8
VICOR CONFIDENTIAL
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
7
6
5
4
3
2
1
REV.
4
<>
#4-40 UNC-2B COLD FORM TAP
.140 DP MIN. FROM FAR SIDE
DO NOT BREAK THRU
(6) PL.
5
6
7
DESCRIPTION
RELEASED PER E090033
REVISED PER E091548
REDRAWN PER E100871
REVISED PER E111266
AR
JS
DCS
VSS
DATE
01/09/09
11/16/09
06/23/10
12/22/11
APPROVED
REJH
REJH
KUK
REJH
F
F
E
E
2.22
<>
2.000
<>
D
D
.11
<>
.650
<>
.49
<>
1.300
<>
2.280
.910
C
C
.90
<>
.190
B
<>
.005
.010
MAT'L TO BE
REMOVED
B
.100
A
NOTES:
1. MATERIAL: EXTRUSION SEE SHEET 2 OF 2
2. REMOVE ALL BURRS AND SHARP EDGES.
<>3. CLEAR FINISH, RoHS COMPLAINT PER CST-0001, LATEST REVISION PER
A)CHROMIUM FREE, OR
B)TRIVALENT CHROMIUM IN ACCORDANCE WITH MIL-DTL-5541, TYPE II, CLASSS 1A OR 3.
SEE CST-0003 FOR TYPES OF AVAILABLE FINISHES.
4. "<>" DENOTES CRITICAL CHARATERISTIC FOR LOT INSPECTION.
5. DIMENSIONS ARE INCHES ONLY.
DRAWN BY
David Schmidt
DATE
06/23/2010
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE : INCH / [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HTSNK, "B" X-FLOW, .9H, LOW
FLOW, THREADED
SIZE
A
C
2
CAGE CODE
DWG NO
REV
67131
30269
SHEET 1 OF 2
7
1
DO NOT SCALE DRAWING
SCALE 2:1
8
7
6
5
4
3
8
VICOR CONFIDENTIAL
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
7
6
5
4
3
2
1
REV.
DESCRIPTION
SEE SHEET 1 OF 2
DATE
APPROVED
F
F
3.00°
1.5 EACH
SIDE OF VERT
E
1.756
R.035
(16) PL.
E
SEE DETAIL
A
R.018
(2) PL.
.024
.034
D
.035
.040
.910
R.035
.080
(14) PL.
D
.200
.110
.215
R.030
(33) PL.
.748
C
C
R.010
(2) PL.
* .227
(3) PL.
* .223
(4) PL.
+.020
2.280
- .000
* .084
(6) PL.
.017
(2) PL.
C
L
.187
B
B
PROFILE COMMON
FOR
30270
30724
30269
30725
NOTES:
1.
MATL: ALUMINUM 6063-T5
2.
* DENOTES DIMENSION TO THEORETICAL SHARP CORNER.
3.
ALL DIMENSIONS ARE CRITICAL CHARACTERISTICS.
4.
RoHS COMPLIANT PER CST-0001 LATEST REVISION.
5.
WORKMANSHIP STANDARDS WS-0004, WS-0006 AND WS-0007 APPLY TO THIS PART.
6.
DIMENSIONS ARE INCHES ONLY.
DETAIL A
SCALE 8 : 1
* .084
DRAWN BY
David Schmidt
DATE
06/23/2010
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE : INCH / [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
A
HTSNK, "B" X-FLOW, .9H, LOW
FLOW, THREADED
SIZE
A
C
2
CAGE CODE
DWG NO
REV
67131
30269
SHEET 2 OF 2
7
1
DO NOT SCALE DRAWING
SCALE 2:1
8
7
6
5
4
3
