19-137/R6GHBHC-A01/2T datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> 19-137/R6GHBHC-A01/2T

19-137/R6GHBHC-A01/2T: Descriptionled red/green/blu water clr 0603; CategoryLED optoelectronic/LED photoelectric; File Size390KB，13 Pages; ManufacturerEVERLIGHT; Websitehttp://www.everlight.com/; Environmental Compliance

Download Datasheet Parametric View All

19-137/R6GHBHC-A01/2T Overview

led red/green/blu water clr 0603

19-137/R6GHBHC-A01/2T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT, SMD, 4 PIN
Reach Compliance Code	compli
Is Samacsys	N
color	BRILLIANT RED/BRILLIANT GREEN/BLUE
color@wavelength	Blue/Bl-Gr/Or-Red
Configuration	COMMON ANODE, 3 ELEMENTS WITH BUILT-IN ZENER DIODE
Maximum forward current	0.025 A
Maximum forward voltage	2.4 V
Lens type	WATER CLEAR
minimum luminous intensity	120 cd
Nominal luminous intensity	100.0/180.0/50.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	4
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	TRIPLE COLOR LED
total height	0.5 mm
method of packing	TAPE AND REEL 7"
peak wavelength	632/518/468 nm
Maximum reverse voltage	5 V
shape	SQUARE
size	1.6 mm
surface mount	YES
Terminal pitch	1.6 mm
perspective	120 deg
Base Number Matches	1

Preview

Download Datasheet

View All

SMD



19-137/R6GHBHC-A01/2T

Features

․

Package in 8mm tape on 7〞diameter reel.

․

Compatible with automatic placement equipment.

․

Compatible with infrared and vapor phase reflow solder process.

․

Multi-color type.

․

Pb-free.

․

ESD protection

․

The product itself will remain within RoHS compliant version.

Description

․

The 19-137 SMD LED is much smaller than lead frame type components, thus enable smaller board

size, higher packing density, reduced storage space and finally smaller equipment to be obtained.

․

Besides, lightweight makes them ideal for miniature applications. etc.

Applications

․

Backlighting in dashboard and switch.

․

Telecommunication: indicator and backlighting in telephone and fax.

․

Flat backlight for LCD, switch and symbol.

․

General use.

Rev.3

www.everlight.com
