DUAL-IN-LINE SOCKETS
Solderless Press-Fit, Compliant Tail
Open Frame
•
Unique compliant tail
pins conform to .040
±.003” finished hole
diameter without
stressing inner layers.
•
Two tail lengths are
offered for .060”-.100”
and .090”-.130” thick
panels.
•
Uses M-M# 4612 or
4613 pins with #30
contact rated at 3 amps.
See page 131 for pin
details.
APPLICATION OF COMPLIANT TAIL PINS
Series 146
Mill-Max’ patented* compliant tail features precision machined pins that are
hollow and slotted to conform to a .040” ± .003” diameter PTH. As the pin is
inserted, the slot compresses to fit the PTH, thus avoiding damage (see illustration
at left). The pin’s tail has fine serrations that form a perfect “gas tight” connection
that doesn’t require soldering. And since the pin doesn’t damage the hole,
compliant tail sockets and connectors can be easily replaced.
*Patent No. 4,799,904.
Total number
of pins
Quantity
per tube
Ordering Information
L=.120
(for .060”-.100”
thick panel)
146-XX-306-41-012000
146-XX-308-41-012000
146-XX-314-41-012000
146-XX-316-41-012000
146-XX-318-41-012000
146-XX-320-41-012000
146-XX-324-41-012000
146-XX-422-41-012000
146-XX-624-41-012000
146-XX-628-41-012000
146-XX-632-41-012000
146-XX-640-41-012000
13
91
10μ” Au
93
30μ” Au
A
B
C
L=.175
(for .090”-.130”
thick panel)
146-XX-306-41-013000
146-XX-308-41-013000
146-XX-314-41-013000
146-XX-316-41-013000
146-XX-318-41-013 000
146-XX-320-41-013000
146-XX-324-41-013000
146-XX-422-41-013000
146-XX-624-41-013000
146-XX-628-41-013000
146-XX-632-41-013000
146-XX-640-41-013000
99
200μ” Sn/Pb
41
200μ” Sn
10μ” Au
43
200μ” Sn
30μ” Au
44
200μ”Sn
200μ” Sn
6
8
14
16
18
20
24
22
24
28
32
40
0.3
0.4
0.7
0.8
0.9
1.0
1.2
1.1
1.2
1.4
1.6
2.0
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
67
50
28
25
22
20
16
18
16
14
12
10
For RoHS compliance,
select plating code.
For the all gold option
(XX=13) also change
part number from
146-XX-XXX-41-01X000
to
146-13-XXX-41-01X100
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
10μ” Au
30μ” Au
200μ” Sn/Pb
200μ” Sn/Pb 200μ”Sn/Pb
w w w. m i l l - m a x . c o m
20
516-922-6000
