CRCW120615R0KNTB

Description
Fixed Resistor, Metal Glaze/thick Film, 0.125W, 15ohm, 200V, 10% +/-Tol, 200ppm/Cel, Surface Mount, 1206, CHIP
CategoryPassive components    The resistor
File Size135KB,5 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

CRCW120615R0KNTB Overview

Fixed Resistor, Metal Glaze/thick Film, 0.125W, 15ohm, 200V, 10% +/-Tol, 200ppm/Cel, Surface Mount, 1206, CHIP

CRCW120615R0KNTB Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Objectid1619290280
package instructionCHIP
Reach Compliance Codenot_compliant
Country Of OriginIsrael
ECCN codeEAR99
YTEOL6.7
Other featuresPRECISION, LASER TRIMMABLE
JESD-609 codee0
Manufacturer's serial numberCRCW
Installation featuresSURFACE MOUNT
Number of terminals2
Maximum operating temperature155 °C
Minimum operating temperature-55 °C
Package shapeRECTANGULAR PACKAGE
method of packingTR, PAPER, 11.25 INCH
Rated power dissipation(P)0.125 W
Rated temperature70 °C
resistance15 Ω
Resistor typeFIXED RESISTOR
size code1206
surface mountYES
technologyMETAL GLAZE/THICK FILM
Temperature Coefficient200 ppm/°C
Terminal surfaceTin/Lead (Sn/Pb)
Terminal shapeWRAPAROUND
Tolerance10%
Operating Voltage200 V
D../CRCW....-TR
Vishay
Lead (Pb)-bearing Thick Film, Rectangular,
Trimmable Chip Resistors
FEATURES
Can be trimmed to the required value after insertion
For applications in precision circuitry where relative
tolerances can be compensated by trimming
SnPb contacts on Ni barrier layer
Metal glaze on high quality ceramic
Protective overglaze
STANDARD ELECTRICAL SPECIFICATIONS
SIZE
MODEL
INCH METRIC
0402
0603
0805
1206
1210
2010
2512
1005
1608
2012
3216
3225
5025
6332
POWER RATING
P
70 °C
W
0.063
0.10
0.125
0.25
0.33
0.50
1.0
LIMITING
ELEMENT
VOLTAGE
MAX V≅
50
75
150
200
200
200
200
TEMPERATURE
COEFFICIENT
ppm/K
± 100
± 200
± 100
± 200
± 100
± 200
± 100
± 200
± 200
± 400
± 500
TOLERANCE
%
RESISTANCE
RANGE
Ω
10R - 10M
R47 - 10M
10R - 10M
R47 - 10M
10R - 10M
R47 - 10M
10R - 10M
R47 - 10M
10R - 4M7
10R - 4M7
10R - 4M7
E-SERIES
D10/CRCW0402-TR
D11/CRCW0603-TR
D12/CRCW0805-TR
D25/CRCW1206-TR
CRCW1210-TR
CRCW2010-TR
CRCW2512-TR
24
24
24
24
24
24
24
± 10
± 15
± 20
+ 0/- 30
± 15
± 15
± 15
Notes:
These resistors do not feature a limited lifetime when operated within the permissible limits. However, resistance value drift increasing over
operating time may result in exceeding a limit acceptable to the specific application, thereby establishing a functional lifetime
Marking: no marking on device, on the label only
Packaging: see appropriate catalog or web pages
Power rating depends on the max. temperature at the solder point, the component placement density and the substrate material
TECHNICAL SPECIFICATIONS
PARAMETER
Rated Dissipation at 70 °C
(3)
Limiting Element Voltage
(2)
Insulation Voltage (1 min)
Thermal Resistance
(1)
Insulation Resistance
Category Temperature Range
Failure Rate
Weight/1000 pieces
(1)
For
UNIT
W
V≅
V
peak
K/W
Ω
°C
h
-1
g
D10/
D11/
D12/
D25/
CRCW1210-TR CRCW2010-TR CRCW2512-TR
CRCW0402-TR CRCW0603-TR CRCW0805-TR CRCW1206-TR
0.063
50
> 75
870
0.1
75
> 100
550
0.125
150
> 200
440
0.25
200
> 300
220
> 10
9
- 55/+ 125 (+ 155)
0.3 x 10
-9
0.65
2
5.5
10
16
25.5
40.5
0.33
200
> 300
140
0.5
400
> 300
88
1.0
500
> 300
65
Notes:
size 0402 until 1206 the measuring conditions are in acc. to EN 140401-802. For all other sizes the result depends on the solder pad
dimensions
(2)
Rated voltage:
PxR
(3)
The power dissipation on the resistor generates a temperature rise against the local ambient, depending on the heat flow support of the
printed-circuit board (thermal resistance). The rated dissipation applies only if the permitted film temperature of 155 °C is not exceeded
www.vishay.com
174
For technical questions in Europe, contact: ff1bresistors@vishay.com
For technical questions in Americas/Asia, contact: ff2aresistors@vishay.com
Document Number: 20012
Revision: 10-Aug-07
