Series 8XXX Elevator Socket
w/Bifurcated Contacts
FEATURES
• Ideal for elevating devices (displays, switches, etc.) to desired level with 0.260 to
1.250 [6.60 to 31.75] height extension.
GENERAL SPECIFICATIONS
• STANDARD SOCKET BODY: black UL 94V-0 glass-filled 4/6 Nylon
• BIFURCATED CONTACTS: Grade A spring-tempered Phosphor Bronze per QQ-B-
750
• CONTACT PLATING: “-10” 50-130µ [1.27-3.30µ] matte Sn per ASTM B545-
97(2004)e1 over 50µ [1.27µ] Ni per SAE AMS-QQ-N-290B; “-10TL” 50-130µ
[1.27-3.30µ] 90/10 Sn/Pb per MIL-T-10727 Type 1 over 50µ [1.27µ] Ni per
SAE AMS-QQ-N-290B; “-11” 10µ [0.25µ] min. Au per MIL-G-45204 over 50µ
CUSTOMIZATION:
In addition to the standard products shown
[1.27µ] Ni per SAE AMS-QQ-N-290B. (consult factory for availability).
on this page, Aries specializes in custom design and production.
• CONTACT CURRENT RATING: 1 amp
Special materials, platings, sizes, and configurations can be
furnished, depending on the quantity.
NOTE:
Aries reserves the
• INSERTION FORCE: 110g/pin average
right to change product general specifications without notice.
• WITHDRAWAL FORCE: 75g/pin average
• OPERATING TEMPERATURE: -67°F to 221°F [-55°C
ORDERING INFORMATION
to 105°C] Sn and Sn/Pb plating; -67°F to 257°F
XX-X8 XXXX-1XXX XX
[-55°C to 125°C] Au plating
• ACCEPTS: flat leads up to 0.014 thick x 0.020 wide
Optional Suffix
No. of Pins
[0.36-0.51], Round Leads up to 0.020 [0.51] dia.
WR = Without Rails
10, 14, 16
Plating
• SOCKET ACCEPTS: lead lengths from seating plane
Row-to-Row Spacing
10
= Sn
8 = 0.300 [7.62] Centers
0.075-0.160 [1.91-4.06]
MOUNTING CONSIDERATIONS
• SUGGESTED PCB HOLE SIZE: 0.035 ±0.002 [0.89
±0.05] dia.
ELEVATOR SOCKETS WITH COLLET CONTACT AVAILABLE
SEE DATA SHEET 13007 AND 13008
(14- & 16-pin)
28 = 0.200 [5.08] Centers
(10-pin only)
10TL
= Sn/Pb
11
= Au (Consult Factory)
Seating Plane Height
(see Table, Dim “C”)
Part No.
10-28440-10
14-8260-10
14-8350-10
14-8400-10
14-8435-10
14-8470-10
14-8510-10
14-8620-10
14-8770-10
14-8870-10
14-81000-10
14-81100-10
14-81187-10
14-81250-10
16-8430-10
16-8480-10
16-8700-10
16-8810-10
16-81250-10
Dim. "C"
0.440 [11.18]
0.260 [6.60]
0.350 [8.89]
0.400 [10.16]
0.440 [11.18]
0.470 [11.94]
0.510 [12.95]
0.620 [15.75]
0.770 [19.56]
0.870 [22.10]
1.000 [24.40]
1.100 [27.94]
1.180 [29.97]
1.250 [31.75]
0.430 [10.92]
0.480 [12.19]
0.700 [17.78]
0.810 [20.57]
1.250 [31.75]
ALL DIMENSIONS IN INCHES [MILLIMETERS]
CONSULT FACTORY FOR NON-STANDARD SIZES
ALL TOLERANCES ±0.005 [±0.13] UNLESS OTHERWISE SPECIFIED
“A” (# PINS PER ROW x 0.100 [2.54]) +0.050 [1.27]
“B” (# PINS PER ROW -1) x 0.100 [2.54]
Bristol, PA 19007-6810 USA
TEL (215) 781-9956 • FAX (215) 781-9845
WWW.ARIESELEC.COM • INFO@ARIESELEC.COM
PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED
13006
1 of 1
Rev. AA
