Features
■
■
■
■
■
Applications
■
■
■
8 or 10 position coded switch
Miniature industrial switch multi-position
Vertical adjust
Rugged surface mount design
Rugged lead frame construction
Board address
Instrumentation
Test equipment
7744 SMD 4 mm Square Sealed Coded Switch
Electrical Characteristics
Contact Rating
Maximum Current ...........100 mA max.
Maximum Voltage .........................16 V
Contact Resistance
..............................100 milliohms max.
Insulation Resistance .....1000 megohms
Dielectric Strength ....................250 volts
General Characteristics
Switch Type ..................................Binary
Operating Temperature Range
................................-55 °C to +125 °C
Storage Temperature Range
................................-55 °C to +125 °C
Seal Test .......................85 °C Fluorinert*
Mechanical Characteristics
Positions ......................................8 or 10
Adjustment Detent Torque
....................................... 0.1-2.5 N-cm
Environmental Characteristics
Shock ............................................100 G
...................0.1 ms. max. discontinuity
Vibration ..........................................20 G
...................0.1 ms. max. discontinuity
Thermal Shock (5 cycles)
................................-55 °C to +125 °C
Contact Resistance
.............................100 milliohms max.
Humidity
Insulation Resistance
................................10 megohms min.
Contact Resistance
..............................100 milliohms max.
Actuation Life .......................1,000 steps
Contact Resistance
..............................100 milliohms max.
Maximum Soldering Heat ...........245 °C,
5 seconds
Standard Packaging
Tube ......................J, G = 50 pcs./tube
H = 100 pcs./tube
Tape & Reel .....................500 pcs./reel
How to Order
4
N/C
Product Dimensions
7744J-8
4.80
(.189)
1 C 2
2.55
(.100)
7744G-8
0.20 TYP
(.008)
0.05
±
0.05
(.002
±
.002)
TYP
5.00
(.197)
1 C 2
2.55
(.100)
TYP 6.20
(.244)
2.55
(.100)
0.05
±
0.05
(.002
±
.002)
4.50 4.80
(.177) (.189)
N/C
2.54
(.10)
4
5.00
4.50
(.177) (.197)
RECOMMENDED PCB LAYOUT
1.27
(.050)
2.54
0.41 TYP (.10)
(.016)
2.54
(.10)
N/C
4
5° MAX TYP.
0.20 TYP
(.008)
1.27
(.050)
0.41 TYP
(.016)
RECOMMENDED PCB LAYOUT
2.54
(.10)
1.27
(.050)
2.70
2
C
1
1.27
(.050)
2.00
(.079)
2
C
1
1.00 TYP
(.039)
4.00
(.157)
1.50 TYP
(.059)
0.71 TYP
(.028)
7744J-10
4.80
(.189)
1 C 2
2.55
(.100)
0.20 TYP
(.008)
0.05
±
0.05
(.002
±
.002)
TYP
4
N/C
1.31 TYP
(.051)
0.71 TYP
(.028)
5.40
(.216)
7744G-10
5.00
(.197)
1 C 2
2.55
(.100)
0.05
±
0.05
(.002
±
.002)
2.55
(.100)
TYP 6.20
(.244)
4.50 4.80
(.177) (.189)
8
4
5.00
4.50
(.177) (.197)
2.54
(.10)
RECOMMENDED PCB LAYOUT
1.27
(.050)
TYP 2.54
(.10)
5° MAX TYP.
1.27
(.050)
2.00
(.079)
8
2.54
(.10)
4
1.27
(.050)
0.41 TYP
(.016)
C
1
2
C
1
0.41
(.016)
0.20 TYP
(.008)
RECOMMENDED PCB LAYOUT
2.54
(.10)
1.27
(.050)
2.70
1.00 TYP
(.039)
1.50 TYP
(.059)
4.00
(.157)
2
0.71 TYP
(.028)
4
8
7744 J - 1 - 008 E
Model
Terminal
Switch Type
1 = Standard
Number of Positions
008 = Binary coded octal
010 = Binary coded decimal
Embossed Tape Option
(Omit letter for tube)
TOLERANCES:
±.2
EXCEPT WHERE NOTED.
MM
DIMENSIONS:
(IN)
"OFF" POSITION IS COMMON.
4
8
1.31 TYP
(.051)
0.71 TYP
(.028)
5.40
(.216)
Specifications are subject to change without notice.
