2.0 x 1.6mm Auto Grade Crystal
AEC Q200 Qualified
IATF-16949 QMS
Tolerances down to ±10 PPM
Stabilities down to ±20 PPM
(former FXA2016B)
C1BA
DATASHEET
• SPECIFICATIONS
PARAMETERS
Frequency Range
Frequency Tolerance @ 25ºC
Frequency Stability, ref @ 25ºC
Temperature Range
Operating (T
OPR
)
Storage
(T
STG
)
Shunt Capacitance (C
0
)
Load Capacitance (C
L
)
Drive Level
Aging per year
Maximum Soldering Temp / Time
Moisture Sensitivity Level (MSL)
Termination Finish
Seal Method
Lead (Pb) Free
RoHS Compliant
Frequency Range
(MHz)
16.000 ~ 19.199999
19.200 ~ 25.999999
26.000 ~ 35.999999
36.000 ~ 54.000
MAX
(unless otherwise noted)
16.000 ~ 54.000 MHz
(See options on page 2)
(See options below)
See options below
-55ºC ~ +150ºC
3pF
(See options on page 2)
100µW
±5 PPM
260ºC / 10 Seconds x 2
1
Au over Ni
Seam
Yes
Yes
Operating Mode
Fundamental
Fundamental
Fundamental
Fundamental
Max ESR
Ω
200
100
80
60
Note: Dimensional drawing is for reference to critical specifications
defined by size measurements.
•Available Operating Temperatures and Stabilities
Operating
Temperature
-40 ~ +85ºC
-40 ~ +105ºC
-40 ~ +125ºC
-55 ~ +125ºC
±20 PPM
O
X
X
X
±25 PPM
O
X
X
X
±30 PPM
O
O
X
X
±50 PPM
O
O
O
O
±100 PPM
O
O
O
O
Key: O=Available, X=Not Available,
1
Does not imply stocked part.
Reference / Comments
© Copyright 2019 Fox Electronics. All rights reserved
Title / Description:
C1BA SERIES STANDARD SPECIFICATIONS
Drawing Number:
C1BA-DOC-2
Size: A
Part Number:
Cage:
61429
Draftsperson:
BEC
Approved:
MAJ
Date:
06/06/2019
2.0 x 1.6mm Auto Grade Crystal
• TAPE SPECIFICATIONS
(millimeters)
A
B
C
4.0
D
3.5
E
8.0
F
0.65
Reel QTY
(former FXA2016B)
C1BA
DATASHEET
• REEL SPECIFICATIONS
(millimeters)
G
2.5
H
13
I
21
J
60
K
180
L
9.0
M
2.0
1.55
4.0
-T3 = 3,000
-T2 = 2,000
-T1 = 1,000
1.75
Available Options & Part Identification for Automotive Crystal Model C1BA
1
F C1BA B C V I 40.0
F
FOX
C1BA
Model
Number
B
Tolerance
B = ±50 PPM
C = ±30 PPM
D = ±25 PPM
E = ±20 PPM
F = ±15 PPM
H = ±10 PPM
C
Stability
A = ±100 PPM
B = ±50 PPM
C = ±30 PPM
D = ±25 PPM
E = ±20 PPM
V
Load
Capacitance
2
V=7pF
D=8pF
E=10pF
G=12pF
J=15pF
K=16pF
L=18pF
M=20pF
I
40.0
Frequency
Operating
(MHz)
Temperature
M = -40 to +85°C
P = -40 to +105°C
I = -40 to +125°C
T = -55 to +125ºC
1
2
Not all frequency, tolerance, stability, load, and operating temperature combinations may be available
.
Listed load capacitances represent the most commonly used. Other load capacitances are available. Contact Fox Technical Support for assistance
