MULTILAYER CERAMIC CHIP CAPACITORS
C Series
Commercial Grade
General (Up to 50V)
Type:
C0402 [EIA CC01005]
C0603 [EIA CC0201]
C1005 [EIA CC0402]
C1608 [EIA CC0603]
C2012 [EIA CC0805]
C3216 [EIA CC1206]
C3225 [EIA CC1210]
C4532 [EIA CC1812]
C5750 [EIA CC2220]
Issue date:
Apr 2014
006-02 / 20140424 / mlcc_commercial_general_en
MULTILAYER CERAMIC CHIP CAPACITORS
REMINDERS
Please read before using this product
SAFETY REMINDERS
REMINDERS
1.
2.
3.
If you intend to use a product listed in this catalog for a purpose that may cause loss of life or other damage,
you must contact our company’s sales window.
We may modify products or discontinue production of a product listed in this catalog without prior notification.
We provide “Delivery Specification” that explain precautions for the specifications and safety of each product
listed in this catalog. We strongly recommend that you exchange these delivery specifications with customers
that use one of these products.
If you plan to export a product listed in this catalog, keep in mind that it may be a restricted item according
to the “Foreign Exchange and Foreign Trade Control Law”. In such cases, it is necessary to acquire export
permission in harmony with this law.
Any reproduction or transferring of the contents of this catalog is prohibited without prior permission from our
company.
We are not responsible for problems that occur related to the intellectual property rights or other rights of our
company or a third party when you use a product listed in this catalog. We do not grant license of these rights.
This catalog only applies to products purchased through our company or one of our company’s official agencies.
This catalog does not apply to products that are purchased through other third parties.
4.
5.
6.
7.
Notice: Effective January 2013, TDK will use a new catalog number which adds product thickness and packaging
specification detail. This new catalog number should be referenced on all catalog orders going forward, and
is not applicable for OEM part number orders. Please be aware the last five digits of the catalog number will
differ from the item description (internal control number) on the product label. Contact your local TDK Sales
representative for more information.
(Example)
Catalog Issued date
Prior to January 2013
January 2013 and Later
Catalog Number
C1608C0G1E103J
C1608C0G1E103J080AA
Item Description (On Delivery Label)
C1608C0G1E103JT000N
C1608C0G1E103JT000N
Page 1
006-02 / 20140424 / mlcc_commercial_general_en
MULTILAYER CERAMIC CHIP CAPACITORS
C Series
Type: C0402 [EIA CC01005], C0603 [EIA CC0201], C1005 [EIA CC0402], C1608 [EIA
CC0603], C2012 [EIA CC0805], C3216 [EIA CC1206], C3225 [EIA CC1210],
C4532 [EIA CC1812], C5750 [EIA CC2220]
General (Up to 50V)
Features
• High capacitance has been achieved through precision technologies
that enable the use of multiple thinner ceramic dielectric layers.
• A monolithic structure ensures superior mechanical strength and
reliability.
• Low ESL and excellent frequency characteristics allow for a circuit
design that closely conforms to theoretical values.
• Low self-heating and high ripple resistance due to low ESR.
Applications
•
•
•
•
•
•
General electronic equipment
Mobile communication equipment
Power supply circuit
Office automation equipment
TV, LED displays
Servers, PCs, Notebooks, Tablets
L
W
T
B
G
Body Length
Body Width
Body Height
Terminal Width
Terminal Spacing
Shape &
Dimensions
Catalog Number
Construction
Series Name
Dimensions L x W (mm)
Code
C0402
C0603
C1005
C1608
C2012
C3216
C3225
C4532
C5750
Length
0.40 ± 0.02
0.60 ± 0.03
1.00 ± 0.05
1.60 ± 0.10
2.00 ± 0.20
3.20 ± 0.20
3.20 ± 0.40
4.50 ± 0.40
5.70 ± 0.40
C • 3225 • X7R • 1H • 106 • M • 250 • A • C
Width
0.20 ± 0.02
0.30 ± 0.03
0.50 ± 0.05
0.80 ± 0.10
1.25 ± 0.20
1.60 ± 0.20
2.50 ± 0.30
3.20 ± 0.40
5.00 ± 0.40
Terminal
0.07 min.
0.10 min.
0.10 min.
0.20 min.
0.20 min.
0.20 min.
0.20 min.
0.20 min.
0.20 min.
*Dimension tolerance are typical values
Temperature Characteristics
Temperature
Temperature Coefficient or
Characteristics
Capacitance Change
0±60 ppm/°C
CH
0±30 ppm/°C
C0G
±10%
JB
±15%
X5R
±22%
X6S
±15%
X7R
±22%
X7S
Temperature
Range
-25 to +85°C
-55 to +125°C
-25 to +85°C
-55 to +85°C
-55 to +105°C
-55 to +125°C
-55 to +125°C
Rated Voltage (DC)
Code
0G
0J
1A
1C
1E
1V
1H
Voltage (DC)
4V
6.3V
10V
16V
25V
35V
50V
Nominal Capacitance (pF)
The capacitance is expressed in three digit codes and in units of pico Farads (pF).
The first and second digits identify the first and second significant figures of the
capacitance. The third digit identifies the multiplier. R designates a decimal point.
Ex. 0R2 = 0.2pF; 103 = 10,000pF; 105 = 1,000,000pF = 1,000nF = 1μF
Capacitance Tolerance
Code
B
C
D
F
G
J
K
M
Tolerance
± 0.10pF
± 0.25pF
± 0.50pF
± 1%
± 2%
± 5%
± 10%
± 20%
Nominal Thickness
Code
020
030
050
060
080
085
115
125
Thickness
0.20 mm
0.30 mm
0.50 mm
0.60 mm
0.80 mm
0.85 mm
1.15 mm
1.25 mm
Code
130
160
200
230
250
280
320
Thickness
1.30 mm
1.60 mm
2.00 mm
2.30 mm
2.50 mm
2.80 mm
3.20 mm
Packaging Style
Code
A
B
K
Style
178” Reel, 4mm Pitch
178” Reel, 2mm Pitch
178” Reel, 8mm Pitch
Special Reserved Code
Code
Description
A, B, C TDK Internal Code
Version A13
Page 2
• All specifications are subject to change without notice.
006-02 / 20140424 / mlcc_commercial_general_en
MULTILAYER CERAMIC CHIP CAPACITORS
Capacitance
Range Chart
Capacitance Range Chart
Temperature Characteristics: C0G(0 ± 30ppm/ºC), CH(0 ± 60ppm/ºC), JB(±10%)
Rated Voltage: 16V (1C), 10V (1A), 6.3V (0J),
Capacitance
(pF)
0.5
0.75
1
1.5
2
2.2
3
3.3
4
4.7
5
6
6.8
7
8
9
10
12
15
18
22
27
33
39
47
56
68
82
100
150
220
330
470
680
1,000
1,500
2,200
3,300
4,700
6,800
10,000
Code
0R5
R75
010
1R5
020
2R2
030
3R3
040
4R7
050
060
6R8
070
080
090
100
120
150
180
220
270
330
390
470
560
680
820
101
151
221
331
471
681
102
152
222
332
472
682
103
Tolerance
C: ± 0.25pF
D: ± 0.50pF
J: ± 5%
K: ± 10%
M: ± 20%
C0G
1C
(16V)
CH
1C
(16V)
1C
(16V)
JB
1A
(10V)
0J
(6.3V)
0G
(4V)
EIA CC01005 [C0402]
Standard Thickness
0.20 mm
Page 3
• All specifications are subject to change without notice.
006-02 / 20140424 / mlcc_commercial_general_en
MULTILAYER CERAMIC CHIP CAPACITORS
Capacitance
Range Chart
Capacitance Range Chart
Temperature Characteristics: X5R (± 15%), X6S (±22%), X7R (±15%)
Rated Voltage: 16V (1C), 10V (1A), 6.3V (0J), 4V (0G)
Capacitance
(pF)
100
150
220
330
470
680
1,000
1,500
2,200
3,300
4,700
6,800
10,000
22,000
47,000
100,000
220,000
Code
101
151
221
331
471
681
102
152
222
332
472
682
103
223
473
104
224
Tolerance
K: ± 10%
M: ± 20%
X5R
1C
(16V)
1A
(10V)
0J
(6.3V)
0G
(4V)
1A
(10V)
X6S
0J
(6.3V)
0G
(4V)
1A
(10V)
X7R
0J
(6.3V)
0G
(4V)
EIA CC01005 [C0402]
Standard Thickness
0.20 mm
Page 4
• All specifications are subject to change without notice.
006-02 / 20140424 / mlcc_commercial_general_en
