2.40
FULL R
DESCRIPTION
RELEASED PER E050350
REVISED PER E100841
REVISED PER E141402
INTL
LEK
KUK
SJW
DATE
11/16/05
06/22/10
12/18/14
APVD
EF
GCK
TO
F
F
.15
2.100
R.015 MAX TYP
FULL R
E
E
.078
TYP
D
3.600
D
4.60
.330
.156 TYP
SEE NOTE 4
1.800
6 FINS EO SP @
1.47 X 2PL
C
C
.330 TYP
.50
.34 TYP
.125±.010
B
.06 TYP
.90
0.005 CONVEX
B
FREE CONVECTION
200 LFM
600 LFM
2.4
1.52
0.72
A
NOTES:
1. MATERIAL: 6063-T5 ALUMINUM.
2. REMOVE ALL LOOSE AND HANGING BURRS,
OTHERWISE, BURRS SHALL NOT EXCEED .003.
3. CLEAR FINISH, RoHS COMPLIANT, CHROMIUM FREE PER
CST-0001, LATEST REVISION.
4. PERMANENTLY MARK PART NUMBER LEGIBLY IN AREA SHOWN.
5. DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.
6. TOLERANCE ON ALL DIMENSIONS SHOWN AS REFERENCE SHALL FOLLOW
STANDARD ALUMINUM ASSOCIATION TOLERANCE.
8
7
6
5
4
3
DRAWN BY
L. KNIGHT
DATE
05/19/05
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE : INCH / [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HEATSINK
0.9" HGT VERT.
SIZE
A
REV
C
2
CAGE CODE
DWG NO
67131
30090
SHEET 1 OF 1
3
1
DO NOT SCALE DRAWING
SCALE 2:1
