Through Hole Ceramic Resonator
Low Frequency
SERIES
CZTB
Part Numbering Example: CZTB ‐ AW ‐ 3 ‐ 5 ‐ 0.455
CZTB
-
SERIES
ADDED FEATURES
-
Blank = Bilk Pac
Z = Tape and Reel
AW
OPERATING TEMP.
-
3
STABILITY (PPM)
-
CZTB
A2 = ‐40 to +85
AW = ‐20 to +85
3 = 3.000
0.455
TOLERANCE (PPM)
FREQUENCY (MHz)
3 = 3.000
In put frequency
5 = 5.000
3 digits after dot.
-
5
Specifications
Frequency Range
Frequency Stability
Frequency Tolerance at 25
Operating Temperature Range
Resonator Resitance
0.190 to 1.250 MHz
3.000 PPM
3.000 PPM
5.000 PPM
‐40 to +85
‐20 to +85
0.190 to 0.509MHz = 20
0.510 to 0.699 MHz = 30
0.700 to 0.999 MHz = 70
1.000 to 1.250 MHz = 100
to 100 VDC = 500 M
0.190 to 0.249 MHz = C1 = 330 pF;C2 = 470 pF
0.250 to 0.374 MHz = C1 = 220 pF;C2 = 470 pF
0.375 to 0.400 MHz = C1 = 120 pF;C2 = 470 pF
0.401 to 1.250 MHz = C1 = C2 = 100 pF
1000
W
3.000 PPM
Insulator Resistance Min.
Recommended Capacitors
Test Circuit Samples
Drive Level Max.
Aging at 25 / ano
