VICOR CONFIDENTIAL
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
7
6
5
4
3
2
1
REV.
1
2
2
3
4
5
6
DESCRIPTION
RELEASED PER E110692
REVISED PER E111132
REVISED PER E111265
REVISED PER E120225a
REVISED PER E131784a
REVISED PER E140404
ZMB
KUK
KUK
KUK
REJH
DATE
07/07/11
11/16/11
12/20/11
03/16/12
12/20/13
APPROVED
NZ
MH
SG
MH
MH
MH
F
F
REW 03/24/2014
1
37052-601
4
11 TURNS
20 AWG SINGLE
BUILD WIRE
3
.66 MAX
16.77 MAX
1
11 TURNS
20 AWG SINGLE
BUILD WIRE
EPOXY
E
E
2
2
D
.32
.26
8.13
6.60
.100
.039
2.54
1.00
MOUNTING PLANE
D
.50
.45
12.70
11.43
STRIP AND TIN WITH
TIN/SILVER SOLDER
4 PLACES
C
.409
10.39
.130
3.30
.260
6.60
C
.0339(4) TYP
.861
.409 Nom.
10.39
.260
6.60
B
.130
3.30
B
NOTES:
1.
2.
3.
4.
CORE: VICOR P/N 37081.
MAGNET WIRE: NEMA MW28C SINGLE BUILD.
ASSEMBLY TO BE FREE OF NICKS.
RoHS COMPLIANT, LEAD FREE PER CST-0001 LATEST REVISION.
DRAWN BY
DATE
10/12/2010
VAC= 100mV RMS
318µH MIN
455µH NOM
592µH MAX
IND. µH PER
WINDING @10KHz
6
Anuyugh
Ragipani
VICOR
SWD
3
A
1 PRIMARY
1 SECONDARY
WINDING
7
11
11
# OF TURNS
20
20
AWG
10A
7.9 mR
7.9mR
DC RES.
MAX
5
f= 10 KHz
f= 10KHz
TEST CONDITION
4
3
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE : INCH / [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
IND COM MODE 600uH 30% 10A
SIZE
37052-601
Vicor P/N
8
2
ITEM NO.
10A
RATED I
A
C
2
CAGE CODE
DWG NO
REV
67131
37052-XXX
SHEET 1 OF 1
6
1
DO NOT SCALE DRAWING
SCALE 5:1
