Electrical / Environmental
oH
li
S
nt
R
mp a
Co
1210 Industry Size
Surface Mount Inductors
•
•
•
•
•
•
Inductance Range
0.12µH to 120µH
Standard Tolerance
±10%(<3.3µH = ±20%)
Operating Temperature Range
-40°C to +105°C
Ambient Temperature, Maximum
80°C
Resistance to Solder Heat
260°C for 10 sec.
Terminal Pull Strength, Minimum
0.5 kg
Specifications
Part
Number
BCL322522-R12MLF
BCL322522-R15MLF
BCL322522-R18MLF
BCL322522-R22MLF
BCL322522-R27MLF
BCL322522-R33MLF
BCL322522-R39MLF
BCL322522-R47MLF
BCL322522-R56MLF
BCL322522-R68MLF
BCL322522-R82MLF
BCL322522-1R0MLF
BCL322522-1R2MLF
BCL322522-1R5MLF
BCL322522-1R8MLF
BCL322522-2R2MLF
BCL322522-2R7MLF
BCL322522-3R3KLF
BCL322522-3R9KLF
BCL322522-4R7KLF
BCL322522-5R6KLF
BCL322522-6R8KLF
BCL322522-8R2KLF
BCL322522-100KLF
BCL322522-120KLF
LF
BCL322522-180KLF
BCL322522-220KLF
BCL322522-270KLF
BCL322522-330KLF
BCL322522-390KLF
BCL322522-470KLF
BCL322522-560KLF
BCL322522-680KLF
BCL322522-820KLF
BCL322522-101KLF
BCL322522-121KLF
Last Updated: 8 April 2008
Inductance
µH
0.12±20%
0.15±20%
0.18±20%
0.22±20%
0.27±20%
0.33±20%
0.39±20%
0.47±20%
0.56±20%
0.68±20%
0.82±20%
1.0±20%
1.2±20%
1.5±20%
1.8±20%
2.2±20%
2.7±20%
3.3±10%
3.9±10%
4.7±10%
5.6±10%
6.8±10%
8.2±10%
10.0±10%
12.0±10%
15.0±10%
18.0±10%
22.0±10%
27.0±10%
33.0±10%
39.0±10%
47.0±10%
56.0±10%
68.0±10%
82.0±10%
100±10%
120±10%
Q Min.
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
20
20
Test
Frequency
MHz
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
SRF
MHz Min.
500
450
400
350
320
300
250
220
180
160
140
120
100
85
80
75
70
60
55
50
45
40
35
30
20
20
20
20
20
17
16
15
13
12
11
10
8
DC
Resistance
Ω
Max
0.22
0.25
0.28
0.32
0.36
0.40
0.45
0.50
0.55
0.60
0.65
0.70
0.75
0.85
0.90
1.00
1.10
1.20
1.30
1.50
1.60
1.80
2.00
2.10
2.50
2.80
3.30
3.70
5.00
5.60
6.40
7.00
8.00
9.00
10.00
11.00
12.00
Rated
Current
IDC mA
450
450
450
450
450
450
450
450
450
450
450
400
390
370
350
320
290
260
250
220
200
180
170
150
140
130
120
110
80
70
65
60
55
50
45
40
70
2007/08 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
www.bitechnologies.com
We reserve the right to change specifications without prior notice
101
Outline Dimensions (Inch/mm)
Packaging
Standard:
Embossed Tape & Reel
Reel:
Diameter
Capacity
=
=
7” (177.8mm)
1000 Units
Ordering Information
BCL 322522
Model Series
Inductance Code:
First 2 digits are significant. Last digit
denotes the number of trailing zeros.
For values below 10µH, ‘R’ denotes
the decimal point.
330
K
LF
Lead-Free
Inductance Tolerance
J = ±5% (From 1µH to 120µH)
K = ±10% (Full inductance range)
M = ±20% (Full inductance range)
102
MAGNETIC COMPONENTS SELECTOR GUIDE 2007/08 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
