX51 incorporates a bi-
directional optical subassembly (OSA) to convert and
transmit an uncompressed electrical HDMI™ video
signal, along with the HDCP/EDID/CEC functionality,
over distances of up to 1000m.
2.0
•
•
•
•
•
•
Features
5 transmit lanes and 1 receive lane over 1 multimode fiber
Compatible with HDMI™ compliant sources and sinks
Scalable to HDMI™ 1.3a 16-bit color
On-board hardware and firmware for HDCP/EDID/CEC functionality
Accepts TMDS inputs directly into its 40 pin plug-down connector
Automatic laser disable upon fiber disconnect
This device is
EXTREMELY SENSITIVE
to Electrostatic Discharge (ESD). At a minimum, all handling must be
performed in accordance with an ANSI-compliant ESD Control Program (ANSI/ESD S20.20-2007) to mitigate
possible ESD-induced damage. Reliability and life of the device will be adversely affected if these precautions are
not met.
This device is a Class 3R Laser device (per IEC 60825-1:2007) and can cause damage to eye sight if used improperly. Refer to ANSI
Z136 for proper handling and usage of Class 3R devices.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
ORIGINATOR:
B. Peters
DATE:
8/7/09
D
PNSPO!
P1TX6A-SX51-01M Product Specification Sheet
DOCUMENT NO.
DOC000924
SHEET
2
OF
10
CONFIDENTIAL INFORMATION
PNSPO
3.0
Parameter
O
MRON
N
ETWORK
P
RODUCTS
®
Absolute Maximum Ratings
Symbol
Tst
VCC1
VCC2
Ta
RH
Min
-40
-0.3
-0.5
0
Typ
Max
85
3.6
6
65
80
Units
°C
V
V
°C
%
cycles
cycles
Storage Temperature
1, 3
3.3V Supply Voltage
5.0V Supply Voltage
Operating Surface Temperature
2
Operating Humidity
3
Durability – SC Connector
Durability – Plug-down Connector
200
50
4.0
Optical Characteristics – High-speed Lanes
Parameter (per lane)
Average Optical Power, per Lane
4
Optical Modulation Amplitude
Center Wavelength – Lane 0
Center Wavelength – Lane 1
Center Wavelength – Lane 2
Center Wavelength – Lane 3
Symbol
Pout
Min
-3.0
-6.25
Typ
0.0
778
800
825
850
Max
Units
dBm
dBm
nm
nm
nm
nm
Stresses listed may be applied without causing damage. Functionality at or above the values listed is not implied. Exposure to these
values for extended periods may affect reliability.
2
See outline drawing for measurement point.
3
Non condensing, 80% RH.
4
I= 5mA, T=25C.
1
ORIGINATOR:
B. Peters
DATE:
8/7/09
D
PNSPO!
P1TX6A-SX51-01M Product Specification Sheet
DOCUMENT NO.
DOC000924
SHEET
3
OF
10
CONFIDENTIAL INFORMATION
PNSPO
5.0
Parameter
5
O
MRON
N
ETWORK
P
RODUCTS
®
Electrical Specifications – High-speed Lanes
Symbol
Min
Typ
Max
1.65
3.50
T
J1
320
160
0.85
2.6
VCC1
ICC1
VCC2
ICC2
4.75
5
3.15
3.30
3.45
235
5.25
35
10
100
2000
1000
VCC
Units
Gb/s
ps
ohm
mVp-p
mVp-p
V
V
V
mA
V
mA
Data Rate per Lane
P1TX6-SX51V-01M
P1TX6-SX51D-01M
Total Jitter (RMS), per lane
6
Input Differential Impedance
Differential Input Voltage
7
Single-ended Input Voltage
Common mode input voltage
(AC-coupled input)
Operating 3.3V Supply Voltage
Operating 3.3V Supply Current
Operating 5.0V Supply Voltage
Operating 5.0V Supply Current
6.0
Optical Characteristics – Low-speed Lanes
Laser Parameter
Wavelength - Lane 4
Data Rate
Average Optical Power
Pavg
Symbol
Min
Typ
911
5
-0.5
Max
Units
nm
Mb/s
dBm
Photodiode Parameter
Wavelength - Lane 5
Data Rate
Maximum Optical Input Power
Symbol
Min
Typ
980
5
Max
Units
nm
Mb/s
Pin
8
dBm
5
6
Measured with input signals conforming to HDMI™ rev 1.3a, section 4.2.4, figure 4-18.
Based on a jitter-free source
7
Differential CML compatible inputs
ORIGINATOR:
B. Peters
DATE:
8/7/09
D
PNSPO!
P1TX6A-SX51-01M Product Specification Sheet
DOCUMENT NO.
DOC000924
SHEET
4
OF
10
CONFIDENTIAL INFORMATION
PNSPO
7.0
Hot Plug Detect High
Hot Plug Detect Low
O
MRON
N
ETWORK
P
RODUCTS
®
HDMI™ Signal Parameters
HDMI™ Signal Parameter
8
Symbol
HDMI™ Input Signal – SCL
IH
,SDA
IH
HDMI™ Input Signal – SCL
IL
,SDA
IL
V
IH
V
IL
HPD
H
HPD
L
V
CEC0
V
CEC1
V
CECT0
V
CECT1
t
CECRise
t
CECFall
Min
3.5
-0.5
2.4
0
0
2.5
0.0
2.0
Typ
Max
5.75
1.5
5.3
0.4
0.6
3.63
0.8
3.63
250
50
Units
V
V
V
V
V
V
V
V
μs
μs
CEC
9
Output Voltage Logic ‘0’
CEC Output Voltage Logic ‘1’
High to Low Input Voltage Threshold
Logic ‘0’
Low to High Input Voltage Threshold
Logic ‘1’
CEC Rise Time (10% to 90%)
CEC Fall Time
8.0
Source
Cable
X
C
C
C
C
D
Status Signal Functional Table
10
Condition
Source
Status
X
ON
OFF
X
X
X
X
D
C
T
0
1
Sink
Cable
X
C
C
D
C
X
Sink
Status
X
ON
ON
X
OFF
X
Optical
Cable
D
C
C
C
C
C
SS 1
T
0
0
0
0
0
Status Signal Pin Output
SS 2
0
0
0
0
0
1
SS 3
0
0
0
1
1
1
SS 4
0
0
1
1
1
1
Does Not Affect Output
Disconnected
Connected
Toggles Between 0 and 1 at ~ 10Hz
0 Volts
5 Volts
Reference I
2
C-Bus Specification v2 and HDMI™ rev 1.3a. Supports up to 100kHz bus speed.
9
The firmware version installed in the module must be version 2.10.06 or higher for CEC functionality. Update to version 2.10.06 or
higher if the current version is not at this revision level. Refer to P1_X6-SX51-01M Bootloader Manual for updating details.
10
Status signal table represents typical output. Variances in status signals may occur between different manufacturers and/or models
of sources and sinks.
8
ORIGINATOR:
B. Peters
DATE:
8/7/09
D
PNSPO!
P1TX6A-SX51-01M Product Specification Sheet
DOCUMENT NO.
DOC000924
SHEET
5
OF
10
CONFIDENTIAL INFORMATION
