Type 450C
105 °C Ultra-Ripple, Long-life, Inverter Grade, Radial Leaded
The Ultimate in Ripple for Plug-in
Type 450C is the 105 °C version of the Type 420C Inverter
Grade capacitor, and it is the PC-mount version of the Type
550C. It delivers the ripple-current capability and exceptional
life needed for motor-drive and inverter bus capacitors. It is
a significantly better value than comparable 105 °C snap-in
capacitors. The extended cathode foil of the 450C assures
cool operation and heat flow from the capacitor element to
the can in all orientations.
Highlights
Specifications
Operating Temperature:
Rated Voltage:
Capacitance:
DC Leakage Current:
Cold Impedance:
Ripple Current Multipliers:
• Better value than large 105 °C snap-in capacitors
• Especially for motor drives and UPS systems
• ESRs to 6.9 mΩ
• Printed-circuit mounting
• Thermal-Pak™ extended cathode construction
–40 °C to 105 °C
100 to 500 Vdc
150 µF to 24,000 µF ± 20%
≤ 3 √CV µA, 4 mA max, 5 minutes
20 °C multiple of 25 °C Z ≤ 3
Ambient Temperature
45 °C
1.66
55 °C
1.52
50 Hz
100 to 350 V
400 to 500 V
2” Diameters
100 to 350 V
400 to 500 V
0.92
0.82
0.94
0.86
1.00
1.00
1.05
1.14
1.07
1.20
1.08
1.23
1.08
1.27
0.91
0.82
65 °C
1.37
60 Hz
0.93
0.86
75 °C
1.20
120 Hz
1.00
1.00
85 ºC
1.00
360 Hz
1.06
1.14
95 ºC
0.75
1 kHz
1.08
1.20
5 kHz
1.09
1.23
105 °C
0.36
10 kHz
1.09
1.23
Frequency
1 3/8” & 1 3/4” Diameters
EIA Ripple Life:
5000 h at 85 °C per EIA IS-749 with 85 ºC ripple current
∆ Capacitance ± 20%
ESR 200 % of limit
DCL 100 % of limit
Life Test:
10,000 h at 105 ºC with rated voltage
∆ Capacitance ± 10%
ESR 200 % of limit
DCL 100 % of limit
Shelf Life Test:
500 h at 105 °C. Capacitance, ESR and DCL meet initial requirements
Vibration:
10 to 55 Hz, 0.06” and 10 g max, 2 h each plane
Complies with the EU Directive
2002/95/EC requirement restricting
the use of Lead (Pb), Mercury (Hg),
Cadmium (Cd), Hexavalent chro-
mium (Cr(VI)), PolyBrominated Bi-
phenyls (PBB) and PolyBrominated
Diphenyl Ethers (PBDE).
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864) 843-2277 • Fax: (864) 843-3800 • www.cde.com
Type 450C
105 °C Ultra-Ripple, Long-life, Inverter Grade, Radial Leaded
Outline Drawings
Case Dimensions
Case
AK
AA
AH
AB
AJ
AC
AD
AE
AF
EA
EH
EB
EJ
EC
ED
EE
EF
BA
BH
BB
BJ
BC
BD
BE
BF
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
1.75
2.25
2.75
3.25
3.75
4.25
4.75
5.25
5.75
2.25
2.75
3.25
3.75
4.25
4.75
5.25
5.75
2.25
2.75
3.25
3.75
4.25
4.75
5.25
5.75
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.70
0.70
0.70
0.70
0.70
0.70
0.70
0.70
0.80
0.80
0.80
0.80
0.80
0.80
0.80
0.80
Inches
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.375
0.375
0.375
0.375
0.375
0.375
0.375
0.375
0.425
0.425
0.425
0.425
0.425
0.425
0.425
0.425
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.55
0.55
0.55
0.55
0.55
0.55
0.55
0.55
0.55
0.90
0.90
0.90
0.90
0.90
0.90
0.90
0.90
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
34.93
34.93
34.98
34.93
34.93
34.93
34.93
34.93
34.93
44.45
44.45
44.45
44.45
44.45
44.45
44.45
44.45
50.80
50.80
50.80
50.80
50.80
50.80
50.80
50.80
44.45
57.15
69.85
82.55
95.25
107.95
120.65
133.35
146.05
57.15
69.85
82.55
95.25
107.95
120.65
133.35
146.05
57.15
69.85
82.55
95.25
107.95
120.65
133.25
146.05
Millimeters
12.70
12.70
12.70
12.70
12.70
12.70
12.70
12.70
12.70
17.78
17.78
17.78
17.78
17.78
17.78
17.78
17.78
20.32
20.32
20.32
20.32
20.32
20.32
20.32
20.32
4.45
4.45
4.45
4.45
4.45
4.45
4.45
4.45
4.45
9.53
9.53
9.53
9.53
9.53
9.53
9.53
9.53
10.80
10.80
10.80
10.80
10.80
10.80
10.80
10.80
6.35
6.35
6.35
6.35
6.35
6.35
6.35
6.35
6.35
8.89
8.89
8.89
8.89
8.89
8.89
8.89
8.89
10.16
10.16
10.16
10.16
10.16
10.16
10.16
10.16
13.97
13.97
13.97
13.97
13.97
13.97
13.97
13.97
13.97
22.86
22.86
22.86
22.86
22.86
22.86
22.86
22.86
25.40
25.40
25.40
25.40
25.40
25.40
25.40
25.40
Code D ± .031 L MAX C ± .015 S ± .031 E ± .031 F ± .015 D ± .78 L MAX C ± .78 S ± .78 E ± .78 F ± .38
Part Numbering System
450C
Type
222
Capacitance
M
100
Voltage
AK
Case Code
8
Insulation
Terminal
222 =
2200 µF
151 =
150 µF
M =
±20%
T =
–10% +50%
U =
–10% +75%
Tolerance
100 =
100 V
450 =
450 V
0 =
Bare can
8 =
PVC and
Standoffs
9 =
Polyester and
Standoffs
(blank) =
Straight
Leads
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864) 843-2277 • Fax: (864) 843-3800 • www.cde.com
Type 450C
105 °C Ultra-Ripple, Long-life, Inverter Grade, Radial Leaded
Ratings
Cap.
(µF)
2200
3300
4000
4800
5800
6100
6600
7100
8200
8400
8700
9800
11000
11000
11000
12000
13000
14000
15000
16000
17000
18000
19000
22000
24000
1200
1800
2600
3000
3300
3300
3600
4000
4500
4700
4800
5300
5800
6000
6100
6700
6900
7400
8000
8700
9100
10000
10000
12000
13000
880
1300
1900
2000
2500
ESR Max.
Ripple
25 ºC
Amps, 85 ºC
120 Hz 20
120 Hz 20
kHz
kHz (A)
Catalog Part
(mΩ) (mΩ)
(A)
Number
100 Vdc (125 Vdc Surge)
450C222M100AK8 74.90 50.90 4.20 5.20
450C332M100AA8 50.30 34.20 5.80 7.30
450C402M100AH8 36.80 24.90 7.00 8.80
450C482M100EA8 40.10 27.20 7.50 9.40
450C582M100AB8 28.50 19.40 8.60 10.70
450C612M100BA8 37.00 25.10 8.40 10.50
450C662M100EH8 28.70 19.50 9.50 11.90
450C712M100AJ8
23.50 15.90 9.90 12.40
450C822M100BH8 26.30 17.80 10.70 13.40
450C842M100AC8 20.10 13.60 11.30 14.10
450C872M100EB8 22.20 15.10 11.70 14.60
450C982M100AD8 17.70 12.00 12.60 15.80
450C113M100AE8 15.90 10.80 13.90 17.40
450C113M100EJ8
18.30 12.40 13.30 16.60
450C113M100BB8 20.40 13.80 12.90 16.10
450C123M100AF8 18.10 12.30 13.70 17.10
450C133M100EC8 15.60 10.60 14.90 18.60
450C143M100BJ8
16.80 11.40 15.90 19.90
450C153M100ED8 13.70 9.30 16.80 21.00
450C163M100BC8 14.40 9.80 17.30 21.60
450C173M100EE8 12.30 8.40 18.80 23.40
450C183M100BD8 12.70 8.60 19.00 23.70
450C193M100EF8
11.30 7.60 21.00 26.20
450C223M100BE8 11.10 7.50 21.00 26.20
450C243M100BF8 10.20 6.90 22.70 28.40
160 Vdc (200 Vdc Surge)
450C122M160AK8 113.00 65.20 4.20 5.60
450C182M160AA8 75.70 44.10 5.90 7.70
450C262M160EA8 56.20 36.80 7.50 9.30
450C302M160AH8 53.20 31.30 7.30 9.50
450C332M160AB8 41.40 24.70 8.90 11.50
450C332M160BA8 47.90 34.10 8.30 9.90
450C362M160EH8 40.20 26.00 9.50 11.80
450C402M160AJ8
34.20 20.60 10.20 13.10
450C452M160BH8 33.90 23.80 10.70 12.70
450C472M160EB8 31.20 20.40 11.70 14.40
450C482M160AC8 29.40 18.00 11.60 14.80
450C532M160AD8 26.90 16.50 12.70 16.20
450C582M160EJ8
25.70 16.90 13.30 16.30
450C602M160BB8 26.40 18.60 12.70 15.10
450C612M160AE8 24.20 15.10 14.00 17.80
450C672M160AF8 22.20 14.10 15.40 19.30
450C692M160EC8 22.00 14.70 14.90 18.20
450C742M160BJ8
21.70 15.50 15.70 18.60
450C802M160ED8 19.40 13.10 16.70 20.30
450C872M160BC8 18.70 13.40 17.10 20.10
450C912M160EE8 17.50 11.90 18.60 22.60
450C103M160EF8 16.00 11.00 20.80 25.10
450C103M160BD8 16.50 11.90 18.70 22.00
450C123M160BE8 14.50 10.70 20.70 24.10
450C133M160BF8 13.40 9.90 22.30 25.90
200 Vdc (250 Vdc Surge)
450C881M200AK8 142.00 78.90 3.80 5.00
450C132M200AA8 95.50 53.30 5.30 7.00
450C192M200EA8 68.40 42.50 6.80 8.70
450C202M200AH8 66.90 37.70 6.50 8.60
450C252M200AB8 51.90 29.50 7.90 10.50
Nominal
Size
DXL
(in)
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/8 X 2 3/4
1 3/4 X 2 1/4
1 3/8 X 3 1/4
2 X 2 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
2 X 2 3/4
1 3/8 X 4 1/4
1 3/4 X 3 1/4
1 3/8 X 4 3/4
1 3/8 X 5 1/4
1 3/4 X 3 3/4
2 X 3 1/4
1 3/8 X 5 3/4
1 3/4 X 4 1/4
2 X 3 3/4
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
2 X 4 3/4
1 3/4 X 5 3/4
2 X 5 1/4
2 X 5 3/4
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/4 X 2 1/4
1 3/8 X 2 3/4
1 3/8 X 3 1/4
2 X 2 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
2 X 2 3/4
1 3/4 X 3 1/4
1 3/8 X 4 1/4
1 3/8 X 4 3/4
1 3/4 X 3 3/4
2 X 3 1/4
1 3/8 X 5 1/4
1 3/8 X 5 3/4
1 3/4 X 4 1/4
2 X 3 3/4
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
1 3/4 X 5 3/4
2 X 4 3/4
2 X 5 1/4
2 X 5 3/4
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/4 X 2 1/4
1 3/8 X 2 3/4
1 3/8 X 3 1/4
Ripple
ESR Max. 25 Amps, 85 ºC
ºC
120 Hz 20
120 Hz 20 kHz kHz (A)
Catalog Part
(mΩ) (mΩ)
Number
(A)
450C252M200BA8
56.70 38.10 7.70 9.30
450C272M200EH8
49.00 30.10 8.60 11.00
450C302M200AJ8
42.70 24.60 9.10 12.00
450C332M200BH8
40.30 26.70 9.80 12.00
450C352M200EB8
37.90 23.50 10.60 13.40
450C362M200AC8
36.50 21.30 10.40 13.60
450C402M200AD8
33.40 19.50 11.40 14.90
450C432M200EJ8
31.20 19.50 12.10 15.20
450C442M200BB8
31.20 20.90 11.70 14.30
450C452M200AE8
29.90 17.70 12.60 16.40
450C502M200AF8
27.30 16.40 13.90 17.90
450C512M200EC8
26.60 16.80 13.50 17.00
450C552M200BJ8
25.70 17.30 14.50 17.60
450C602M200ED8
23.40 14.90 15.20 19.00
450C642M200BC8
22.00 14.90 15.70 19.10
450C672M200EE8
21.00 13.50 17.00 21.20
450C742M200BD8
19.40 13.30 17.30 20.90
450C762M200EF8
19.10 12.50 19.00 23.60
450C892M200BE8
16.90 11.80 19.10 22.90
450C982M200BF8
15.50 10.90 20.70 24.70
250 Vdc (300 Vdc Surge)
450C551M250AK8
210.00 87.30 3.10 4.80
450C831M250AA8
141.00 58.90 4.30 6.70
450C102M250AH8
98.10 41.60 5.40 8.20
450C122M250EA8
96.10 45.90 5.80 8.30
450C152M250BA8
76.50 40.60 6.60 9.00
450C162M250AB8
75.70 32.50 6.50 10.00
450C172M250EH8
69.20 32.60 7.20 10.60
450C192M250AJ8
62.00 27.00 7.60 11.50
450C212M250BH8
54.70 28.50 8.40 11.60
450C222M250EB8
53.40 25.40 8.90 12.90
450C232M250AC8
52.70 23.30 8.70 13.00
450C252M250AD8
48.20 21.30 9.50 14.20
450C272M250EJ8
43.60 21.00 10.20 14.70
450C282M250BB8
42.20 22.20 10.10 13.90
450C292M250AE8
43.00 19.40 10.50 15.70
450C312M250AF8
38.90 17.90 11.60 17.10
450C322M250EC8
37.10 18.10 11.50 16.40
450C342M250BJ8
34.60 18.40 12.50 17.10
450C382M250ED8
32.40 16.00 12.90 18.40
450C412M250BC8
29.40 15.90 13.60 18.50
450C422M250EE8
28.90 14.50 14.50 20.50
450C472M250BD8
26.00 14.10 14.90 20.30
450C482M250EF8
26.20 13.40 16.30 22.80
450C562M250BE8
22.40 12.50 16.60 22.30
450C622M250BF8
20.40 11.50 18.00 24.00
300 Vdc (350 Vdc Surge)
450C381M300AK8
283.00 134.00 2.40 3.50
450C571M300AA8
189.00 89.90 3.30 4.80
450C801M300AH8
131.00 63.10 4.10 6.00
450C961M300EA8
119.00 56.70 4.80 6.90
450C112M300AB8
101.00 49.00 5.10 7.30
450C122M300BA8
106.00 53.20 5.50 7.80
450C132M300EH8
87.00 40.80 6.00 8.70
450C132M300AJ8
82.40 40.40 5.90 8.40
450C152M300AC8
69.70 34.60 6.70 9.50
450C162M300BH8
75.80 37.70 7.00 9.90
450C172M300EB8
66.90 31.70 7.30 10.70
Nominal
Size
DXL
(in)
2 X 2 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
2 X 2 3/4
1 3/4 X 3 1/4
1 3/8 X 4 1/4
1 3/8 X 4 3/4
1 3/4 X 3 3/4
2 X 3 1/4
1 3/8 X 5 1/4
1 3/8 X 5 3/4
1 3/4 X 4 1/4
2 X 3 3/4
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
2 X 4 3/4
1 3/4 X 5 3/4
2 X 5 1/4
2 X 5 3/4
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/8 X 2 3/4
1 3/4 X 2 1/4
2 X 2 1/4
1 3/8 X 3 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
2 X 2 3/4
1 3/4 X 3 1/4
1 3/8 X 4 1/4
1 3/8 X 4 3/4
1 3/4 X 3 3/4
2 X 3 1/4
1 3/8 X 5 1/4
1 3/8 X 5 3/4
1 3/4 X 4 1/4
2 X 3 3/4
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
2 X 4 3/4
1 3/4 X 5 3/4
2 X 5 1/4
2 X 5 3/4
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/8 X 2 3/4
1 3/4 X 2 1/4
1 3/8 X 3 1/4
2 X 2 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
1 3/8 X 4 1/4
2 X 2 3/4
1 3/4 X 3 1/4
Cap.
(µF)
2500
2700
3000
3300
3500
3600
4000
4300
4400
4500
5000
5100
5500
6000
6400
6700
7400
7600
8900
9800
550
830
1000
1200
1500
1600
1700
1900
2100
2200
2300
2500
2700
2800
2900
3100
3200
3400
3800
4100
4200
4700
4800
5600
6200
380
570
800
960
1100
1200
1300
1300
1500
1600
1700
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864) 843-2277 • Fax: (864) 843-3800 • www.cde.com
Type 450C
105 °C Ultra-Ripple, Long-life, Inverter Grade, Radial Leaded
Cap.
(µF)
Catalog Part
Number
ESR Max.
Ripple Amps,
25 ºC
85 ºC
120 Hz 20 kHz 120 Hz 20 kHz
(mΩ) (mΩ)
(A)
(A)
Nominal
Size
DXL
(in)
Cap.
(µF)
Catalog Part
Number
ESR Max.
Ripple Amps,
25 ºC
85 ºC
120 Hz 20 kHz 120 Hz 20 kHz
(mΩ) (mΩ)
(A)
(A)
Nominal
Size
DXL
(in)
1800
2100
2100
2100
2300
2500
2600
2900
3100
3300
3600
3700
4300
4700
300
460
600
770
860
960
1000
1000
1200
1300
1400
1500
1700
1700
1700
1800
2000
2100
2300
2500
2600
2900
3000
3500
3800
270
410
600
690
770
860
930
930
1100
1200
1200
1300
1500
1500
1500
1600
1800
1900
450C182M300AD8 60.60 30.50 7.50
450C212M300AE8 53.70 27.50 8.40
450C212M300EJ8 54.50 26.10 8.40
450C212M300BB8 58.40 29.30 8.40
450C232M300AF8 48.40 25.10 9.30
450C252M300EC8 48.10 23.30 9.50
450C262M300BJ8 47.60 24.10 10.40
450C292M300ED8 41.80 20.50 10.70
450C312M300BC8 41.10 21.50 11.30
450C332M300EE8 37.10 18.40 12.00
450C362M300BD8 35.50 18.30 12.50
450C372M300EF8 33.50 16.90 13.50
450C432M300BE8 30.50 16.10 14.00
450C472M300BF8 27.60 14.80 15.30
350 Vdc (400 Vdc Surge)
450C301M350AK8 325.00 150.00 2.20
450C461M350AA8 217.00 100.00 3.10
450C601M350AH8 151.00 70.30 3.80
450C771M350EA8 135.00 61.90 4.50
450C861M350AB8 116.00 54.50 4.70
450C961M350BA8 119.00 57.40 5.20
450C102M350EH8 99.00 44.70 5.60
450C102M350AJ8 94.40 44.90 5.50
450C122M350AC8 79.80 38.40 6.30
450C132M350BH8 85.60 40.70 6.60
450C142M350EB8 76.10 34.70 6.90
450C152M350AD8 69.30 33.80 7.00
450C172M350EJ8 62.00 28.50 7.90
450C172M350BB8 65.80 31.60 7.90
450C172M350AE8 61.40 30.30 7.80
450C182M350AF8 55.20 27.70 8.70
450C202M350EC8 54.60 25.40 8.90
450C212M350BJ8 53.70 26.00 9.80
450C232M350ED8 47.40 22.30 10.00
450C252M350BC8 46.20 23.10 10.70
450C262M350EE8 42.00 20.00 11.30
450C292M350BD8 40.00 19.70 11.80
450C302M350EF8 37.80 18.30 12.70
450C352M350BE8 34.20 17.30 13.20
450C382M350BF8 30.90 15.80 14.40
400 Vdc (450 Vdc Surge)
450C271M400AK8 356.00 161.00 2.10
450C411M400AA8 238.00 108.00 3.00
450C601M400AH8 166.00 75.70 3.70
450C691M400EA8 147.00 65.80 4.30
450C771M400AB8 127.00 58.70 4.50
450C861M400BA8 129.00 60.60 5.00
450C931M400EH8 108.00 47.60 5.30
450C931M400AJ8 103.40 48.20 5.20
450C112M400AC8 87.40 41.20 6.00
450C122M400EB8 83.00 36.90 6.60
450C122M400BH8 92.90 43.00 6.30
450C132M400AD8 75.90 36.20 6.70
450C152M400BB8 71.40 33.30 7.60
450C152M400AE8 67.20 32.50 7.50
450C152M400EJ8 67.50 30.30 7.50
450C162M400AF8 60.40 29.60 8.30
450C182M400EC8 59.40 26.90 8.50
450C192M400BJ8 58.20 27.40 9.40
10.60
11.70
12.10
11.90
12.90
13.60
14.70
15.30
15.60
17.10
17.50
19.10
19.30
20.80
1 3/8 X 4 3/4
1 3/8 X 5 1/4
1 3/4 X 3 3/4
2 X 3 1/4
1 3/8 X 5 3/4
1 3/4 X 4 1/4
2 X 3 3/4
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
2 X 4 3/4
1 3/4 X 5 3/4
2 X 5 1/4
2 X 5 3/4
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/8 X 2 3/4
1 3/4 X 2 1/4
1 3/8 X 3 1/4
2 X 2 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
1 3/8 X 4 1/4
2 X 2 3/4
1 3/4 X 3 1/4
1 3/8 X 4 3/4
1 3/4 X 3 3/4
2 X 3 1/4
1 3/8 X 5 1/4
1 3/8 X 5 3/4
1 3/4 X 4 1/4
2 X 3 3/4
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
2 X 4 3/4
1 3/4 X 5 3/4
2 X 5 1/4
2 X 5 3/4
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/8 X 2 3/4
1 3/4 X 2 1/4
1 3/8 X 3 1/4
2 X 2 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
1 3/8 X 4 1/4
1 3/4 X 3 1/4
2 X 2 3/4
1 3/8 X 4 3/4
2 X 3 1/4
1 3/8 X 5 1/4
1 3/4 X 3 3/4
1 3/8 X 5 3/4
1 3/4 X 4 1/4
2 X 3 3/4
2100
2200
2300
2600
2600
3100
3400
210
310
400
520
580
650
700
710
840
870
920
990
1100
1100
1200
1200
1400
1400
1600
1700
1800
2000
2000
2300
2600
150
230
330
350
430
440
500
530
620
630
660
700
820
830
830
930
970
1000
1100
1200
1300
1400
1400
1700
1900
3.30
4.60
5.60
6.60
6.90
7.50
8.30
8.00
9.10
9.60
10.20
10.10
11.60
11.40
11.20
12.30
13.00
14.10
14.60
15.10
16.40
16.80
18.30
18.60
20.10
3.10
4.40
5.40
6.40
6.60
7.30
8.10
7.70
8.70
9.90
9.30
9.70
11.10
10.80
11.30
11.90
12.60
13.70
450C212M400ED8 51.60 23.70 9.60
450C222M400BC8 50.10 24.30 10.20
450C232M400EE8 45.70 21.20 10.80
450C262M400EF8 41.10 19.40 12.20
450C262M400BD8 43.30 20.70 11.40
450C312M400BE8 37.00 18.10 12.70
450C342M400BF8 33.40 16.60 13.90
450 Vdc (500 Vdc Surge)
450C211M450AK8 384.00 171.00 2.00
450C311M450AA8 256.00 115.00 2.90
450C401M450AH8 178.00 80.40 3.50
450C521M450EA8 157.00 69.20 4.10
450C581M450AB8 137.00 62.30 4.30
450C651M450BA8 138.00 63.30 4.80
450C701M450EH8 116.00 50.10 5.20
450C711M450AJ8 111.00 51.10 5.10
450C841M450AC8 93.90 43.60 5.80
450C871M450BH8 99.20 45.00 6.10
450C921M450EB8 88.90 38.80 6.40
450C991M450AD8 81.50 38.30 6.50
450C112M450EJ8 72.30 31.80 7.30
450C112M450AE8 72.10 34.30 7.20
450C122M450AF8 64.80 31.20 8.00
450C122M450BB8 76.30 34.90 7.40
450C142M450BJ8 62.10 28.70 9.10
450C142M450EC8 63.60 28.30 8.20
450C162M450ED8 55.20 24.80 9.30
450C172M450BC8 53.40 25.40 9.90
450C182M450EE8 48.90 22.30 10.50
450C202M450EF8 44.00 20.30 11.80
450C202M450BD8 46.20 21.60 11.00
450C232M450BE8 39.40 18.90 12.30
450C262M450BF8 35.60 17.30 13.40
500 Volts (550 Volts Surge)
450C151M500AK8 440.00 158.00 1.90
450C231M500AA8 294.00 106.00 2.70
450C331M500AH8 204.00 73.80 3.30
450C351M500EA8 262.00 146.00 3.70
450C431M500AB8 157.00 57.00 4.10
450C441M500BA8 208.00 122.00 4.40
450C501M500EH8 182.00 102.00 4.80
450C531M500AJ8 128.00 46.70 4.70
450C621M500BH8 144.00 85.30 5.70
450C631M500AC8 145.00 82.80 5.40
450C661M500EB8 140.00 78.60 5.90
450C701M500AD8 93.50 34.70 6.10
450C821M500EJ8 114.00 64.40 6.80
450C831M500BB8 111.00 66.00 6.90
450C831M500AE8 82.70 31.00 6.80
450C931M500AF8 74.30 28.20 7.50
450C971M500EC8 96.00 54.80 7.60
450C102M500BJ8 90.40 54.10 8.50
450C112M500ED8 83.30 48.00 8.60
450C122M500BC8 76.40 46.20 9.30
450C132M500EE8 73.70 42.80 9.70
450C142M500EF8 66.30 38.90 11.00
450C142M500BD8 66.40 40.50 10.30
450C172M500BE8 57.30 35.40 11.50
450C192M500BF8 51.80 32.30 12.60
14.20
14.70
15.90
17.80
16.40
18.20
19.70
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
1 3/4 X 5 3/4
2 X 4 3/4
2 X 5 1/4
2 X 5 3/4
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/8 X 2 3/4
1 3/4 X 2 1/4
1 3/8 X 3 1/4
2 X 2 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
1 3/8 X 4 1/4
2 X 2 3/4
1 3/4 X 3 1/4
1 3/8 X 4 3/4
1 3/4 X 3 3/4
1 3/8 X 5 1/4
1 3/8 X 5 3/4
2 X 3 1/4
2 X 3 3/4
1 3/4 X 4 1/4
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
1 3/4 X 5 3/4
2 X 4 3/4
2 X 5 1/4
2 X 5 3/4
1 3/8 X 1 3/4
1 3/8 X 2 1/4
1 3/8 X 2 3/4
1 3/4 X 2 1/4
1 3/8 X 3 1/4
2 X 2 1/4
1 3/4 X 2 3/4
1 3/8 X 3 3/4
2 X 2 3/4
1 3/8 X 4 1/4
1 3/4 X 3 1/4
1 3/8 X 4 3/4
1 3/4 X 3 3/4
2 X 3 1/4
1 3/8 X 5 1/4
1 3/8 X 5 3/4
1 3/4 X 4 1/4
2 X 3 3/4
1 3/4 X 4 3/4
2 X 4 1/4
1 3/4 X 5 1/4
1 3/4 X 5 3/4
2 X 4 3/4
2 X 5 1/4
2 X 5 3/4
3.10
4.30
5.30
6.30
6.40
7.10
7.90
7.50
8.50
9.10
9.60
9.50
11.00
10.50
11.60
10.90
13.50
12.30
13.90
14.40
15.50
17.40
16.10
17.80
19.30
3.20
4.50
5.50
6.00
6.70
6.90
7.70
7.80
9.00
8.90
9.50
9.90
10.90
10.70
11.00
12.20
12.20
13.30
13.70
14.50
15.40
17.30
15.90
17.70
19.10
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864) 843-2277 • Fax: (864) 843-3800 • www.cde.com
Notice and Disclaimer:
All product drawings, descriptions, specifications, statements, information and
data (collectively, the “Information”) in this datasheet or other publication are subject to change. The
customer is responsible for checking, confirming and verifying the extent to which the Information con-
tained in this datasheet or other publication is applicable to an order at the time the order is placed. All
Information given herein is believed to be accurate and reliable, but it is presented without any guaran-
tee, warranty, representation or responsibility of any kind, expressed or implied. Statements of suitability
for certain applications are based on the knowledge that the Cornell Dubilier company providing such
statements (“Cornell Dubilier”) has of operating conditions that such Cornell Dubilier company regards
as typical for such applications, but are not intended to constitute any guarantee, warranty or representa-
tion regarding any such matter – and Cornell Dubilier specifically and expressly disclaims any guarantee,
warranty or representation concerning the suitability for a specific customer application, use, storage,
transportation, or operating environment. The Information is intended for use only by customers who
have the requisite experience and capability to determine the correct products for their application. Any
technical advice inferred from this Information or otherwise provided by Cornell Dubilier with reference
to the use of any Cornell Dubilier products is given gratis (unless otherwise specified by Cornell Dubilier),
and Cornell Dubilier assumes no obligation or liability for the advice given or results obtained. Although
Cornell Dubilier strives to apply the most stringent quality and safety standards regarding the design
and manufacturing of its products, in light of the current state of the art, isolated component failures may
still occur. Accordingly, customer applications which require a high degree of reliability or safety should
employ suitable designs or other safeguards (such as installation of protective circuitry or redundancies
or other appropriate protective measures) in order to ensure that the failure of an electrical component
does not result in a risk of personal injury or property damage. Although all product-related warnings,
cautions and notes must be observed, the customer should not assume that all safety measures are indi-
cated in such warnings, cautions and notes, or that other safety measures may not be required.
Embedded System
京公网安备 11010802033920号
EEWORLD
