SPRING RATE = 1.6 N/MM [9 LB/IN]
2
19.94
.785
REF
C
B
B
DRAWN
R.E.J.HICKEY
MATERIAL
DATE
03/14/07
VICOR
SWD
A
NOTES:
1. FOR A LIST OF PARTS SEE BOM NO. 33625
2. ITEM 1 IS GRAY.
3. RoHS COMPLIANT PER CST-0001 LATEST REVISION.
8
7
6
5
4
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE MM [INCH]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
ASSY DWG GRAY PIN
VIC JLEAD PUSH PIN (19.9 MM)
SIZE
CAGE CODE
DWG NO
REV
A
FINISH
C
DO NOT SCALE DRAWING
67131
33630
SHEET 1 OF 1
2
1
SCALE 10 : 1
