SMD Precision Current Sense Resistor
Type S Series
Type S Series
Characteristics -
Electrical
Values S1/2:
Values S1:
Values S2:
Values S3:
Grid:
Resistance Tolerances:
Power Rating @ 25°C S1/2:
Power Rating @ 25°C S1:
Power Rating @ 25°C S2:
Power Rating @ 25°C S3:
Derating:
Max. Operating Voltage S1/2:
Max Operating Voltage S1:
Max Operating Voltage S2:
Max Operating Voltage S3:
Inductance:
"SL" Lo Ohm
R01 - R05
R005 - R075
R005 - R099
R005 - R099
E24
1%, 3%, 5%.
0.5 Watt
1 Watt
2 Watts
3 Watts
See Curve Below
√Power
x Resistance
√Power
x Resistance
√Power
x Resistance
√Power
x Resistance
< 7 Nanohenries
"SP" Power
R06 - 1K4
R10 - 5K0
R10 - 10K
R10 - 45K
E96
0.1% to 5%.
0.75 Watts
1.5 Watt
2.5 Watts
3.5 Watts
See Curve Below
33 Volts
58 Volts
127 Volts
212 Volts
----
"SU" Precision
----
1R0 - 300K
1R0 - 1 Meg
1R0 - 2 Meg
E192
0.005% to 1%.
----
0.125 Watts
0.250 Watts
0.500 Watts
See Curve Below
----
100 Volts
300 Volts
400 Volts
----
Tyco introduces a range of surface
mount power resistors to meet today's
circuit design needs. One design
concept allows an engineer to choose
from three styles (Lo Ohm, Power, or
Ultra Precision) while staying within
the new standard circuit board land
pattern guidelines now accepted by
the wirewound resistor industry. Each
size offers low profile case design with
flexible tinned copper terminations for
reliable solder joints. All styles utilise a
fully welded construction technique,
unlike other designs that rely solely on
tinned termination connections. These
features allow the S Series to withstand
the higher temperatures associated
with reflow, vapour phase, or infrared
(IR) manufacturing processes without
degradation.
Characteristics -
Electrical
Solder Immersion:
Load Life:
Moisture Resistance:
Thermal Shock:
Dielectric Withstand:
Short Term Overload:
Solderability:
Flammability:
260°C for 10 seconds.
2000 hours at rated power at 25°C.
240 hours with humidity ranging from 80% RH to 98% RH.
-55°C for 15 minutes no load.
1000 Volts.
5 times rated power for 5 seconds
95% coverage within 1/16" of contact point.
UL94V Rating.
Typical
∆R
0.1%
0.2%
0.1%
0.1%
0.1%
----
----
Key Features
I
I
I
I
I
I
I
Low Profile Design
Available on Tape
(3 Reel Sizes)
Very Wide Value Range
Ideal for Current Sensing
Up to 3.0 Watts Power
High TCR Versions
(to 6000ppm)
Stable to 5ppm/°C
Temperature Coefficient
of Resistance
Range
R005 - R20
R10 - R99
1R0 - 10R
11R - 99R
100R and over
(L) Low Ohm
<100 PPM
(P) Power
±30ppm
±20ppm
±90ppm
±50ppm
(U) Precision
±25ppm
±10ppm
±10ppm
NB: High TCR Type Available to 6000ppm/°C
Power Derating
100
Percent Rated Power
75
50
25
0
25
50
75
100
125
150
175
200
225
250
275
Ambient Temperature (°C)
0.1%, 0.25%, 0.5%, 1.0%
0.02%, 0.05%
0.01%
0.005%
Note: U Style derates to 145°C. All others derate to 275°C
Literature No. 1773276
Issued: 07-05
Dimensions are shown for
reference purposes only.
Dimensions are in millimetres
unless otherwise specified.
Specifications subject to
change.
www.tycoelectronics.com
passives.tycoelectronics.com
SMD Precision Current Sense Resistor
Type S Series
Dimensions
Size
S 1/2
S1
S2
S3
Length
(L)
5.46
6.48
12.14
15.24
Width
(W)
3.18
3.81
5.84
7.00
Height
(H)
2.54
2.84
5.33
6.48
Stand Off
(S)
n/a
0.50
0.50
0.50
Pad Width
(PW)
1.27
1.27
2.54
2.29
Pad Length
(PL)
1.02
1.25
2.54
1.27
Land Pattern
Type
S 1/2
S1
S2
S3
H
1.91
3.43
6.98
10.42
J
4.45
5.97
10.54
14.78
X
1.78
2.03
3.05
2.80
Y
2.54
2.54
3.56
3.56
Cleaning Conditions
After soldering use cleaning solvents such as chlorosen, dyefreon, suitable aqueous or semi aqueous cleaner.
Storage
To prevent damage to the electrode, be sure to observe the following cautions for storage.
• Store in 40°C maximum ambient temperature, and 70% maximum R.H.
• For maximum possible shelf life do not disturb polythene sleeve until you are ready to use.
• Store where there are no harmful gases containing sulphur or chlorine.
How to Order
S
Common Part
L
Resistor Type
L - Low Ohmic
1 - 6.5 x 3.8
S - Standard Part
P - Power
2 - 12.1 x 5.9
U - Precision
3 - 15.3 x 7.0
1
Case Size
1/2 - 5.5 x 3.2
1R0
Resistance Value
0.1 Ohm
(100 milli ohms)
R10
1 Ohm
(1000 milli ohms)
1R0
1K Ohm
(1000 Ohms)
1K0
J
Absolute Tol.
at +25°C
K ±10%
J ±5%
E ±3%
F ±1%
D ±0.5%
C ±0.25%
B ±0.1%
A ±0.05%
Q ±0.02%
T ±0.01%
Z ±0.005%
T
Pack Style
L - Loose Piece
R - S_1 500 pcs
7” Reel
S - S_1 1000 pcs
13” Reel
W - S_2 1000 pcs
13” Reel
Literature No. 1773276
Issued: 07-05
Dimensions are shown for
reference purposes only.
Dimensions are in millimetres
unless otherwise specified.
Specifications subject to
change.
www.tycoelectronics.com
passives.tycoelectronics.com
