A6810KLWTR-T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> A6810KLWTR-T

A6810KLWTR-T: DescriptionIC source drvr 10bit ser 20soic; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size358KB，9 Pages; ManufacturerAllegro; Websitehttp://www.allegromicro.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

A6810KLWTR-T Overview

IC source drvr 10bit ser 20soic

A6810KLWTR-T Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Allegro
Parts packaging code	SOIC
package instruction	SOP, SOP20,.4
Contacts	20
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	CAN ALSO OPERATE WITH 5V LOGIC SUPPLY
data entry mode	SERIAL
Interface integrated circuit type	VACUUM FLUORESCENT DISPLAY DRIVER
JESD-30 code	R-PDSO-G20
JESD-609 code	e3
length	12.8 mm
Humidity sensitivity level	3
Multiplex display function	NO
Number of functions	1
Number of segments	10
Number of terminals	20
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP20,.4
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
power supply	3.3/5,60 V
Certification status	Not Qualified
Maximum seat height	2.65 mm
Maximum slew rate	3 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	3 V
Nominal supply voltage	3.3 V
Supply voltage1-Nom	60 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
width	7.5 mm
minfmax	10 MHz

Preview

Download Datasheet

View All

A6810

10-Bit Serial Input Latched Source Driver

Discontinued Product

This device is no longer in production. The device should not be

purchased for new design applications. Samples are no longer available.

Date of status change: November 1, 2010

Recommended Substitutions:

For existing customer transition, and for new customers or new appli-

cations, contact Allegro Sales.

NOTE: For detailed information on purchasing options, contact your

local Allegro field applications engineer or sales representative.

Allegro MicroSystems, Inc. reserves the right to make, from time to time, revisions to the anticipated product life cycle plan

for a product to accommodate changes in production capabilities, alternative product availabilities, or market demand. The

information included herein is believed to be accurate and reliable. However, Allegro MicroSystems, Inc. assumes no respon-

sibility for its use; nor for any infringements of patents or other rights of third parties which may result from its use.

A6810KLWTR-T Related Products

	A6810KLWTR-T	A6810ELWTR-T	A6810ELW-T	A6810ELWTR	A6810SA-T	A6810KLWTR
Description	IC source drvr 10bit ser 20soic	IC source drvr 10bit ser 20soic	IC source drvr 10bit ser 20soic	IC source drvr 10bit ser 20soic	IC source drvr 10bit ser 18dip	IC source drvr 10bit ser 20soic
Is it Rohs certified?	conform to	conform to	conform to	incompatible	conform to	incompatible
Maker	Allegro	Allegro	Allegro	Allegro	Allegro	Allegro
Parts packaging code	SOIC	SOIC	SOIC	SOIC	DIP	SOIC
package instruction	SOP, SOP20,.4	SOP, SOP20,.4	SOP, SOP20,.4	SOP, SOP20,.4	DIP, DIP18,.3	SOP, SOP20,.4
Contacts	20	20	20	20	18	20
Reach Compliance Code	unknown	unknow	unknown	compliant	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Other features	CAN ALSO OPERATE WITH 5V LOGIC SUPPLY	CAN ALSO OPERATE WITH 5V LOGIC SUPPLY	CAN ALSO OPERATE WITH 5V LOGIC SUPPLY	CAN ALSO OPERATE WITH 5V LOGIC SUPPLY	CAN ALSO OPERATE WITH 5V LOGIC SUPPLY	CAN ALSO OPERATE WITH 5V LOGIC SUPPLY
data entry mode	SERIAL	SERIAL	SERIAL	SERIAL	SERIAL	SERIAL
Interface integrated circuit type	VACUUM FLUORESCENT DISPLAY DRIVER	VACUUM FLUORESCENT DISPLAY DRIVER	VACUUM FLUORESCENT DISPLAY DRIVER	VACUUM FLUORESCENT DISPLAY DRIVER	VACUUM FLUORESCENT DISPLAY DRIVER	VACUUM FLUORESCENT DISPLAY DRIVER
JESD-30 code	R-PDSO-G20	R-PDSO-G20	R-PDSO-G20	R-PDSO-G20	R-PDIP-T18	R-PDSO-G20
JESD-609 code	e3	e3	e3	e0	e3	e0
length	12.8 mm	12.8 mm	12.8 mm	12.8 mm	22.86 mm	12.8 mm
Multiplex display function	NO	NO	NO	NO	NO	NO
Number of functions	1	1	1	1	1	1
Number of segments	10	10	10	10	10	10
Number of terminals	20	20	20	20	18	20
Maximum operating temperature	125 °C	85 °C	85 °C	85 °C	85 °C	125 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-20 °C	-40 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	SOP	SOP	SOP	DIP	SOP
Encapsulate equivalent code	SOP20,.4	SOP20,.4	SOP20,.4	SOP20,.4	DIP18,.3	SOP20,.4
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260	260	260	240	260	245
power supply	3.3/5,60 V	3.3/5,60 V	3.3/5,60 V	3.3/5 V	3.3/5,60 V	3.3/5,60 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	2.65 mm	2.65 mm	2.65 mm	2.65 mm	5.33 mm	2.65 mm
Maximum slew rate	3 mA	3 mA	3 mA	0.3 mA	3 mA	3 mA
Nominal supply voltage	3.3 V	3.3 V	3.3 V	3.3 V	3.3 V	3.3 V
Supply voltage1-Nom	60 V	60 V	60 V	60 V	60 V	60 V
surface mount	YES	YES	YES	YES	NO	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	AUTOMOTIVE	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	OTHER	AUTOMOTIVE
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	TIN LEAD	Matte Tin (Sn)	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	THROUGH-HOLE	GULL WING
Terminal pitch	1.27 mm	1.27 mm	1.27 mm	1.27 mm	2.54 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	40	40	40	30	NOT SPECIFIED	30
width	7.5 mm	7.5 mm	7.5 mm	7.5 mm	7.62 mm	7.5 mm
minfmax	10 MHz	10 MHz	10 MHz	10 MHz	10 MHz	10 MHz
Maximum supply voltage	5.5 V	5.5 V	-	-	5.5 V	5.5 V
Minimum supply voltage	3 V	3 V	-	-	3 V	3 V
