Electrical / Environmental
• Operating Temperature Range
• Operating Frequency
-40°C to +85°C
Up to 3MHz
Surface Mount Power Inductors
HM62-2610
S
RoH
liant
mp
Co
Schematic
Specifications @ 25°C / Packaging
Part
Number
HM62-26101R0NLF
HM62-26102R2MLF
HM62-26103R3MLF
HM62-26104R7MLF
HM62-26106R8MLF
HM62-2610100MLF
HM62-2610150MLF
HM62-2610220MLF
Notes:
Inductance
100kHz, 0.1Vrms
@ 0 Adc
µH
Tolerance
1.0
± 30%
2.2
± 20%
3.3
± 20%
4.7
± 20%
6.8
± 20%
10
± 20%
15
± 20%
22
± 20%
DCR
Ω
±
20%
0.092
0.179
0.219
0.282
0.453
0.667
0.857
1.511
I
rated
(Adc)
Max.
1.40
1.00
0.85
0.70
0.61
0.45
0.40
0.33
(1)
I
sat
(Adc)
Max.
1.77
1.30
1.10
0.95
0.75
0.58
0.50
0.38
(2)
Heating
(3)
Current
(Adc)
Marking
Max.
Code
1.55
A
1.28
D
0.98
F
0.86
H
0.73
J
0.52
L
0.43
N
0.32
O
13” Reel
Qty
(Units)
5,000
5,000
5,000
5,000
5,000
5,000
5,000
5,000
Carton
Box
Qty
(Units)
50,000
50,000
50,000
50,000
50,000
50,000
50,000
50,000
(1) The rated current (I
rated
) is the current at which the inductance will be decreased by 10% from its initial (zero DC) value.
(2) The saturation current (I
sat
) is the current at which the inductance rolls off approximately 30% from its initial (zero DC) value.
(3) The heating current is the DC current which causes the inductor temperature to increase by approximately 40°C.
Outline Dimensions (mm)
Top View
Bottom View
Recommended Solder Pad Layout
2.60 ± 0.20
Packaging
A
B
C
1.00 Max.
D
3.82 Max.
E
1.15 Ref.
F
0.50 Ref.
G
0.80 Ref.
H
1.2
I
1.2
J
1.0
2.80 ± 0.20
www.bitechnologies.com
2009/10 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
51
We reserve the right to change specifications without prior notice.
Electrical Characteristics @ 25°C
Ordering Information
HM62 - 2610
Model Series
Case Size
2R2
M
LF
TR
Tape & 13” Reel Packing
Lead-Free
Inductance Tolerance:
M = ±20%
N = ±30%
Inductance Code:
First 2 digits are significant. Last digit denotes the
number of trailing zeros. For values below 10µH,
‘R’ denotes the decimal point.
52
MAGNETIC COMPONENTS SELECTOR GUIDE 2009/10 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
Electrical / Environmental
• Operating Temperature Range
• Operating Frequency
-40°C to +85°C
Up to 3MHz
Surface Mount Power Inductors
HM62-2815
S
RoH
liant
mp
Co
Schematic
Specifications @ 25°C / Packaging
Inductance
100kHz, 0.5Vrms
@ 0 Adc
µH
Tol.
1.5
± 30%
2.2
± 20%
3.3
± 20%
4.7
± 20%
6.8
± 20%
10
± 20%
15
± 20%
22
± 20%
33
± 20%
47
± 20%
DCR
Ω
Typ.
0.062
0.084
0.123
0.172
0.254
0.386
0.497
0.709
1.116
1.835
Max.
0.069
0.098
0.140
0.190
0.270
0.410
0.520
0.740
1.250
1.980
I
rated
(Adc)
Max.
1.05
0.87
0.70
0.70
0.60
0.42
0.26
0.26
0.21
0.20
(1)
Part
Number
HM62-28151R5NLF
HM62-28152R2MLF
HM62-28153R3MLF
HM62-28154R7MLF
HM62-28156R8MLF
HM62-2815100MLF
HM62-2815150MLF
HM62-2815220MLF
HM62-2815330MLF
HM62-2815470MLF
Notes:
I
sat
(Adc)
Max.
1.65
1.40
1.10
0.90
0.85
0.68
0.58
0.48
0.35
0.30
(2)
Heating
(3)
Current
(Adc)
Max.
1.65
1.40
1.20
1.10
0.90
0.75
0.65
0.50
0.40
0.30
Marking
Code
H1R5
H2R2
H3R3
H4R7
H6R8
H100
H150
H220
H330
H470
13” Reel
Qty
(Units)
4,000
4,000
4,000
4,000
4,000
4,000
4,000
4,000
4,000
4,000
Carton
Box
Qty
(Units)
40,000
40,000
40,000
40,000
40,000
40,000
40,000
40,000
40,000
40,000
(1) The rated current (I
rated
) is the current at which the inductance will be decreased by 10% from its initial (zero DC) value.
(2) The saturation current (I
sat
) is the current at which the inductance rolls off approximately 35% from its initial (zero DC) value.
(3) The heating current is the DC current which causes the inductor temperature to increase by approximately 40°C.
Outline Dimensions (mm)
Top View
Side View
Bottom View
Recommended
Solder Pad Layout
www.bitechnologies.com
2009/10 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
53
We reserve the right to change specifications without prior notice.
Electrical Characteristics @ 25°C
Ordering Information
HM62 - 2815
Model Series
Case Size
2R2
M
LF
TR
Tape & 13” Reel Packing
Lead-Free
Inductance Tolerance:
M = ±20%
N = ±30%
Inductance Code:
First 2 digits are significant. Last digit denotes the
number of trailing zeros. For values below 10µH,
‘R’ denotes the decimal point.
54
MAGNETIC COMPONENTS SELECTOR GUIDE 2009/10 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
Electrical / Environmental
• Operating Temperature Range
• Operating Frequency
-40°C to +85°C
Up to 3MHz
Surface Mount Power Inductors
HM62-3214
S
RoH
liant
mp
Co
Schematic
Specifications @ 25°C / Packaging
Inductance
100kHz, 0.1Vrms
Part
@ 0 Adc
Number
µH
Tolerance
HM62-32141R0MLF
1.0
± 20%
HM62-32141R5MLF
1.5
± 20%
HM62-32142R2MLF
2.2
± 20%
HM62-32143R3MLF
3.3
± 20%
HM62-32144R7MLF
4.7
± 20%
HM62-32146R8MLF
6.8
± 20%
HM62-32148R2MLF
8.2
± 20%
HM62-3214100MLF
10
± 20%
HM62-3214150MLF
15
± 20%
HM62-3214220MLF
22
± 20%
HM62-3214330MLF
33
± 20%
HM62-3214101MLF
100
± 20%
Notes:
DCR
Ω
±
20%
0.088
0.120
0.153
0.193
0.290
0.356
0.495
0.547
0.696
0.942
1.264
4.042
I
rated
(Adc)
Max.
2.10
2.00
1.60
1.40
1.20
0.92
0.90
0.80
0.68
0.56
0.51
0.28
(1)
I
sat
(Adc)
Max.
3.35
2.70
2.30
1.90
1.60
1.35
1.20
1.05
0.92
0.75
0.63
0.35
(2)
Heating
(3)
Current
(Adc)
Marking
Max.
Code
1.70
A
1.40
B
1.30
D
1.20
F
0.90
H
0.80
J
0.65
K
0.60
L
0.55
N
0.45
O
0.40
P
0.20
S
13” Reel
Qty
(Units)
4,000
4,000
4,000
4,000
4,000
4,000
4,000
4,000
4,000
4,000
4,000
4,000
Carton
Box
Qty
(Units)
40,000
40,000
40,000
40,000
40,000
40,000
40,000
40,000
40,000
40,000
40,000
40,000
(1) The rated current (I
rated
) is the current at which the inductance will be decreased by 10% from its initial (zero DC) value.
(2) The saturation current (I
sat
) is the current at which the inductance rolls off approximately 30% from its initial (zero DC) value.
(3) The heating current is the DC current which causes the inductor temperature to increase by approximately 40°C.
Outline Dimensions (mm)
Top View
Bottom View
Recommended Solder Pad Layout
3.20 ± 0.30
Packaging
A
B
C
1.40 Max.
D
4.50 Max.
E
1.25 Ref.
F
0.70 Ref.
G
1.00 Ref.
H
1.2
I
1.4
J
1.4
3.20 ± 0.30
www.bitechnologies.com
2009/10 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
55
We reserve the right to change specifications without prior notice.
