PJ1082
10 Amp Low Dropout Positive Voltage Regulator
T
he PJ1082 Series of high performance positive voltage
regulators are designed for applications requiring low
dropout
performance
at full rated
current,
TO-220
Additionally, the PJ1082 Series provide excellent regulation
over variations due to changes in line, load and temperature.
Outstanding features include low dropout performance at
rated current, fast transient response, internal current limiting
and thermal shutdown protection of the output device. The
PJ1082 Series are three terminal regulators with fixedand
adjustable voltage options available in popular packages.
Pin: 1.Adj (com)
2.Out
3.In
FEATURES
•
Low dropout voltage 1.3V max.
Full current rating over line and temperature
•
•
Fast transient response
Total output regulation
±2%
over line, load and
temperature
•
•
•
•
•
Adjust pin current max 120
µ
A over temperature
Line regulation typical 0.015%.
Load regulation typical 0.05%.
Fixed/adjustable output voltage
TO-220 package
ORDERING INFORMATION
Device
Operating Temperature
(Ambient)
PJ1082CZ
PJ1082CZ-2.5
-20℃ to +85℃
TO-220
PJ1082CZ-3.3
NOTE: Contact factory for additional voltage option.
BLOCK DIAGRAM
Package
ABSOLUTE MAXIMIUM RATING
ABSOLUTE MAXIMUM RATING
Parameter
Input Voltage
Power Dissipation
Thermal Resistance Junction to Case
Thermal Resistance Junction to Ambient
Operating Junction Temperature Range
Operating Ambient Temperature Range
Storage Temperature Range
Lead Temperature (Soldering) 10 Sec.
Symbol
V
IN
P
D
θ
JC
θ
JA
T
J
T
A
T
STG
T
LEAD
Maximum
7
Internally Limited
1.6
50
0 to +125
-20 to +85
-25 to 150
260
Units
V
W
º
C
/W
º
C
1-6
2002.rev.A
PJ1082
10 Amp Low Dropout Positive Voltage Regulator
ELECTRICAL CHARACTERISTICS
Unless otherwise specified, Adjust V
IN
= 2.75V to 7V and Adjust Io = 10mA to 10A
Fixed V
IN
= 4.75V to 7V and Fixed Io = 10mA to 10A
Parameter
Output Voltage
(1)
Fixed Voltage
Reference Voltage
(1)
Adj Voltage
Line Regulation
(1)
(Vin-Vout=3V)
Load Regulation
(1)
(Vin-Vout=3V)
Dropout Voltage
ΔV
REF
=1%
Current Limit
(Vin-Vout =5V)
Quiescent Current
Fixed Model
Temperature Coefficient
Adjust Pin Current
I
Q
Tc
I
ADJ
25
5V
Ic
L
Over Temp.
12
0.005
55
120
Adjust Pin Current Change
Temperature Stability
Minimum Load Current
Adjust Model
RMS Output Noise
(2)
Ripple Rejection Ratio
(3)
I
ADJ
Ts
Io
V
N
R
A
5V
9.5A
5V
5V
25
Over Temp.
60
500mA Over Temp.
0.2
0.5
5
0.003
72
10
5
%
mA
%Vo
dB
µ
A
Symbol
Vo
Test Conditions
V
IN
-V
OUT
5V
I
O
10mA
T
J(4)
25
Over Temp.
Min
0.99|Vo|
0.98|Vo|
1.238
1.225
Test Limits
Typ
Vo
Max
1.01|Vo|
1.02|Vo|
1.250
1.262
1.275
0.015
0.035
0.05
0.2
1
1.1
9.5
10.5
1.3
0.3
0.4
0.2
Units
V
REF
5V
10mA
25
Over Temp.
V
REG
(LINE)
10mA
25
Over Temp.
REG
(LOAD)
25
Over Temp.
%
V
D
25
V
A
14
mA
%/
º
C
(1)Low duty cycle pulse testing with Kelvin connections required.
(2)Bandwidth of 10Hz to 10KHz.
(3)120Hz input ripple (C
ADJ
for ADJ) =25
µ
F .
(4)Over Temp.-over specified operating junction temperature range.
2-6
2002.rev.A
PJ1082
10 Amp Low Dropout Positive Voltage Regulator
Typical Application Circuit
(1) C1 NEEDED IF DEVICE IS FAR FROM FILTER CAPACITORS
(2) C2 REQUIRED FOR STABILITY
(3) C1 NEEDED IF DEVICE IS FAR FROM FILTER CAPACITORS
(4) C2 REQUIRED FOR STABILITY
3-6
2002.rev.A
