SEATING PLANE
E
4
1
.945 MAX
LEAD LENGTH
.20- .40
2 PLCS
STRIP & TIN
TO SEATING PLANE
MIN
7
5
E
.450±.050
D
D
.980
MAX
2
.50±.05
C
3
4
IF APPLICABLE
.450
MAX
3
C
IF APPLICABLE
STRIP & TIN
.150 MAX
BEYOND SEATING PLANE
B
NOTES:
1. ASSEMBLY TO BE FREE OF NICKS.
2. WINDINGS TO BE EVENLY SPACED.
3. RoHS COMPLIANT, LEAD FREE PER CST-0001 LATEST REVISION.
4. GENERAL WORKMANSHIP STANDARDS FOR MAGNETIC COMPONENTS PER WS-0002.
5. DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.
6. BOND THE MOUNT ITEM 3 IF APPLICABLE TO INDUCTOR LEADS (2 POSITIONS) USING EPOXY ITEM 7.
TEST
REF VICOR P/N 29764
REF VICOR P/N 33206
DRAWN
P.E.IENI
MATERIAL
B
DATE
11/04/05
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE INCH [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
ASSY DWG
IND TOR .98 DIA 1W
SIZE
CAGE CODE
DWG NO
REV
A
1 KHz @
10 mV
2
ITEM
NO.
PRI
WINDING
20
NO. OF TURNS
14.7-
22.1
IND.(uH)
8
MAX
DC RES
(mΩ)
FINISH
B
DO NOT SCALE DRAWING
67131
2
32065
SHEET 1 OF 1
5
1
A
SCALE 4 : 1
8
7
6
`
5
4
