ALUMINUM ELECTROLYTIC CAPACITORS
UT
6mmL Chip Type , Wide Temperature Range
series
Chip type with load life 2000 hours at +105
°C
.
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine using carrier tape.
UA
Long Life
UT
Long Life
WT
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
UX
Higher C/V
Performance Characteristics
– 55 ~ +105°C
4 ~ 50V
0.1 ~ 100µF
± 20% at 120Hz, 20°C
After 2 minutes' application of rated voltage, leakage current is not more than 0.01 CV or 3 (µA) , whichever is greater.
Measurement frequency :120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
4
0.37
6.3
0.28
4
6
12
10
0.24
6.3
3
8
16
0.20
10
3
5
25
0.16
16
2
4
25
2
3
35
0.13
35
2
3
50
0.12
50
2
3
Measurement frequency :120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance ratio
Z– 40°C / Z+20°C
ZT / Z20 (MAX.)
Endurance
After 2000 hours' application of rated voltage
at 105°C , capacitors meet the characteristic
requirements listed at right.
Capacitance
change
tan
δ
Leakage current
Within ±25% of initial value (16V or less)
Within ±20% of initial value (25V or more)
200% or less of initial specified value
Initial specified value or less
Shelf Life
Resistance to soldering
heat
Marking
After leaving capacitors under no load at 105°C for 1000 hours,
they meet the specified value for endurance characteristics listed above.
The capacitors shall be kept on the hot plate maintained at 250°C
Capacitance change
for 30 seconds. After removing from the hot plate and restored
tan
δ
at room temperature, they meet the characteristic requirements
Leakage current
listed at right.
Black print on the case top.
Within ±10% of initial value
Initial specified value or less
Initial specified value or less
Chip Type
105°C Marking
Capacitance
Lot No.
Plastic platform
0.3MAX.
Voltage
0.5MAX.
Positive
Type numbering system (Example : 16V 10
µ
F)
1
2
3
4
5
6
7
8
9 10 11 12 13 14
UU T 1 C 1 0 0 M CR1 GS
φD
4
C±0.2
X2P
10
16V
φD±0.5
B±0.2
E
A
B
C
E
L
1.8
4.3
4.3
1.0
5.8
5
2.1
5.3
5.3
1.3
5.8
(mm)
6.3
2.4
6.6
6.6
2.2
5.8
Taping code
Configuration
Capacitance tolerance (±20%)
Rated Capacitance (10µF)
Rated voltage (16V)
Series name
Type
L±0.3
Voltage mark for 6.3V is
6V .
0.5 ~ 0.8
Negative
A±0.2
A±0.2
•
The lead-free product is also available upon request.
In this case, L will be put at 11th digit of type numbering system.
Dimensions
V
Cap.(µF)
Code
4
0G
6.3
0J
10
1A
16
1C
25
1E
35
1V
4
4
4
4
4
4
4
5
6.3
50
1H
1.0
2.6
3.2
3.8
6.2
11
14
19
30
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
100
0R1
R22
R33
R47
010
2R2
3R3
4R7
100
220
330
470
101
4
5
5
6.3
22
30
36
60
4
5
5
6.3
22
30
36
60
5
5
6.3
6.3
27
35
46
60
4
5
6.3
6.3
18
30
40
50
4
5
6.3
6.3
13
23
38
48
4
5
6.3
15
25
42
Case size
φ
D (mm)
Allowable
Rated
ripple
ripple
Rated Ripple (mA rms) at 105°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz~
1.50
Taping specifications are given in page 22.
Recommended land size are given in page 23
Please refer to page 3 for the minimum order quantity.
CAT.8100T
