DUAL-IN-LINE SOCKETS
Surface Mount, Stub Tail, with
Alignment Pins for Hand Placement
•
Unique floating contacts
compensate for effects of
unevenly dispensed solder
paste.
•
Two corner alignment pins
(power & ground positions)
permit manual placement.
•
High temperature insulator
can withstand infra-red reflow
and vapor phase soldering.
•
Hi-Rel, 4-finger BeCu #30 clip
rated at 3 amps. See page
208 for details.
•
Uses Mill-Max #1334 & 1434
pins. See pages 140 & 131.
Series 113
.059 DIA.
PADS
.028 DIA.
PTH x2
Ø.020 ALIGNMENT PINS,
.064 LONG, x2
Total number
of pins
Quantity
per tube
Ordering Information
ALIGNMENT PINS
A
B
C
10
4
6
8
10
14
16
18
20
22
24
28
20
22
24
28
32
24
28
32
36
40
42
48
50
52
50
52
64
0.5
0.2
0.3
0.4
0.5
0.7
0.8
0.9
1.0
1.1
1.2
1.4
1.0
1.1
1.2
1.4
1.6
1.2
1.4
1.6
1.8
2.0
2.1
2.4
2.5
2.6
2.5
2.6
3.2
0.2
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.4
0.4
0.4
0.4
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.9
0.9
0.9
0.3
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.5
0.5
0.5
0.5
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
1.0
1.0
1.0
41
100
67
50
40
28
25
22
20
18
16
14
20
18
16
14
12
16
14
12
11
10
9
8
8
7
8
7
6
PLATING CODE =
113-93-210-41-117
113-93-304-41-117
113-93-306-41-117
113-93-308-41-117
113-93-310-41-117
113-93-314-41-117
113-93-316-41-117
113-93-318-41-117
113-93-320-41-117
113-93-322-41-117
113-93-324-41-117
113-93-328-41-117
113-93-420-41-117
113-93-422-41-117
113-93-424-41-117
113-93-428-41-117
113-93-432-41-117
113-93-624-41-117
113-93-628-41-117
113-93-632-41-117
113-93-636-41-117
113-93-640-41-117
113-93-642-41-117
113-93-648-41-117
113-93-650-41-117
113-93-652-41-117
113-93-950-41-117
113-93-952-41-117
113-93-964-41-117
93
200µ” Sn/Pb
30µ” Au
Sleeve (Pin)
Contact (Clip)
