Semitronics
Features:
•
•
•
Isolated Power Package
Rugged Construction
HR Military Screening Available
Rectifiers
483-03
600V, 25 Amps
3 Phase Rectifier Bridge
Schematic Diagram
A
A
C
A
C
A
C
C
Table 1: Maximum Ratings Per Leg
l
Parameter
Peak Repetitive Reverse Voltage, V
RPM
Peak Working Reverse Voltage, V
RWM
DC Reverse Blocking Voltage, V
R
Average Forward Current, I
O
@ 55°C
Average Forward Current, I
O
@ 100°C
Max. Surge Current, I
FSM @
T
j
= 55°C, sinusoidal
Operating and Storage Junction Temp. Range
Thermal Resistance, junction to case
Thermal Resistance Junction to Ambient
25°C
Max Rating
600 V
25 A
18.5A
150 A
-65 to +150 °C
2.5 °C/W
20 °C/W
25°C
Limits
Min
Max
2
200
1.3
2.0
Units
µA
µA
V
µsec
Parameter
Reverse Current
Reverse Current
Forward Voltage
Max. Recovery Time
Table 2: Electrical Characteristics per leg
l
Symbol
Conditions
I
R1
I
R2
V
F1
t
rr
V
R
= 600V
V
R
= 600V, T
A
= 100°C
I
FM
= 39A
I
F
= 0.5A, I
r
=1.0A, I
rr
=0.25A
Mechanical Dimensions
Semitronics
,
64 Commercial St. Freeport, NY 11520 Tel (516) 623-9400 / Fax (516) 623-6954
Pg. 1 of 1
