DUAL-IN-LINE SOCKETS
Gull Wing Shrink DIP Sockets & Strips
Surface Mount Solder Tail
0,38-0,64
0,25*0,46
Series 117, 317
317...105
B
2,64
•
Surface mount Gull Wing DIP
sockets for devices featuring
1,78 lead spacing.
5,59
3,68
2,11
2,79
5,59
2,79
•
Gull wing terminals for max.
strength and easy in-circuit
test.
•
Hi-Rel, 4-finger BeCu #30
contact is rated at 3 amps.
See page 218 for details.
•
Series 117 and 317 use MM
#1802 pins. See page 140 for
details.
•
Insulators are high temperature
thermoplastic.
0,46
3,45 PAD
4,52
2,26
2,54
0,81
0,79
0,99
0,51 DIA.
5,08
3,56
117...105
Total number
of pins
Quantity
per tube
Ordering Information
1,78
A
B
C
16
28
30
48
20
28
40
42
48
52
56
64
68
64
14,53
7,62
9,91
35
20
18
12
28
20
14
13
12
11
10
9
8
8
For Electrical,
Mechanical & Enviromental
Data, See pg. 4
117-43-316-41-105000
117-43-428-41-105000
117-43-430-41-105000
117-43-448-41-105000
117-43-620-41-105000
117-43-628-41-105000
117-43-640-41-105000
117-43-642-41-105000
117-43-648-41-105000
117-43-652-41-105000
117-43-656-41-105000
117-43-664-41-105000
117-43-668-41-105000
117-43-764-41-105000
XX=Plating Code
See Below
2002/95/EC
RoHS
25,20 10,16 12,45
26,97 10,16 12,45
42,98 10,16 12,45
18,08
25,20
35,86
37,64
42,98
46,53
50,09
57,20
60,76
15,24
15,24
15,24
15,24
15,24
15,24
15,24
15,24
15,24
17,53
17,53
17,53
17,53
17,53
17,53
17,53
17,53
17,53
For RoHS compliance
select
plating code.
57,20 19,05 21,34
A = 37,64 FOR 21 POS.
2,64
1,78
SINGLE ROW STRIP HEADER
If desired, we will supply any length up to 21 pins.
-
SPECIFY PLATING CODE XX=
21
37,64
---
2,64
317-43-121-41-105000
43
5,08µm Sn
0,76µm Au
Coplanarity 0,13. For Pin Counts >10 positions
consult Technical Support.
Sleeve (Pin)
Contact (Clip)
w w w. m i l l - m a x . c o m
58
516-922-6000
