3 Watts
IP Series
•
•
•
•
•
•
•
Wide 4:1 Input Range
SIP Package
1600 VDC Isolation
40 °C to 85 °C Operation
Remote On/Off
3 Year Warranty
DC DC
xppower.com
Regulated Single & Dual Output
Specification
Input
Input Voltage Range
Input Reflected
Ripple Current
Input Filter
Input Surge
• See table
• 20 mA pk-pk through 12 µH inductor and
47 µF capacitor, 5 Hz to 20 MHz
• Capacitor
• 12 V models: 25 VDC for 100 ms
24 V models: 50 VDC for 100 ms
48 V models: 100 VDC for 100 ms
Input
Voltage
Output
Voltage
3.3 V
5.0 V
12.0 V
4.5-18.0 V
15.0 V
±5.0 V
±12.0 V
±15.0 V
3.3 V
5.0 V
12.0 V
9.0-36.0 V
15.0 V
±5.0 V
±12.0 V
±15.0 V
3.3 V
5.0 V
12.0 V
18.0-75.0 V
15.0 V
±5.0 V
±12.0 V
±15.0 V
Output
Current
700 mA
600 mA
250 mA
200 mA
±300 mA
±125 mA
±100 mA
700 mA
600 mA
250 mA
200 mA
±300 mA
±125 mA
±100 mA
700 mA
600 mA
250 mA
200 mA
±300 mA
±125 mA
±100 mA
No Load
Input
Current
40 mA
40 mA
40 mA
40 mA
40 mA
40 mA
40 mA
25 mA
25 mA
25 mA
25 mA
25 mA
25 mA
25 mA
15 mA
15 mA
15 mA
15 mA
15 mA
15 mA
15 mA
Max
Capacitive
Load
1760 µF
1000 µF
170 µF
110 µF
±470 µF
±100 µF
±47 µF
1760 µF
1000 µF
170 µF
110 µF
±470 µF
±100 µF
±47 µF
1760 µF
1000 µF
170 µF
110 µF
±470 µF
±100 µF
±47 µF
Efficiency
72%
77%
81%
81%
77%
80%
80%
75%
79%
82%
82%
79%
79%
80%
74%
78%
80%
81%
79%
79%
79%
Model
Number
IP1203SA
IP1205SA
IP1212SA
IP1215SA
IP1205S
IP1212S
IP1215S
IP2403SA
IP2405SA
IP2412SA
IP2415SA
IP2405S
IP2412S
IP2415S
IP4803SA
IP4805SA
IP4812SA
IP4815SA
IP4805S
IP4812S
IP4815S
Output
Output Voltage
•
Minimum Load
•
Line Regulation
•
Load Regulation
•
Setpoint Accuracy
•
Ripple & Noise
•
Temperature Coefficient
•
Short Circuit Protection
•
Cross Regulation
•
Remote On/Off
•
See table
None
(1)
±0.2% max
±1.0% max for a 10-100% load change
(1)
±1% max
30 mV pk-pk max, 20 MHz bandwidth
0.02%/°C
Continuous with auto recovery (foldback)
±5% on dual output models
(2)
Apply 2 to 4 mA to pin 3 to turn off output
General
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
•
•
•
•
•
•
See table
1600 VDC
10
9
Ω
200 pF
100-600 kHz variable
>1.7 MHrs to MIL-HDBK-217F at 25 °C, GB
Mechanical Details
0.86 (21.85)
Printed Face
0.42
(10.60)
1
2
3
5
6
7 8
0.12
(3.05)
0.44
(11.10)
0.36 (9.20)
Environmental
Operating Temperature
• -40 °C to +85 °C, derate from 100% load at
70 °C to 30% load at 85 °C
Storage Temperature
• -40 °C to +125 °C
Case Temperature
• 100 °C max
Cooling
• Convection cooled
0.02
(0.50)
0.10
(2.54)
0.70 (17.78)
0.02 (0.50)
0.36
(9.20)
0.01
(0.25)
0.14
(3.50)
0.02
(0.50)
Notes
1. Operation at no load will not damage the converter but may not meet
all specifications.
2. When one output is set to 100% load and the other varies between
25%-100% load.
3. Pin pitch tolerance ±0.014 (±0.35)
4. Case tolerance ±0.02 (0.5)
5. Weight: 0.014 lbs (6.5 g)
6. All dimensions in inches (mm)
Pin
1
2
3
4
Single
-V Input
+V Input
Remote On/Off
No Pin
PIN CONNECTIONS
Dual
Pin
Single
-V Input
5
N.C.
+V Input
6
+V Output
Remote On/Off
7
-V Output
No Pin
8
N.C.
Dual
N.C.
+V Output
Common
-V Output
21-Jan-11
