F5D1/2/3
AlGaAs INFRARED EMITTING DIODE
PACKAGE DIMENSIONS
0.209 (5.31)
0.184 (4.67)
DESCRIPTION
• The F5D series is a 880 nm LED in a
narrow angle, TO-46 package.
0.030 (0.76)
NOM
0.255 (6.48)
FEATURES
1.00 (25.4)
MIN
• Good optical to mechanical alignment
ANODE
(CASE)
• Mechanically and wavelength matched
to the TO-18 series phototransistor
• Hermetically sealed package
• High irradiance level
SCHEMATIC
ANODE
(Connected
To Case)
CATHODE
3
0.100 (2.54)
0.050 (1.27)
1
1
0.040 (1.02)
0.040 (1.02)
45°
3
Ø0.020 (0.51) 2X
NOTES:
1. Dimensions for all drawings are in inches (mm).
2. Tolerance of ± .010 (.25) on all non-nominal dimensions
unless otherwise specified.
1. Derate power dissipation linearly 1.70 mW/°C above 25°C ambient.
2. Derate power dissipation linearly 13.0 mW/°C above 25°C case.
3. RMA flux is recommended.
4. Methanol or isopropyl alcohols are recommended as cleaning
agents.
5. Soldering iron tip
1/16”
(1.6mm) minimum from housing.
6. As long as leads are not under any stress or spring tension
7. Total power output, P
O
, is the total power radiated by the device into
a solid angle of 2
!
steradians.
ABSOLUTE MAXIMUM RATINGS
Parameter
Operating Temperature
Storage Temperature
Soldering Temperature (Iron)
(3,4,5 and 6)
Soldering Temperature (Flow)
(3,4 and 6)
Continuous Forward Current
Forward Current (pw, 10µs; 100Hz)
Forward Current (pw, 1µs; 200Hz)
Reverse Voltage
Power Dissipation (T
A
= 25°C)
(1)
Power Dissipation (T
C
= 25°C)
(2)
(T
A
= 25°C unless otherwise specified)
Symbol
T
OPR
T
STG
T
SOL-I
T
SOL-F
I
F
I
F
I
F
V
R
P
D
P
D
Rating
-65 to +125
-65 to +150
240 for 5 sec
260 for 10 sec
100
3
10
3
170
1.3
Unit
°C
°C
°C
°C
mA
A
A
V
mW
W
ELECTRICAL / OPTICAL CHARACTERISTICS
PARAMETER
TEST CONDITIONS
(T
A
=25°C) (All measurements made under pulse conditions)
MIN
TYP
MAX
UNITS
SYMBOL
Peak Emission Wavelength
Emission Angle at 1/2 Power
Forward Voltage
Reverse Leakage Current
Total Power F5D1
(7)
Total Power F5D2
(7)
Total Power F5D3
(7)
Rise Time 0-90% of output
Fall Time 100-10% of output
I
F
= 100 mA
I
F
= 100 mA
I
F
= 100 mA
V
R
= 3 V
I
F
= 100 mA
I
F
= 100 mA
I
F
= 100 mA
"
P
#
V
F
I
R
P
O
P
O
P
O
t
r
t
f
—
—
—
—
12.0
9.0
10.5
—
—
880
±8
—
—
—
—
—
1.5
1.5
—
—
1.7
10
—
—
—
—
—
nm
Deg.
V
µA
mW
mW
mW
µs
µs
2001 Fairchild Semiconductor Corporation
DS300286
4/24/01
1 OF 3
www.fairchildsemi.com
F5D1/2/3
AlGaAs INFRARED EMITTING DIODE
Figure 1. Power Output vs. Input Current
10
P
O
, NORMALIZED POWER OUTPUT
P
O
, NORMALIZED POWER OUTPUT
20
10
8
6
4
2
I
F
= 100 mA
1
0.8
0.6
0.4
0.2
0.1
-25
NORMALIZED TO
I
F
= 100 mA, T
A
= 25°C
P
W
= 80
µsec,
f = 30 Hz
0
25
50
75
,
100
125
150
Figure 2. Power Output vs. Temperature
I
F
= 1 A
1.0
0.1
NORMALIZED TO
I
F
= 100 mA
T
A
= 25°C
PULSED INPUTS
P
W
= 80
µsec
RR = 30 Hz
10
100
1000
0.01
0.001
1
I
F
, INPUT CURRENT (mA)
T
A
, AMBIENT TEMPERATURE (°C)
Figure 3. Forward Voltage vs. Temperature
4
I
F
= 1 A
P
W
= 80
µsec
F = 30 Hz
P
O
, RELATIVE OUTPUT (%)
100
Figure 4. Typical Radiation Pattern
V
F
, FORWARD VOLTAGE (volts)
3
80
F5D
60
I
F
= 0.5 A
2
I
F
= 100 mA
I
F
= 10 mA
40
20
1
-25
0
25
50
75
100
125
150
0
-80
-60
-40
-20
0
20
40
60
80
100
T
A
, AMBIENT TEMPERATURE (°C)
θ,
DISPLACEMENT FROM OPTICAL AXIS (DEGREES)
Figure 5. Output vs. Input with L14G Detector
100
I
F
I
L
L14G
5V
F5D1
Figure 6. Output vs. Wavelength
120
100
P
O
, RELATIVE OUTPUT (%)
80
60
40
20
I
F
= 100 mA
T
A
= 25°C
I
L
, OUTPUT CURRENT (mA)
10
1.0
TYPICAL OUPUTS
AT A DISTANCE OF
10 CM PULSED
INPUTS, P
W
= 80
µsec
RR = 30 Hz
TYPICAL SPECTRAL
RESPONSE OF SILICON
PHOTOSENSORS
F5D
0.1
0.01
10
100
I
F
, INPUT CURRENT (mA)
1000
700
800
900
1000
λ,
WAVE LENGTH (nm)
www.fairchildsemi.com
2 OF 3
4/24/01
DS300286
F5D1/2/3
