Solenoid valve banks for connection by multi-core cable
Part numbers
With sub-base Ø 4
With sub-base Ø 6
81 517 401*
81 517 402*
24 V
c
+ 10 % - 15 %
40 mA
SUB D 15 connector
1500 V
100 MΩ
8 (17.5 mm) for 3/2 or 4/2, mono or 4
bistable miniature control valve
1 common point with 2 push-in
connectors for 6 mm o.d. tubing.
1 common point with 2 push-in
connectors for 6 mm o.d. tubing
2 push-in connectors for 4 mm or
6 mm o.d. tubing for each
miniature control valve
2 to 8 bars for 81 516 miniature
control valves
3 to 8 bars for 81 513 miniature
control valves
Compressed air or inert gas
oil-free air filtered to 50 µ
IP 20 (IEC 529)
-5 °C to +50 °C (IEC 68-2-14)
-15 °C to +50 °C (IEC 68-2 12)
IEC 1131 - 2
700 g
81 517 403 / 404
79
6
5,5
142,4
81 517 403*
81 517 404*
24 V
c
+ 10 % - 15 %
40 mA
SUB D 25 connector
1500V
100 MΩ
16 (17.5 mm) for 3/2 or 4/2, mono or
8 bistable miniature control valve
1 common point with 3 push-in
connectors for 6 mm o.d. tubing.
1 common point with 3 push-in
connectors for 6 mm o.d. tubing
2 push-in connectors for 4 mm or
6 mm o.d. tubing for each
miniature control valve
2 to 8 bars for 81 516 miniature
control valves
3 to 8 bars for 81 513 miniature
control valves
Compressed air or inert gas
oil-free air filtered to 50 µ
1
Electrical characteristics
Supply voltage
Consumption/miniature solenoid valve
Connection by
Dielectric strength acc. to IEC 255-5
Insulation resistance
Pneumatic characteristics
Number of valve mounting positions
Supply pressures
Exhaust
Output
Working pressure
Working medium
5
General characteristics
Degree of protection
Operating temperature
Storage temperature
Vibration resistance
Weight
Dimensions
81 517 401 / 402
79
6
5,5
124,5
1300 g
142,4
135,5
160,2
181
160,2
341
160,2
Connector pin connections
81 517 401 / 402
8
7
6
5
4
3
2
9
1
15 14 13 12 11 10
Possible variations:
- Number of 17.5 mm
mounting locations
(with control valve banks only)
Please consult us
S.V. 1 to 1
S.V. 2 to 2
S.V. 3 to 3
S.V. 4 to 4
S.V. 5 to 5
S.V. 6 to 6
S.V. 7 to 7
S.V. 8 to 8
S.V. 9 to 9
S.V. 10 to 10
Common 11 to 15
135,5
125
125
81 517 403 / 404
13 12 11 10
9
8
7
6
5
4
3
2
1
25 24 23 22 21 20 19 18 17 16 15 14
S.V. 1 to 1
S.V. 2 to 2
S.V. 3 to 3
S.V. 4 to 4
S.V. 5 to 5
S.V. 6 to 6
"
"
"
"
"
"
S.V. 16 to 16
Common 17 to 25
Other information
* N.B. : Products with these part numbers do not include pilot solenoid valves
or miniature control valves. See pages 5/6 and 5/8.
The part numbers given above are for banks without miniature solenoid
valves or miniature control valves.
Products with these components are available on request.
To order, specify :
Standard products
Standard products,
non stocked
1
Part number
Example : Solenoid valve bank 81 517 402
Products and specifications subject to change without notice.
Consult factory for application assistance.
204 Airline Drive, Suite 300, Coppell, Texas 75019 / Tel: (888) 778-2733 / FAX: (888) 329-9773 / www.crouzet-usa.com
5/14
