BIPOLARICS, INC.
Part Number B20V1640
SILICON MICROWAVE POWER TRANSISTOR
PRODUCT DATA SHEET
FEATURES:
DESCRIPTION AND APPLICATIONS:
•
High Output Power
8W @ 1.0 GHz
•
High Gain Bandwidth Product
f = 6.0 GHz @ I
C
= 1600 mA
t
Bipolarics' B20V1640 is a high performance, low cost silicon bipolar
transistor intended for linear power applications at frequencies of 0.5 to
2.6 GHz. Uniformity and reliability are assured by the use of advanced
process techniques: ion implanted junctions, ion implanted ballast
resistors and gold metallization. When the B20V1640 is bonded common
emitter, linear output power of 8 Watt can be achieved.
•
High Gain
G
PE
= 10.0 dB @ 1.0 GHz
Absolute Maximum Ratings:
SYMBOL
PARAMETERS
RATING
UNITS
V
CBO
V
CEO
V
EBO
I
C
T
J
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current (instantaneous)
Junction Temperature
Storage Temperature
40
20
3.0
2400
200
-65 to +150
V
V
V
mA
o
PERFORMANCE DATA:
•
Electrical Characteristics (T
A
= 25
o
C)
C
C
T
STG
o
SYMBOL
PARAMETERS & CONDITIONS
V
CE
=15V, I
C
= 1600 mA, Class A, unless stated
UNIT
MIN.
TYP.
MAX.
P
1dB
G
1dB
Power output at 1 dB compression:
f = 1.0 GHz
W
8.0
Gain at 1dB compression:
f = 1.0 GHz
dB
10.0
η
C
CB
Collector Efficiency
Class A
%
30
Collector Base Capacitance:
f = 1 MHz, I
E
= 0
pF
5.2
4.0
h
FE
P
T
Forward Current Transfer Ratio: V
CE
= 8V, I
C
=800 mA
Total Power Dissipation
W
20
60
100
24
PAGE
2
BIPOLARICS, INC
20 0.200" Pill Package
45
Part Number B20V1640
28 0.280" Pill Package
45
SILICON MICROWAVE POWER TRANSISTOR
4
4
0.060
(1.524)
1
0.880
(22.35)
0.225
(5.71)
1
3
1.030
(26.16)
3
2
0.030
(0.762)
0.004
(0.102)
0.210
(5.334)
0.11
(2.80)
0.045
(1.143)
0.055 0.005
(1.40) (0.13 )
2
0.280 DIA
(7.11 DIA)
0.13
(3.30)
50 Ceramic 4 Lead PAK Surface Mount
.125
(3.175)
08 Ceramic SO8 Package
0.086
(2.184)
Emitter
.050
Base
(1.27)
.050
(1.27)
Base
.250 .140
(6.35)(3.556)
.050
(1.27)
.020
(.508)
Base
Collector
.070
(1.778)
Collector
Base
Emitter
.090
(2.286)
Emitter
Base
Collector
Base
.250
(6.35)
.560
(14.224)
.050
(1.27)
.050
(1.27)
.160
(4.064)
.190
(4.826)
NOTES:
(unless otherwise specified)
in
1. Dimensions are
(mm)
2. Tolerances:
in .xxx =
±
.005
mm .xx =
±
.13
3. All dimensions nominal; subject to change
without notice
Drawings are not to scale.
LEAD
20 & 28
Package
1
Base
2
Emitter
3
Base
4
Collector
