Pulse Jack
SMT Power Inductors
Power Beads - PA4228.XXXHL Series
Current Rating:
Over 80Apk
Inductance Range:
150nH to 180nH
Height:
9.0 mm Max
Footprint:
12.8mm x 8.3mm Max
Halogen Free
Electronics
Part
Number
PA4228.151HL
PA4228.181HL
Inductance
1
@ 0A
DC
(nH +/- 15%)
150
180
IN
AR
Y
125°C
66
57
Dimensions:
mm
Electrical Specifications @ 25°C — Operating Temperature - 40°C to +130°C
7
Saturation Current
5
Inductance
2
3
4
Irated
DCR
(A TYP)
@Irated
(ADC)
(mΩ nominal)
(nH TYP)
25°C
100°C
145
69
75+
69
0.13 +/- 15%
171
60
73
60
Heating Current
6
(A TYP)
80
NOTES:
1. Inductance measured at 100kHz, 100mVrms.
2. Inductance at Irated is the value of the inductance at 25°C at the listed rated current.
3. The rated current as listed is either the saturation current (25°C or 100°C) or the heating current depending on
which value is lower.
4. The nominal DCR is measured from point a to point b , as shown below on the mechanical drawing.
7. In high volt*time applications, additional heating in the component can occur due to core losses in the inductor
which may neccessitate derating the current in order to limit the temperature rise of the component. To determine
the approximate total losses (or temperature rise) for a given application, the coreloss and temperature rise curves
can be used.
6. The heating current is the DC current which causes the part temperature to increase by approximately 40°C
when used in a typical application.
IM
Mechanical
5. The saturation current is the typical current which causes the inductance to drop by 20% at the stated ambient
temperatures (25°C, 100°C ). This current is determined by placing the component in the specified ambient
environment and applying a short duration pulse current (to eliminate self-heating effects) to the component.
8. Parts with the HLT suffix are sold in tape and reel packaging. Pulse complies to industry standard tape and reel
specification EIA-481. The tape and reel for this product has a width (W=24mm), pitch (Po=16mm) and depth
(Ko=10.8mm). Samples of these parts can be ordered by removing the HLT suffix and replacing with HL.
9. The temperature of the component (ambient plus temperature rise) must be within the stated operating
temperature range.
Schematic
PR
EL
Weight
. . . . . . . . . X .XX/grams
Tape & Reel
. . . . . . . .XXX/reel
Unless otherwise specified,
all tolerances are ± 0,25
PA4228.XXXHL
1
pulseelectronics.com
P778.A (12/15)
Pulse Jack
SMT Power Inductors
Power Beads - PA4228.XXXHL Series
Electronics
PA4228.151HL, LvsI, 25C/100C/125C
160
140
120
Inductance (nH)
100
80
60
40
20
0
0
10
20
IN
AR
Y
30
40
50
60
70
80
Current (A)
151HL_25C
151HL_100C
151HL_125C
200
180
160
Inductance (nH)
140
120
100
80
60
40
20
0
PR
0
10
20
30
40
50
EL
60
70
IM
181HL_25C
PA4228.181HL, LvsI, 25C/100C/125C
Current (A)
181HL_100C
181HL_125C
2
pulseelectronics.com
P778.A (12/15)
Pulse Jack
SMT Power Inductors
Power Beads - PA4228.XXXHL Series
0 .6
0 .5
0 .4
0 .3
0 .2
0 .1
0 .0
PA4228.XXXHL CoreLoss (W)
Electronics
CoreLoss (W)
0
500
200kHz
300kHz
60
Temp Rise above Ambient (C)
50
40
30
20
10
0
PR
EL
0
0 .2
0 .4
0 .6
Power (W)
0 .8
1
1 .2
Total Power Dissipation (W) = CopperLoss + CoreLoss
CopperLoss = Irms^2 * Rdc(mOhms) / 1000
CoreLoss = (from table)
For More Information
Pulse Worldwide
Headquarters
12220 World Trade Drive
San Diego, CA 92128
U.S.A.
Pulse China Headquarters
Pulse North China
Pulse South Asia
Pulse North Asia
B402, Shenzhen Academy of
Room 2704/2705
135 Joo Seng Road
3F, No. 198
Aerospace Technology Bldg.
Super Ocean Finance Ctr.
#03-02
Zhongyuan Road
10th Kejinan Road
2067 Yan An Road West
PM Industrial Bldg.
Zhongli City
High-Tech Zone
Shanghai 200336
Singapore 368363
Taoyuan County 320
Nanshan District
China
Taiwan R. O. C.
Shenzhen, PR China 518057
Tel: 886 3 4356768
Tel: 858 674 8100
Tel: 49 7032 7806 0
Tel: 86 755 33966678
Tel: 86 21 62787060
Tel: 65 6287 8998
Fax: 886 3 4356823 (Pulse)
Fax: 858 674 8262
Fax: 49 7032 7806 135
Fax: 86 755 33966700
Fax: 86 2162786973
Fax: 65 6287 8998
Fax: 886 3 4356820 (FRE)
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product names mentioned herein may be
trademarks or registered trademarks of their respective owners. © Copyright, 2015. Pulse Electronics, Inc. All rights reserved.
Pulse Europe
Einsteinstrasse 1
D-71083 Herrenberg
Germany
IM
pulseelectronics.com
PA4228 .XXXHL Temp Rise vs Power Dissipation
3
IN
AR
Y
1000
1500
2000
2500
3000
DeltaB
where DeltaB = .38 * L(nH) * DeltaI
400kHz
500kHz
600kHz
700kHz
1 .0MHz
P778.A (12/15)
