PC3Q65 Series
PC3Q65 Series
∗
1-channel package type is also available.
(model No.
PC3H5 Series)
Mini-flat Half Pitch 4-channel Package
Darlington Phototransistor Output
Photocoupler
■
Description
PC3Q65 Series
contains an IRED optically coupled
to a phototransistor.
It is packaged in a 4 channel Mini-flat, Half pitch
type.
Input-output isolation voltage(rms) is 2.5kV.
CTR is MIN. 600% at input current of 1mA.
■
Agency approvals/Compliance
1. Recognized by UL1577 (Double protection isolation),
file No. E64380 (as model No.
PC3Q65)
2. Approved by VDE, VDE0884 (as an option), file No.
5922UG (as model No.
PC3Q65)
3. Package resin : UL flammability grade (94V-0)
■
Features
1. 4 channel Mini-flat Half pitch package (Lead pitch :
1.27mm)
2. Double transfer mold package (Ideal for Flow Solder-
ing)
3. Darlington phototransistor output (CTR : MIN. 600%
at I
F
=1mA, V
CE
=2V)
4. Isolation voltage between input and output
(V
iso(rms)
=2.5kV)
■
Applications
1. Programmable controllers
2. Facsimiles
3. Telephones
Notice The content of data sheet is subject to change without prior notice.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
1
Sheet No.: D2-A01801EN
Date Sep. 30. 2003
© SHARP Corporation
PC3Q65 Series
■
Absolute Maximum Ratings
Parameter
Symbol
Forward current
I
F
*1
Peak forward current
I
FM
Reverse voltage
V
R
Power dissipation
P
Collector-emitter voltage V
CEO
Emitter-collector voltage V
ECO
I
C
Collector current
Collector power dissipation
P
C
P
tot
Total power dissipation
T
opr
Operating temperature
T
stg
Storage temperature
*2
Isolation voltage
V
iso (rms)
*3
Soldering temperature
T
sol
(T
a
=25˚C)
Rating
Unit
50
mA
1
A
V
6
70
mW
V
35
6
V
80
mA
150
mW
170
mW
−30
to
+100
˚C
−40
to
+125
˚C
2.5
kV
260
˚C
*1 Pulse width≤100µs, Duty ratio : 0.001
*2 40 to 60%RH, AC for 1 minute, f=60Hz
*3 For 10s
■
Electro-optical Characteristics
Parameter
Symbol
Forward voltage
V
F
I
R
Reverse current
Terminal capacitance
C
t
Collector dark current
I
CEO
Collector-emitter breakdown voltage BV
CEO
Emitter-collector breakdown voltage BV
ECO
Collector current
I
C
Collector-emitter saturation voltage V
CE (sat)
Isolation resistance
R
ISO
Floating capacitance
C
f
Rise time
t
r
Response time
Fall time
t
f
Conditions
I
F
=20mA
V
R
=4V
V=0, f=1kHz
V
CE
=10V,
I
F
=0
I
C
=0.1mA,
I
F
=0
I
E
=10µA,
I
F
=0
I
F
=1mA,
V
CE
=2V
I
F
=1mA,
I
C
=2mA
DC500V, 40 to 60%RH
V=0, f=1MHz
Output
Input
Input
Output
Transfer
charac-
teristics
V
CE
=2V,
I
C
=2mA,
R
L
=100Ω
MIN.
−
−
−
−
35
6
6
−
5×10
10
−
−
−
TYP.
1.2
−
30
−
−
−
16
0.8
1×10
11
0.6
60
53
MAX.
1.4
10
250
1000
−
−
75
1.0
−
1.0
300
250
(T
a
=25˚C)
Unit
V
µA
pF
nA
V
V
mA
V
Ω
pF
µs
µs
Sheet No.: D2-A01801EN
4
