390168-1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 390168-1

390168-1: DescriptionSIMM/DIMM SOCKET,168 CONTACTS,2; CategoryThe connector The connector; File Size119KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

390168-1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	390168-1	-	-	View	Buy Now

390168-1 Overview

SIMM/DIMM SOCKET,168 CONTACTS,2

390168-1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	compliant
Other features	HIGH TEMPERATURE
Board mount options	SPLIT BOARD LOCK
body width	0.297 inch
subject depth	0.93 inch
body length	5.55 inch
Body/casing type	RECEPTACLE
Connector type	CARD EDGE CONNECTOR
Contact to complete cooperation	AU ON NI
Contact material	PHOSPHOR BRONZE
Contact resistance	20 mΩ
Contact style	BELLOWED TYPE
Dielectric withstand voltage	1000VAC V
Durability	25 Cycles
maximum insertion force	LIF N
Insulation resistance	10000000000 Ω
Insulator color	WHITE
insulator material	GLASS FILLED NYLON
Manufacturer's serial number	390168
Plug contact pitch	0.05 inch
Match contact row spacing	0.075 inch
Installation option 1	LATCH & EJECT
Installation option 2	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	4
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
PCB contact pattern	STAGGERED
PCB contact row spacing	0.075 mm
Plating thickness	15u inch
polarization key	POLARIZED KEY
Rated current (signal)	1 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.11 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	168
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Socket/C ard Products

Product Feature Selector

> Product Details

390168-1 Product Details

Live Product Chat

Product View

Memory Sockets

Not EU R oHS or ELV C om pliant

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

390168-1

T E I nternal N umber: 3 9 0 1 6 8 - 1

Product Highlights:

DIMM 2P

Gold (15) C ontact Mating Area Plating Material

Number of Positions = 168

DRAM Type = Non-Buffered

DRAM Voltage = 3.3 V

View all Features

Obsolete

C ontact Product Information C enter

View 3D PDF

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

PERSONAL SYSTEMS PRODUC TS

(PDF, English)

Product Specifications:

Socket, Dual Readout, Low Insertion Force, DIMM 2P

(PDF, English)

Application Specifications:

Low Insertion Force DIMM 2P Sockets

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

AD Format & C ompression Information)

2D Drawing

(DXF, Version L)

3D Model

(IGES, Version L)

3D Model

(STEP, Version L)

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = DIMM 2P

Number of Positions

= 168

DRAM Type

= Non-Buffered

PC B Mount Style = Through Hole

Module Orientation

= Vertical

PC B Retention Feature = Yes

Profile = Standard

Mechanical Attachment:

C enter Retention Hole Diameter (mm [in])

= 2.44 [0.096]

Electrical Characteristics:

DRAM Voltage

= 3.3 V

Termination Related Features:

Termination Post Length (mm [in])

= 2.79 [0.110]

Solder Tail C ontact Plating = Tin-Lead over Nickel

Body Related Features:

Row-to-Row Spacing (mm [in])

= 1.90 [0.075]

C enterline (mm [in])

= 1.27 [0.050]

Number of Rows

= Dual

Ejector Type = Standard

Ejector Location

= Both Ends

C enter Post = With

Number of Keys

= 2

PC B Retention Method = Boardlock(s)

Mount Type = Printed C ircuit Board

Module Key Type = Key1= Offset Left / Key2= C enter

Contact Related Features:

C ontact Mating Area Plating Material = Gold (15)

C ontact Base Material = Phosphor Bronze

Retention Post(s) Location

= C enter

Retention Post Material = Stainless Steel

Housing Related Features:

Housing Material = High Temperature Nylon

Housing C olor = Black

Housing Flammability Rating = UL 94V-0

Configuration Related Features:

Insertion Style

= Direct Insert

C enter Key (mm [in])

= None

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Wave solder capable to 240?C

Packaging Related Features:

Packaging Method = Tray

Other:

Brand = AMP

Additional Information:

Product Line Information
