MCR
Series
Tantalum Chip
Surface Mount
Low Impedance
125 C
Maximum
Temperature
Actual
Size
The MCR series are new low impedance tantalum chip capacitors available from UCC/NCC. These
capacitors have a standard 20% tolerance and are available in the D case size. The MCR series
capacitors are specifically designed for use as filters at high frequencies and are ideal for small power
supplies due to their low impedance.
Refer to the Mini-Glossary at the end of the tantalum chip capacitors section for additional technical
information and specifications.
TANTALUM CHIP
MCR
Summary of Specifications
Surface mount terminals.
Capacitance range: 10 to 150µF.
Voltage range: 6.3 to 35VDC.
Operating temperature range: 55 C to 125 C.
Standard capacitance tolerance: 20%
Nominal case size (L W H): 7.3 4.3 2.8mm.
Rated lifetime: 1,000 hours at 85 C.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
107
MCR Series
MCR Specifications
Item
Operating Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
55 to
Characteristics
85 C without voltage derating;
55 to 125 C with voltage derating.
6.3 to 35VDC
10 to 150 F
20% ( M ) at
20 C, 120Hz
I
0.01CV or 0.5 A, whichever is greater, after applying the DC rated voltage for 5 minutes
at 20 C.
Where I = Leakage current ( A ), C = Nominal capacitance ( F ) and V = Rated voltage ( VDC)
Dissipation Factor ( Tan )
At
20 C, 120Hz
10 F
≤
4V
> 4V
8%
6%
15 - 68 F
8%
8%
≥
100 F
11%
10%
Capacitance ( F )
Max. Tan
( DF )
Low and High Temperature
Characteristics
In accordance with JIS-C-5102 test conditions, the measurements for stability of electrical
performance of capacitors at 55 C, 85 C and 125 C are shown in the following table.
Temperature ( C )
Max. Capacitance Change
10 F
Max. Tan
( DF )
15 - 68 F
≥
100 F
Max. Leakage Current
55 C
10%
8% (
≤
4V:10%)
10% (
≤
4V:10%)
12% (
≤
4V:13%)
—
85 C
10%
6% (
≤
4V: 8%)
8% (
≤
4V: 8%)
10% (
≤
4V:11%)
≤10
initial specified
limit at 20 C
125 C
15%
8% (
≤
4V:10%)
10% (
≤
4V:10%)
12% (
≤
4V:13%)
≤12.5
initial specified
limit at 20 C
Surge Voltage Test
In accordance with JIS-C-5102 test conditions, the following specifications shall be satisfied
when the capacitors are restored to 20 C after applying the specified surge voltage for 1,000
cycles (1 cycle = 30 sec. on, 330 sec. off ) at 85 C.
Capacitance change :
≤
12% of initial measured value for 6.3 -10V
:
≤
10% of initial measured value for 16- 35V
Tan ( DF )
: shall not exceed initial specified DF value above
Leakage current
: shall not exceed initial specified LC value above
Soldering Heat Resistance
In accordance with JIS-C-5143 test conditions, the mounting surface of capacitor terminals
shall be dipped in a solder bath of eutectic solder (Sn 60%, Pb 40%) at 260 C for 5 seconds.
After cooling and 1- 2 hours at room temperature, the following specifications shall be satisfied
when the capacitors are tested for electrical performance and appearance at 20 C.
Capacitance change :
≤
8% of initial measured value for 6.3 -10V
:
≤
5% of initial measured value for 16- 35V
Tan ( DF )
: shall not exceed initial specified DF value above
Leakage current
: shall not exceed initial specified LC value above
Appearance
: no abnormality
TANTALUM CHIP
MCR
Humidity Load Life Test
In accordance with JIS-C-5102 test conditions, the following specifications shall be satisfied
when the capacitors are restored to 20 C after applying the DC rated voltage for 500 hours
at 40 C, 90 - 95% RH.
Capacitance change :
≤
10% of initial measured value
Tan ( DF )
: shall not exceed initial specified DF value above
Leakage current
: shall not exceed initial specified LC value above
Load Life Test
In accordance with JIS-C-5102 test conditions, the following specifications shall be satisfied
when the capacitors are restored to 20 C after applying the DC rated voltage for 1,000 hours
at 85 C.
Capacitance change :
≤
12% of initial measured value for 6.3 -10V
:
≤
10% of initial measured value for 16- 35V
Tan ( DF )
: shall not exceed initial specified DF value above
Leakage current
: shall not exceed 125% of initial specified LC value above
Failure Rate
Standard
1% per 1,000 hours after applying the DC rated voltage through a 1Ω / V resistor at
Satisfies characteristic LB of JIS-C-5143
85 C.
108
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
MCR Series
Diagram of Dimensions
Tantalum Chips
Unit: mm
L
W
H
Case Dimensions
UCC
EIA
Case Code Case Code
L
7.3
0.2
4.3
W
0.2
2.8
H
0.2
1.3
a
0.3
2.4
b
0.2
a
a
b
D
D
Part Numbering System for MCR Series
16
MCR
336
M
D
TER
When ordering, always specify complete catalog number for MCR Series.
Taping Code: TER = standard polarity orientation on 7” reel.
TEL = optional polarity orientation on 7” reel.
Case Code: Refer to diagram of dimensions for standard case sizes.
Capacitance Tolerance: M = 20%
Capacitance Value: Expressed in picofarads. The first two digits are
significant figures, and the third digit indicates the number of zeros
following these figures ( e.g. 336 = 33,000,000pF = 33 F ).
Series Name: Indicates Basic Capacitor Design.
Voltage Code: 16 = 16VDC (decimals are dropped for part numbering code).
Standard Voltage Ratings - Tantalum Chips
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
†Part
Number
†
UCC
Case Code*
EIA
Case Code*
Maximum ESR
(
Ω
) at
20 C, 100kHz
TANTALUM CHIP
6.3 Volts
8 Volts Surge
68
100
150
47
68
100
33
47
22
33
6MCR686MDTER
6MCR107MDTER
6MCR157MDTER
10MCR476MDTER
10MCR686MDTER
10MCR107MDTER
16MCR336MDTER
16MCR476MDTER
20MCR226MDTER
20MCR336MDTER
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
0.175
0.15
0.15
0.2
0.15
0.1
0.25
0.2
0.275
0.225
MCR
10 Volts
13 Volts Surge
16 Volts
20 Volts Surge
20 Volts
25 Volts Surge
25 Volts
32 Volts Surge
15
25MCR156MDTER
D
D
0.275
35 Volts
44 Volts Surge
10
35MCR106MDTER
D
D
0.3
†
TER = standard taping code. TEL = optional taping code. Refer to taping specifications.
*
Refer to diagram of dimensions for actual case sizes.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
109
MCR Series
Soldering Conditions
Soldering Guidelines
Pre-heat tantalum chip capacitors. Do not exceed 150 C for more than 5 minutes. The recommended soldering temperature
profiles for the capacitors are shown below. Be sure to stay within the allowable range to avoid capacitor damage.
Recommended Soldering Temperature Profiles
Immersion Soldering Profile
Surface Temperature of Substrate ( C)
Temperature of Solder Bath ( C)
270
260
270
260
Reflow Soldering Profile
Dangerous Range
250
240
Dangerous Range
250
240
230
220
Allowable Range
230
220
210
200
0
2
4
6
8
10
12
14
16
18
Allowable Range
210
200
0
10
20
30
40
50
60
70
Time in Solder Bath (sec.)
Time in Reflow (sec.)
Tape and Reel Specifications
Tantalum Chips
Taping
T
1
P
1
P
2
P
0
Ø
D
Unit: mm
Taping Dimensions
Case Code
(EIA Code)
X 0.1
Y 0.1
W 0.3
F 0.05
E 0.1
P
1
0.1
P
2
P
0
Ø
D
T
1
T
2
0.05
0.1
0.1, 0
0.2
D
( D)
4.8 0.2
7.7 0.2
12.0
5.65
1.5
8.0
2.0
4.0
1.5
0.3
3.6
E
F
Y
W
X
T
2
Direction of Feed
Orientation of Component Polarity
Taping Code: TER (standard)
Taping Code: TEL (optional )
TANTALUM CHIP
MCR
Direction of Feed
Direction of Feed
Reel
Reel Dimensions and Quantity Per Reel
Case Code
(EIA Code)
Ø
E 2
Ø
F min.
Ø
G 0.5
Ø
H 0.8
K 0.5
W 1.5
T 0.5
R
Pieces
Per Reel
D
( D)
178
50
13
21
2
18
2
1.0
600
K
Ø
G
Ø
E
Ø
F
R
Ø
H
T
W
110
