3.3V HCMOS SMD OSCILLATOR WITH STANDBY
F330 SERIES
FEATURES
•
•
•
•
3.3V Operation
HCMOS Output
Standby Function
Tape and Reel
(2,000 pcs. STD)
• MODEL NUMBER SELECTION
Model Number
F330
F330R
F335
F335R
F336
F338
Frequency
Stability
1
±100PPM
±100PPM
±50PPM
±50PPM
±25PPM
±20PPM
Operating
Temperature (ºC)
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
-10 ~ +70
Frequency
Range (MHz)
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
1.800 ~ 50.000
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
O
)
Storage Temperature Range (T
STG
)
Supply Voltage
(V
DD
)
Input Current
(I
DD
)
1.800 ~ 32.000 MHz
32.000+ ~ 50.000 MHz
MAX
(unless otherwise noted)
1.800 ~ 50.000 MHz
-55ºC ~ +125ºC
3.3V ± 10%
20mA
25mA
Output Symmetry (50% V
DD
)
1.000 ~ 50.000 MHz
Rise Time (10% ~ 90% V
DD
) (T
R
)
Fall Time (90% ~ 10% V
DD
) (T
F
)
Output Voltage
(V
OL
)
(V
OH
)
Output Current
(I
OL
)
(I
OH
)
Output Load
(HCMOS)
Standby Current (V
IL
≤
0.99V)
Start-up Time
(T
S
)
Output Disable Time
2
Output Enable Time
2
1
45% ~ 55%
6nS
6nS
10% V
DD
90% V
DD
Min
2mA Min
-2mA Min
15pF
10µA
5mS
150nS
5mS
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
2
An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
See
page 29
for mechanical specifications, test circuits, and output waveform.
Note: A 0.01µF bypass capacitor should be placed between VDD (Pin 4) and GND (Pin 2) to
minimize power supply line noise.
All specifications subject to change without notice.
Rev. 3/3/04
All dimensions are in millimeters.
• ENABLE / DISABLE FUNCTION
2
INH (Pin 1)
OUTPUT (Pin 3)
OPEN
3
ACTIVE
'1' Level V
IH
≥
2.31 V
ACTIVE
'0' Level V
IL
≤
0.99 V
High Z
See
page 53
for tape and reel specifications.
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +001(239)693-0099 FAX +001(239)693-1554
http://www.foxonline.com
© 2004 FOX ELECTRONICS
1
