SPECIFICATION FOR
ULTRA HIGH Q/LOW ESR MULTILAYER CERAMIC CHIP
CAPACITORS
Part No.
: RF Series
Description : Size 0201 ~ 0603, COG, 25Vdc to 250Vdc
RoHS Compliant
DRAWN BY
CHECKED BY
APPROVED BY
PDC
1. INTRODUCTION
MLCC consists of a conducting material and electrodes. To manufacture a chip-type SMT and achieve miniaturization, high
density and high efficiency, ceramic condensers are used.
PDC RF series MLCC is used at high frequencies generally have a small temperature coefficient of capacitance, typical within
the
±30ppm/°C
required for NP0 (C0G) classification and have excellent conductivity internal electrode. Thus, PDC RF series MLCC
will be with the feature of low ESR and high Q characteristics.
2. FEATURES
a.
b.
c.
d.
e.
f.
High Q and low ESR performance at high frequency.
Ultra low capacitance to 0.1pF.
Can offer high precision tolerance to ±0.05pF.
Quality improvement of telephone calls for low
power loss and better performance.
RoHS compliant
HALOGEM compliant
3. APPLICATIONS
a.
b.
c.
Telecommunication products & equipments: Mobile
phone, WLAN, Base station.
RF module: Power amplifier, VCO.
Tuners.
4. HOW TO ORDER
RF
Series
15
Size
N
Dielectric
100
Capacitance
Two significant
digits followed by
no. of zeros. And
R is in place of
decimal point.
eg.:
0R5=0.5pF
1R0=1.0pF
100=10x10
0
=10pF
J
Tolerance
A=±0.05pF
B=±0.1pF
C=±0.25pF
D=±0.5pF
F=±1%
G=±2%
J=±5%
500
Rated voltage
C
Termination
T
Packaging
T=7”
reeled
G=
13” reeled
RF=Ultra
High Q
03=0201
(0603)
N=NP0
& Low ESR
15=0402
(1005)
(C0G)
18=0603
(1608)
Two significant
C=Cu/Ni/Sn
digits followed by
no. of zeros. And
R is in place of
decimal point.
6R3=6.3
VDC
100=10
VDC
250=25
VDC
500=50
VDC
101=100
VDC
251=250
VDC
Prosperity Dielectrics Co., Ltd.
No.148, Chang-An Rd., Sec.1, Lu-Tsu Shiang, Taoyuan, Taiwan
Page 1 of 7
http://www.pdc.com.tw
ACS-1015 Rev3
PDC
5. EXTERNAL DIMENSIONS
Size
Inch (mm)
0201 (0603)
0402 (1005)
0603 (1608)
0805 (2012)
L (mm)
0.60±0.03
1.00±0.05
1.60±0.10
2.00±0.20
W (mm)
0.30±0.03
0.50±0.05
0.80±0.10
1.25±0.20
T max(mm)
0.33
0.55
0.87
0.95
Remark
#
#
M
B
(mm)
0.15±0.05
0.25+0.05/-0.10
0.40±0.15
0.50±0.20
M
B
M
B
W
L
T
Fig. 1 The outline of MLCC
# Reflow soldering only is recommended.
6. GENERAL ELECTRICAL DATA
Dielectric
Size
Capacitance*
Capacitance tolerance
Rated voltage (WVDC)
Q*
Insulation resistance at Ur
Operating temperature
Capacitance change
Termination
NP0
0201, 0402, 0603
0201: 0.1pF to 33pF;
0402: 0.1pF to 22pF;
0603: 0.3pF to 47pF; 0805: 0.3pF to 100pF
Cap≤5pF: A (±0.05pF ), B (±0.1pF), C (±0.25pF)
5pF<Cap<10pF: B (±0.1pF), C (±0.25pF), D (±0.5pF)
Cap≥10pF: F (±1%), G (±2%), J (±5%)
6.3V, 10V, 25V, 50V, 100V, 250V
Cap≥30pF, Q≥1000; Cap<30pF,Q≥400+20C
≥10G
-55 to +125°
C
±30ppm/°
C
Ni/Sn (lead-free termination)
* Measured at the conditions of 25°C ambient temperature and 30~70% related humidity.
Apply 1.0±0.2Vrms, 1.0MHz±10% for Cap≤1000pF and 1.0±0.2Vrms, 1.0kHz±10% for Cap>1000pF.
Prosperity Dielectrics Co., Ltd.
No.148, Chang-An Rd., Sec.1, Lu-Tsu Shiang, Taoyuan, Taiwan
Page 2 of 7
http://www.pdc.com.tw
ACS-1015 Rev3
PDC
7. CAPACITANCE RANGE
DIELECTRIC
SIZE
RATED VOLTAGE (VDC)
0.1pF (0R1)
0.2pF (0R2)
0.3pF (0R3)
0.4pF (0R4)
0.5pF (0R5)
0.6pF (0R6)
0.7pF (0R7)
0.8pF (0R8)
0.9pF (0R9)
1.0pF (1R0)
1.2pF (1R2)
1.5pF (1R5)
1.8pF (1R8)
2.2pF (2R2)
2.7pF (2R7)
3.3pF (3R3)
3.9pF (3R9)
4.7pF (4R7)
5.6pF (5R6)
6.8pF (6R8)
8.2pF (8R2)
10pF (100)
11pF (110)
12pF (120)
13pF (130)
15pF (150)
16pF (160)
18pF (180)
20pF (200)
22pF (220)
24pF (240)
27pF (270)
30pF (300)
33pF (330)
36pF (360)
39pF (390)
43pF (430)
47pF (470)
56pF (560)
68pF (680)
82pF (820)
100pF (101)
6.3
0201
10
25
50
NP0
0402
100
50
0603
100
250
B
A, B
A, B
A, B
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
A, B, C
B, C, D
B, C, D
B, C, D
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
F, G, J
Tolerance
1. For more information about products with special capacitance or other data, please contact PDC local representative.
8. PACKAGING DIMENSION AND QUANTITY
Size
0201 (0603)
0402 (1005)
0603 (1608)
Unit: pieces
Thickness (mm)
0.30±0.03
0.50±0.05
0.80±0.07
Paper tape
7” reel
15k
10k
4K
13” reel
-
50k
10K
