2225G391D302ST-A datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> capacitor> 2225G391D302ST-A

Preview

2225G391D302ST-A: DescriptionCeramic Capacitor, Multilayer, Ceramic, 3000V, 0.1282% +Tol, 0.1282% -Tol, NP0, -/+30ppm/Cel TC, 0.00039uF, 2225; CategoryPassive components capacitor; File Size81KB，1 Pages; ManufacturerCapax Technologies Inc; Websitehttp://www.capaxtechnologies.com/

Download Datasheet Parametric View All

2225G391D302ST-A Overview

Ceramic Capacitor, Multilayer, Ceramic, 3000V, 0.1282% +Tol, 0.1282% -Tol, NP0, -/+30ppm/Cel TC, 0.00039uF, 2225

2225G391D302ST-A Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	1214089305
package instruction	, 2225
Reach Compliance Code	compliant
Country Of Origin	USA
ECCN code	EAR99
YTEOL	5.33
capacitance	0.00039 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	4.064 mm
JESD-609 code	e0
length	5.588 mm
Manufacturer's serial number	2225(NP0,3KV)HV
multi-layer	Yes
negative tolerance	0.1282%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package form	SMT
method of packing	TR, 7 Inch
positive tolerance	0.1282%
Rated (DC) voltage (URdc)	3000 V
series	2225(NP0,3KV)HV
size code	2225
Temperature characteristic code	NP0
Temperature Coefficient	30ppm/Cel ppm/°C
Terminal surface	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
width	6.35 mm

Preview

Download Datasheet

View All

Technologies, Inc

Surface Mount Capacitors:

2225 - NPO, High Voltage

Mechanical Dimensions

Length (L): .220” ± .010”

Width (W): .250” ± .010”

Thickness (T): .160” max

Bandwidth (bw): .040”

2225 SMT Capacitors feature:

•

2225 Case Size

•

High Capacitance

•

Low ESR

•

NPO Dielectric Material

Capacitance Value

Value (pF)

10

15

18

20

22

27

33

39

47

56

68

82

100

120

150

180

220

270

330

390

470

560

Cap. Code

100

150

180

200

220

270

330

390

470

560

680

820

101

121

151

181

221

271

331

391

471

561

Max Voltage

3000 VDC

Dielectric

NPO

Value (pF)

680

820

1000

1500

1800

2200

3300

4700

6800

8200

10,000 (.01µF)

22,000 (.022µF)

33,000 (.033µF)

47,000 (.047µF)

100,000 (.10µF)

Cap. Code

681

821

102

152

182

222

332

472

682

822

103

223

333

473

104

Max Voltage

2000 VDC

Dielectric

NPO

1000 VDC

NPO

500 VDC

NPO

100 VDC

NPO

50 VDC

NPO

** For Additional Capacitance Values and Working Voltages, Please Contact the Factory **

O

RDERING

I

NFORMATION

Case Size

Dielectric

Capacitance

Tolerance

Voltage

Termination

Packaging

Hi-Reli Testing

2225

Mechanical

Dimensions

Shown

Above

G

G = NPO

101

First 2 digits are

Significant; Third

digit indicates

# of Zeros. Use “R”

for decimal point

Examples:

201 = 200pF

2R2 = 2.2pF

J

B ±.10pF

C ±.25pF

D ±.50pF

F ±1%

G ±2%

J ±5%

K ±10%

302

First 2 digits are

Significant; Third

digit indicates

number of Zeros

Examples:

201 = 200V

151 = 150V

SN

S Solder Plated

Over Nickel

SN Tin over

Nickel Plated

G Gold over

Nickel Plated

(RoHS Compliant)

T

T = Tape and

Reel

- A

(Optional)

A = Group A

B = Group B

C = Group C

Tested and

Screened

C

APAX

T

ECHNOLOGIES

, I

NC

º

24842 A

VE

T

IBBITTS

º

V

ALENCIA

, C

A

º

91355

º

661.257.7666

º

F

AX

: 661.257.4819

WWW

.C

APAX

T

ECHNOLOGIES

.C

OM
