Crystal unit
Product Number (please contact us
)
X1E000351xxxx18
MHz RANGE CRYSTAL UNIT
FA2016AN
Nominal
frequency range
External
dimensions
Overtone
order
Applications
:
:
:
:
24 MHz to 54 MHz
2.0 × 1.6 × 0.5 mm
Fundamental
Mobile phone, Bluetooth, W-LAN
ISM band radio, Clock for MPU
Actual size
Specifications (characteristics)
Item
Symbol
Specifications
For RF Reference
For Clock
Conditions / Remarks
Fundamental
Please contact us about available frequencies.
Standard Frequency
Storage as single product.
Recommended: 1 to 100
W
+25
C,
please contact us for requirements not
listed in this specification.
-20
C
to +75
C,
please contact us for
requirements not listed in this specification.
Please specify.
-20
C
to +75
C
-6
24.000 MHz to 54.000 MHz
Nominal frequency range
f_nom
24, 24.576, 25, 26, 27, 27.12, 30, 32, 37.4, 38.4,
40, 48, 50, 52, 54 MHz
Storage temperature range
Operating temperature range
Level of drive
Frequency tolerance (standard)
Frequency versus temperature
characteristics (standard)
Load capacitance
Motional resistance (ESR)
T_stg
T_use
DL
f_tol
f_tem
CL
R1
-6
-40
C
to +125
C
-40
C
to +85
C
100
W
Max.
10
10
-6
*1
10
10
-6
*1
6 pF to
As per table below
200
W
Max.
30
10
-6
30
10
-6
Frequency aging
f_age
1
10 / year Max.
5
10 / year Max.
+25
C,
First year
*1
Please contact us for available frequency tolerances as they are dependent upon the nominal frequency.
Motional resistance (ESR)
Frequency
24.0 MHz
f_nom < 26.0 MHz
26.0 MHz
f_nom
54.0 MHz
Product name
(Standard form)
Motional resistance
80
Max.
60
Max.
FA2016AN 24.000000MHz 12.0 +10.0-10.0
①
②
③
④
①Model
②Frequency
③Load
capacitance(pF)
④Frequency
tolerance(
×
10
-6
,
+25
C)
In addition to the above mentioned specification item, please specify frequency temperature characteristics
and operating temperature range in case of inquiry.
(Unit:mm)
External dimensions
2.0±0.1
#4
#3
Footprint (Recommended)
(Unit:mm)
0.1
±
1.6
#1
2400T
E38T2
#2
1.45
0.5
Max.
#1
0.45
0.50
#4
1.15
C0.20
#2
#4
#1
#3
0.60 0.65
Internal connection
(TOP VIEW )
#3
#2
0.85
0.95
#2 and #4 are con nected to the cover.
(Please connect to ground)
