smt POWer inductOrs
Unshielded Drum Core – PG0016NL Series
Current Rating:
up to 8.5A
Inductance Range:
0.33μH to 220μH
Height:
4.85 mm Max
Footprint:
6.0mm x 5.4mm MAX
electrical specifications @ 25°c — Operating temperature - 40°c to +130°c
6
Part
5
Number
PG0016.331NL
PG0016.561NL
PG0016.681NL
PG0016.821NL
PG0016.102NL
PG0016.152NL
PG0016.222NL
PG0016.272NL
PG0016.332NL
PG0016.472NL
PG0016.682NL
PG0016.822NL
PG0016.103NL
PG0016.123NL
PG0016.153NL
PG0016.183NL
PG0016.223NL
PG0016.273NL
PG0016.333NL
PG0016.393NL
PG0016.473NL
PG0016.563NL
PG0016.683NL
PG0016.823NL
PG0016.104NL
PG0016.124NL
PG0016.154NL
PG0016.184NL
PG0016.224NL
Inductance
@Irated
1
(µH
TYP)
0.29
0.48
0.68
0.71
1.0
1.3
2.1
2.7
3.1
4.2
6.1
7.4
10
12
14
18
21
27
33
39
46
56
68
82
100
120
150
180
217
Irated
2
(A)
8.5
6.6
6.0
6.0
4.5
4.0
3.2
2.9
2.6
2.3
1.8
1.7
1.5
1.4
1.3
1.2
1.1
0.97
0.88
0.80
0.72
0.68
0.61
0.58
0.52
0.48
0.40
0.38
0.35
DCR
(mW)
4.3
6.5
7.0
11
13
16
23
25
30
34
55
60
80
120
140
150
180
200
230
320
370
420
530
600
840
930
1250
1400
1600
Inductance
@ 0Adc
(µH
± 15%)
0.33
0.56
0.68
0.82
1.0
1.5
2.2
2.7
3.3
4.7
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
Saturation Current
3
Isat
(A TYP)
13
10
8.0
7.8
6.8
6.1
5.0
4.2
4.0
3.3
2.9
2.6
2.3
2.1
1.8
1.6
1.6
1.4
1.3
1.1
1.0
0.95
0.80
0.70
0.70
0.60
0.55
0.50
0.50
Heating Current
4
Idc
(A TYP)
8.5
6.6
6.0
6.0
4.5
4.0
3.2
2.9
2.6
2.3
1.8
1.7
1.5
1.4
1.3
1.2
1.1
0.97
0.88
0.80
0.72
0.68
0.61
0.58
0.52
0.48
0.40
0.38
0.35
mechanical
.191
4.85
MAX
.213
5.4
MAX
.005
.039
1.00 TYP
.228
5.8
TYP
.24
6.1
TYP
schematic
XXXNL
DATE
CODE
(1)
(2)
Ø
.236
MAX
6.0
Weight
. . . . . . . . . . 0.46 grams
Tape & Reel
. . . . 1400pcs/reel
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .004
0,10
SUGGESTED PCB LAYOUT
USA 858 674 8100 • Germany 49 7032 7806 0 • Singapore 65 6287 8998 • Shanghai 86 21 54643211 / 2 • China 86 755 33966678 • Taiwan 886 3 4643715
www.pulseeng.com
P683.A (5/09)
smt POWer inductOrs
Unshielded Drum Core – PG0016NL Series
NOTES:
1. Inductance at Irated is a typical inductance value for the component
taken at rated current.
2. The rated current listed is the lower of the saturation current @ 25°C
or
the heating current.
3. The saturation current, Isat, is the current at which the component
inductance drops by 10% (typ.) at an ambient temperature of 25°C. This
current is determined by placing the component in the specified ambient
environment and applying a short duration pulse current (to eliminate
self-heating effects) to the component.
4. The heating current, IDC, is the DC current reqired to raise the compo-
nent temperature by approximately 40°C.
The heating current is deter-
mined by mounting the component on a typical PCB and applying current
for 30 minutes.
5. Optional Tape & Reel packaging can be ordered by adding a “T” suffix to
the part number (i.e. PG0016.331NL becomes PG0016.331NLT). Pulse
complies to industry standard tape and reel specification EIA481.
6. The temperature of the component (ambient plus temperature rise) must
be within the stated operating temperature range.
Typical Inductance vs. Current Characteristics
