SCB63C
SMD POWER INDUCTORS
XXX
MARKING
●
Features
1. Magnetically shielded construction
2 Excellent Power Density
3 Engineered to Provide High Efficiency
CHARACTERISTICS
Part Number
料號
Inductance
(uH)
(1)
Test
Frequency
DCResistance
(Ω
MAX)
(2)
Saturation
(3)
Current
(A)
Temperature
(4)
Current
(A)
BCB63C I nduct ance decr ease
by current
SCB63C Inductance decrease
by cur r ent
1000
SCB63C-2R2
SCB63C-3R3
SCB63C-4R7
SCB63C-6R8
SCB63C-100
SCB63C-120
SCB63C-150
SCB63C-180
SCB63C-220
SCB63C-270
SCB63C-330
SCB63C-390
SCB63C-470
SCB63C-560
SCB63C-680
SCB63C-820
SCB63C-101
SCB63C-121
SCB63C-151
SCB63C-181
SCB63C-221
SCB63C-271
SCB63C-331
2.2
3.3
4.7
6.8
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
1KHZ
39m
49m
63m
75m
94m
115m
135m
152m
191m
214m
259m
299m
356m
401m
473m
572m
670m
860m
990m
1.27
1.80
1.96
2.32
1.60
1.40
1.15
0.90
0.80
0.60
0.59
0.57
0.53
0.44
0.42
0.33
0.32
0.30
0.27
0.25
0.24
0.23
0.20
0.14
0.13
0.12
0.11
3.80
3.00
2.70
2.40
2.00
1.80
1.62
1.45
1.30
1.17
1.12
1.00
0.95
0.90
0.80
0.70
0.63
0.56
0.53
0.48
0.41
0.36
0.34
Inductance (µH)
uH
I nduct ance( )
331
100
470
10
2R2
1
0. 1
10
100
DC cur r ent (
(mA)
A)
DC current
m
1000
10000
100000
SCB63C Temperature
r
rise
by cur r ent
BC
B63C Tem at ur e i se
by current
per
Temperature rise °C
Tem at ur e r i se ℃
per
80
70
60
50
40
30
20
10
0
1000
2000
3000
4000
5000
6000
7000
8000
9000
331
470
2R
2
D
DC current
(
(mA)
C cur r ent m
A)
(1). Inductance tolerance for 2.2uH~6.8uH:
±30%,
for 10uH~330uH:
±20%.
Tested at 0.25V, 0ADC and 25℃
(2). DCR measured at 25℃.
(3). The DC current at which the inductance decreases by 10% from its initial value.
(4). The DC current that results in a 40℃ temperature rise from 25℃ambient.
